3. Use genuine Hyundai spare parts for the replacement of parts. We expressly point out that Hyundai will not accept any responsibility for defects resulting from non- genuine parts or non workmanlike repair. In such cases Hyundai cannot assume liability for any damage.
The procedures in this manual do not supersede any requirements imposed by federal, state, provincial or local laws. Hyundai can not anticipate every possible circumstance or environment in which this machine may be used and serviced. All personnel must remain alert to potential hazards.
SAFETY LABELS 1. LOCATION Always keep these labels clean. If they are lost or damage, attach them again or replace them with a new label. DETAIL - D PUMP ROOM VIEW - A DETAIL - C R130 37, 38 2-15 CAB - RH CAB - RH CONSOLE BOX-LH...
Page 6
2. DESCRIPTION There are several specific warning labels on this machine please become familiarized with all warning labels. Replace any safety label that is damaged, or missing. AIR CLEANER FILTER(Item 1) This warning label is positioned on the air cleaner cover. Periodic and proper inspection, cleaning and change of elements prolong engine life time and maintain the good...
Page 7
BATTERY ACCIDENT(Item 5) This warning label is positioned on the battery cover. Electrolyte containing sulfuric acid cause severe burns. Avoid being in contact with skin, eyes or clothes. In the event of accident flush with sufficient water, call a physician immediately. Maintain electrolyte recommended level.
Page 8
HYDRAULIC OIL LUBRICATION(Item 8) This warning label is positioned on the right side of air breather. Do not mix with different brand oils. Never open the filler cap while engine running or at high hydraulic oil temperature. Loosen the cap slowly and release internal pressure completely.
Page 9
SIDE KEEP CLEAR(Item 13) This warning label is positioned on the side of counterweight. To prevent serious personal injury or death keep clear of machine swing radius. Do not deface or remove this label from the machine. 21070FW13 STAY FIX(Item 14) This warning label is positioned on the side cover.
Page 10
NO STEP-ENGINE HOOD(Item 16) This warning label is positioned on the engine hood. Do not step on the engine hood. 21070FW16 TRANSPORTING(Item 17) This warning label is positioned right side of upper frame. Study the operator's manual before transporting the machine, if provided and tie down arm and track to the carrier with lashing wire.
Page 11
CONTROL IDEOGRAM-RH(Item 21) This warning label is positioned on the RH console box. Check the machine control pattern for conformance to pattern on this label. not, change label to match pattern before operating machine. Failure to do so could result in injury or death.
Page 12
ALTERNATE EXIT(Item 25) This warning label is positioned on the inside of rear window. The rear window serves us an alternate exit. To remove rear window, pull the ring and push out the glass. 21070FW25 AIR CONDITIONER FILTER(Item 26) This warning label is positioned on the air conditioner cover up.
Page 13
INTERFERENCE(Item 29) This warning label is positioned on the right side frame of cab. Be careful to operate machine equipped with quick clamp or extensions. Bucket may hit cab or boom, boom cylinders when it reached vicinity of them. 14070FW62 CLAMP-LOCKING(Item 30) This warning label is positioned on the right side window of cab.
GUIDE 1. DIRECTION Forward The direction of this manual indicate forward, backward, right and left on the standard of operator when the travel motor is in the rear and machine is on the traveling direction. Left Right Travel motor Backward 11070SG01 2.
SAFETY HINTS 1. BEFORE OPERATING THE MACHINE Think-safety first. In special situation, wear protective clothing including a safety helmet, safety shoes, gloves, safety glasses and ear protection as required by the job condition. Almost every accident is caused by disre- garding the simple and fundamental safety hints.
Page 16
Check daily according to the operation manual.Repair the damaged parts and tighten the loos-ened bolts. 13031SH05 Check for leakage of engine oil, hydraulic oil, fuel and coolant. Keep machine clean, clean machine regularly. 13031SH06 Do not operate the machine if it requires repairs. Operate after complete repair.
Page 17
UNAUTHORIZED MODIFICATION Any modification made without authorization from Hyundai can create hazards. Before making a modification, consult your Hyundai distributor. Hyundai will not be respon- sible for any injury or damage caused by any unauthorized modification. PREPARE FOR EMERGENCY Only in case of emergency, use the installed hammer for breaking the windshield of the cab, and then exit carefully.
