Table of contents

Introduction .............................................................................................................................. 4
BeeHive8S elements ............................................................................................................. 7
Manipulation with the programmed device ............................................................................ 8
In-system serial programming by BeeHive8S........................................................................ 8
Selftest and calibration check ................................................................................................ 9
Technical specification......................................................................................................... 11
Programming a device........................................................................................................... 16
Engineering mode................................................................................................................ 16
Production mode.................................................................................................................. 20
Software .................................................................................................................................. 23
Detailed description of Graphics user interface with touch screen ...................................... 23
Administration of build in PC................................................................................................ 39
Troubleshooting and warranty.............................................................................................. 43
Troubleshooting ................................................................................................................... 43
If you have an unsupported target device............................................................................ 44
Maintenance ........................................................................................................................ 44
Warranty terms .................................................................................................................... 45
Conventions used in the manual
References to the control program functions are in bold, e.g. Load, File, Device, etc.
References to control keys are written in brackets <>, e.g. <F1>.
Terminology used in the manual:
Device
ZIF socket
Buffer
USB port
HEX data format
Please, download actual version of manual from
ELNEC WEB site (www.elnec.com), if current one
will be out of date.
any kind of programmable integrated circuits or programmable
devices
Zero Insertion Force socket used for insertion of target device
part of memory or disk, used for temporary data storage
type of PC port
format of data file, which may be read with standard text viewers;
e.g. byte 5AH is stored as characters '5' and 'A', which mean
bytes 35H and 41H. One line of this HEX file (one record) contains
start address and data bytes. All records are secured with
checksum.
