Plug connector for power supply, M12x1 socket,
4-pin for cable Ø 4 – 8 mm, A-coded
Plug-in connection for power supply plug 7/8",
5-pin, socket
Plug connector for input/output modules
AVENTICS | PROFINET-IO | R412015162–BDL–001–AE
10.3 Power plug for bus coupler
and output module
180° (X10, POWER)
90° (X10, POWER)
M12x1 plug, straight
M12x1 plug, angled
M12x1 dual plug for cable
Ø 3 mm or 5 mm

11 Disposal

Dispose of the device in accordance with the currently
applicable regulations in your country.
113
Disposal
Order number
8941054324
8941054424
R412010402
1834484222
1834484223
1834484246