Page 18
Do not use attachments that are not authorized by Hyundai or your Hyundai distributor. Use of unauthorized attachments could create a safety problem and adversely affect the proper opera- tion and useful life of the machine.
Page 19
SAFETY FEATURES Be sure all guards and covers are in their prop- er position. Have guards and covers repaired if damaged. Use safety features such as safety lock and seat belts properly. Never remove any safety features. Always keep them in good operating condition. Improper use of safety features could result in serious bodily injury or death.
2. DURING OPERATING THE MACHINE Use the handle and footstep when getting on or off the machine. Do not jump on or off the machine. 13031SH09 Sound the horn to warn nearby personnel before operating the machine. Remove all the obstacles like frost on the window before operating the machine for the good visibility.
Page 21
Provide proper ventilation when operating engine in a closed area to avoid the danger of exhaust gases. 13031SH13 Check the locations of underground gas pipes or water line and secure the safety before operation. 13031SH14 The operating near the electrical lines is very dangerous.
Page 22
Watch out for obstacles. Be particularly careful to check the machine clearance during the swing. 13031SH17 When using the machine as breaker or working in a place where stones may fall down, cab roof guard and head guard should be provided for proper protection.
Page 23
The operation on a slope is dangerous. Avoid operating the machine on a slope of over 10 degree. 13031SH21 Operate the machine after making ground flat when operation is required on a slope. 13031SH22 The swing on the slope can be danger of rolling over.
Page 24
Avoid traveling in a cross direction on a slope as it can cause the danger of rolling over and sliding. 13031SH25 Traveling on a slope is dangerous. Be sure to operate slowly when traveling down a slope and maintain the bucket at a height of 20~30cm(1ft) above the ground so that it can be used as brake in an emergency.
Page 25
Before traveling the machine, sound the horn to warn nearby personnel. Operate forward and backward correctly with confirming the location of the travel motor. 13031SH29 Slow down when traveling through obstacles or uneven ground. 13031SH30 When working on soft ground, place mats or wood boards on the ground to prevent the machine sinking.
Page 26
Additional track frame step can be fitted for wider optional shoe. In this case please contact your Hyundai distributor. Do not hold any control levers when getting on or off the machine.
3. DURING MAINTENANCE Stop the engine immediately when the trouble of the machine is found. Inspect immediately the cause of trouble such as vibration, overheating and trouble in the cluster then repair. 13031SH33 Park on a flat place and stop the engine for inspecting and repairing.
Page 28
There is the danger of fire in fuel and oil. Store in cool and dry area, away from any open flames. 13031SH37 Do not touch exhaust pipe, or may cause severe burn. 13031SH38 Do not open the engine hood and covers while the engine is running.
Page 29
Be careful that the front window may be promptly closed. Be sure to support stay, when the side door needs to be opened. Be careful that the open side door may closed by the external or natural force like strong wind. RD21071SH41 The antislip protection should be replaced if they have become worn or have been printed over.
4. PARKING When leaving the machine after parking, lower the bucket to the ground completely and put the safety lever at parking position then remove the key. Lock the cab door. 13031SH44 Park the machine in the flat and safe place. 13031SH45 Hope you can work easily and safely observing safety rules.
SPECIFICATIONS 1. MAJOR COMPONENT Tool box Fuel tank Hydraulic tank Main pump Engine Radiator Oil cooler Bucket Main control valve Tooth Turning joint Swing motor Arm cylinder Boom Boom cylinder Muffler Counterweight R130 Side cutter Idler Connecting link Travel motor Track roller Bucket cylinder Carrier roller...
7. UNDERCARRIAGE TRACKS X-leg type center frame is integrally welded with reinforced box-section track frames. The design includes dry tracks, lubricated rollers, idlers, sprockets, hydraulic track adjusters with shock absorbing springs and assembled track-type tractor shoes with triple grousers. TYPES OF SHOES Triple grouser Model Shapes...
8. SPECIFICATIONS FOR MAJOR COMPONENTS ENGINE Item Specification Model Kirloskar 4R1040T Type 4-cycle turbocharged diesel engine Cooling method Water cooling Number of cylinders and arrangement 4 cylinders, in-line Firing order 1-3-4-2 Combustion chamber type Direct injection type Cylinder bore stroke 105 120mm(4.13"...
