Reparaturanleitung | Repair instruction
Ersatzteilsatz
Spare kit
Serie 523 / ITS
R961403359-RAW-001-AD/09.2014,
Replaces: 22.09.2014, DE/EN
Durchmesser / Ersatzteilsatz /
Diameter Sparepart kit
Ø 32 5230030002
Ø 40 5231030002
Ø 50 5232030002
Ø 63 5233030002
Ø 80 5234030002
Ø100 5235030002
Ø 125 5236030002
Ø 160 5237030002
Ø 200 5238030002
Ø 250 5239030002
Ø 320 5239010012
Stückliste /
Bill of Material
Tabelle 1 / Table 1
Tabelle 2 / Table 2
Tabelle 3 / Table 3
Tabelle 4 / Table 4
Tabelle 5 / Table 5
Tabelle 6 / Table 6