Page 40
GEAR PUMP Item Specification Type Fixed displacement gear pump single stage Capacity 15cc/rev Maximum pressure 35kgf/cm (500psi) Rated oil flow 29.3 /min(7.7U.S.gpm/6.4U.K.gpm) MAIN CONTROL VALVE Item Specification Type 11 spools mono-block Operating method Hydraulic pilot system Main relief valve pressure 330kgf/cm (4695psi) Overload relief valve pressure...
Page 41
REMOTE CONTROL VALVE Item Specification Type Pressure reducing type Minimum 6.5kgf/cm (92psi) Operating pressure Maximum 26kgf/cm (370psi) Lever 61mm(2.4in) Single operation stroke Pedal 123mm(4.84in) CYLINDER Specification Item Bore dia Rod dia Stroke 70 1015mm Boom cylinder Cushion Extend only Bore dia Rod dia Stroke 75 1070mm...
9. RECOMMENDED OILS Use only oils listed below or equivalent. Do not mix different brand oil. Ambient temperature C( F) Capacity Service point Kind of fluid (U.S. gal) (-4) (14) (32) (50) (68) (86) (104) SAE 30 SAE 10W Engine Engine oil 11.50(3.04) oil pan...
CONTROL DEVICES 1. CAB DEVICES The ergonomically designed console box and suspension type seat provide the operator with comfort. ELECTRONIC MONITOR SYSTEM The centralized electronic monitor system allows the status and conditions of the machine to be monitored at a glance. It is equipped with a safety warning system for early detection of machine malfunction.
2. CLUSTER MONITOR PANEL The monitor panel consists of gauges and lamps as shown below, to warn the operator in case of abnormal machine operation or conditions for the appropriate operation and inspection. Gauges : Indicate operating status of the machine. Warning lamp : Indicate abnormality of the machine(Red).
Page 45
Monitoring display This displays the current time and machine information such as engine rpm, coolant/hydraulic oil temperature, hydraulic oil pressure and also error codes. Refer to the page 4-11 for details. 14073CD03 Fuel gauge This gauge indicates the amount of fuel in the fuel tank. Fill the fuel when the white range or warning lamp blinks.
Page 46
Fuel low level warning lamp This lamp blinks and the buzzer sounds when the level of fuel is below 28 (7.4U.S. gal). Fill the fuel immediately when the lamp blinks. 21073CD04A Hydraulic oil temperature warning lamp This warning lamp operates and the buzzer sounds when the temperature of hydraulic oil is over 102 C( 215.6 F) .
Page 47
(11) CPU controller check warning lamp Communication problem between CPU controller and cluster makes the lamp blinks and the buzzer sounds. Check if any fuse for CPU burnt off. If not check the communication line between them. 21073CD10 Battery charging warning lamp (12) This lamp blinks and the buzzer sounds when the starting switch is ON, it is turned OFF after starting the engine.
Page 48
SWITCH PANEL Work mode switch Power mode switch Travel speed switch Wiper switch Buzzer stop switch Select switch Auto Decel D11073CD19A Power mode switch This switch is to select the machine power mode, which shifts from high power work to standard power work and light power work in a raw by pressing the switch.
Page 49
This switch is used to actuate or cancel the auto deceleration (3) Auto Decel function. When the switch actuated and all control levers and pedals are at neutral position, engine speed will be lowered automatically to save fuel consumption. Light ON : Auto deceleration function is selected. Light OFF : Auto deceleration function is cancelled so that the 11073CD22 engine speed increased to previous setting value.
Page 50
CLUSTER MONITOR PANEL The monitor panel consists of gauges and lamps as shown below, to warn the operator in case of abnormal machine operation or conditions for the appropriate operation and inspection. Gauges : Indicate operating status of the machine. Warning lamp : Indicate abnormality of the machine(Red).
Page 51
2. LCD main operation display Default screen Option screen Default screen Option screen Time display RPM display Hydraulic oil temperature gauge Fuel level gauge Engine coolant temperature gauge 1607A3CD02A 1607A3CD02B Time display This displays the current time. Refer to the page 3-8-6 to set time for details. 1607A3CD02C RPM display This displays the engine rpm.
Page 52
3. Warning of main operation screen Warning display Engine coolant temperature This lamp blinks and the buzzer sounds when the temperature of coolant is over the normal temperature 105 C 221 F) . Check the cooling system when the lamp blinks.
Page 53
: LCD SYSTEM MENU Monitoring Diagnosis Management : Escape, Settings Display User Mode Return to the previous menu : Down/Left Direction : Up/Right Direction : Select(Enter) Activate the currently chosen item RD8075MS10 Main menu : Menu information : Monitoring Equipment, Switch, Output : Diagnosis Current error, Recorded error : Maintenance...
Page 55
Protocol type 2 - If there are more than 2 error codes, each one can be displayed by pressing switch respectively. - 3 error codes ( SPN200200, FMI06, SPN6789, FMI04, 345) display. No change Maintenance Setting Time set : Adjusting : Setting System lock - Reserved 3-8-6...
Page 56
Dual mode - Changing the MCU mode Display Operation skin Brightness Language 3-8-7...
Page 57
Warning and pilot lamp Engine oil pressure warning lamp This lamp blinks and the buzzer sounds after starting the engine because of the low oil pressure. If the lamp blinks during engine operation, shut OFF engine immediately. Check oil level. 21073CD07 Air cleaner warning lamp This lamp blinks and the buzzer sounds when the filter of air...
Page 58
Decel pilot lamp Operating auto decel or one touch decel makes the lamp ON. The lamp will be ON when pushing one touch decel switch on the LH RCV lever. 21073CD17 Warming up pilot lamp This lamp is turned ON when the coolant temperature is below 30 C 86 F).
Page 59
S WITCH PANEL Work mode switch Power mode switch Travel speed switch Wiper switch Buzzer stop switch Select switch Auto Deceleration switch RD8075MS11 Power mode switch This switch is to select the machine power mode, which shifts from high power work to standard power work and light power work in a raw by pressing the switch.
Page 60
(3) Auto Deceleration Switch This switch is used to actuate or cancel the auto deceleration function. When the switch actuated and all control levers and pedals are at neutral position, engine speed will be lowered automatically to save fuel consumption. 1107A3CD22 Travel speed control switch This switch is to control the travel speed which is changed...
3. SWITCHES Accel dial Beacon switch (option) Start switch Spare cover Switch Fan switch panel Spare cover Main light switch Cab light switch Spare cover Horn switch Breaker operation switch Master switch One touch decel switch RD11073CD26A STARTING SWITCH There are three positions, OFF, ON and START. (OFF) : None of electrical circuits activate.
Page 62
MASTER SWITCH This switch is used to shut off the entire electrical system. I : The battery remains connected to the electrical system. O : The battery is disconnected to the electrical system. Never turn the master switch to O(OFF) with the engine running. It could result in engine and electrical system damage.
Page 63
HORN SWITCH This switch is at the top of right side control lever. Horn switch On pressing, the horn sounds. RH RCV-lever 21073CD39 BREAKER OPERATION SWITCH On pressing this switch, the breaker operates only when the breaker Breaker selection switch on the switch panel is selected. operation switch RH RCV lever...
4. LEVERS AND PEDALS RD11073CD41A LH CONTROL LEVER This joystick is used to control the swing and the arm. Refer to operation of working device in chapter 4 for details. 21073CD42 RH CONTROL LEVER This joystick is used to control the boom and the bucket. Refer to operation of working device in chapter 4 for details.
Page 65
EMERGENCY ENGINE STARTING CONNECTOR If the CPU controller is removed, the engine does not start. Before starting the engine, connect the connector CN-92 A with B. Do not connect these connectors when the CPU is not removed. CN-92 11073CD46 SAFETY LEVER All control levers and pedals are disabled from operation by locating the lever to lock position as shown.
5. OTHERS Seat 12V socket EMERGENCY CN-47 CN-19&19B CN-19A CN-92A CN-92B Prolix resistor CN-47 CPU controller CN-19&19A Cigar lighter Emergency engine CN-19B starting connector Service meter CN-92A CN-92B RS232 serial connector Fuse box RD11073CD22A CIGAR LIGHTER This can be used when the engine starting switch is ON. The lighter can be used when it springs out in a short while after being pressed down.
Page 67
SEAT The seat is adjustable to fit the contours of the operator's body. It will reduce operator fatigue due to long work hours and enhance work efficiency. Forward/Backward adjustment Pull lever A to adjust seat forward or backward. The seat can be moved forward and backward over 140mm(5.5") in 7 steps.
Page 68
CPU CONTROLLER To match the engine torque with the pump absorption torque, CPU controller varies EPPR valve output pressure, which control pump discharge amount whenever feedbacked engine speed drops under the reference rpm of each mode set. Three LED lamps on the CPU controller display as below. L : R : 2 1 LED lamp...
Page 69
UPPER WINDSHIELD Perform the following procedure in order to open the upper windshield. Release both latches(1) in order to release the upper windshield. Hold both grips that are located at the bottom of the windshield frame and at the top of the windshield frame push the windshield upward.
Page 70
Volume button(down) Short press : Volume down one step Long press : Volume down continuous. 4507A3CD83 (4) Source & mute button Short press : Change source(Radio/CD) Long press : To mute or cancel mute. 4507A3CD84 (5) Next button Tuner mode Short press : Preset up Long press : Band up Cassette mode...
OPERATION 1. SUGGESTION FOR NEW MACHINE It takes about 100 operation hours to enhance its designed performance. Operate according to below three steps and avoid excessive operation for the initial 100 hours. Avoid excessive Service meter Load operation for initial 100 hours Until 10 hours About 60% Until 100 hours...
2. CHECK BEFORE STARTING THE ENGINE Look around the machine and under the machine to check for loosen nut or bolts, collection of dirt, or leakage of oil, fuel or coolant and check the condition of the work equipment and hydraulic system.
3. STARTING AND STOP THE ENGINE CHECK INDICATOR LIGHTS Check if all the operating lever is on the neutral position. Turn the starting switch to the ON position, and START check following. If all the lamps light ON and buzzer sounding for 2 seconds.
Page 74
STARTING ENGINE IN COLD WEATHER Sound horn to warn surroundings after checking if there are obstacles in the area. Replace the engine oil and fuel referring to recommended oils at page 2-16. Fill the anti-freeze solution to the coolant as required.
Page 75
WARMING-UP OPERATION The most suitable temperature for the hydraulic oil is about 50 C (122 F ). It can cause serious trouble in the hydraulic system by sudden operation when the hydr- aulic oil temperature is below 25 C (77 F ). Then temperature must be raised to at least 25 C (77 F ) before starting work.
4. MODE SELECTION SYSTEM STRUCTURE OF CAPO SYSTEM CAPO, Computer Aided Power Optimization system, is the name of mode selection system developed by Hyundai. Power mode 3 power modes can be selected for the optimal power of the machine operation.
Page 77
HOW TO OPERATE MODE SELECTION SYSTEM When start key is turned ON Monitoring display When start key is turned ON, all illumination lamps are ON and all lamps are OFF automatically after 5 seconds. But the battery charging warning lamp and the engine oil pressure warning lamp keep turned ON until engine starting.
Page 78
SELECTION OF POWER MODE S mode (Standard power) When the accel dial is at setting 10 and one touch decel mode is cancelled and S mode is selected. When the accel dial is located below 9 the engine speed decreases about 50~100rpm per dial set.
Page 79
MONITORING DISPLAY Information of machine performance as monitored by the CPU controller can be displayed on the cluster when the operator selects a display mode by touching switch alone or with SELECT switch on the cluster as below. BUZZER STOP How to select display mode Display group Name...
Page 80
5. OPERATION OF WORKING DEVICE Confirm the operation of control lever and working device. Left control lever controls arm and swing. Right control lever controls boom and bucket. When you release the control lever, control lever returns to neutral position automatically. When operating swing, consider the swing distance by inertia.
6. TRAVELING OF THE MACHINE BASIC OPERATION Travelling position Traveling position It is the position which the traveling motor is in the rear and the working device is forward. Be careful as the traveling direction will be reversed when the whole machine is swinged 180 degree Traveling operation It is possible to travel by either travel lever or...
Page 82
TRAVELING ON A SLOPE Make sure that the travel lever is properly maneuvered by confirming the travel motor is in the right location. Lower the bucket 20 to 30cm(1ft) to the ground so that it can be used as a brake in an emergency.
Page 83
TOWING THE MACHINE Tow the machine as follows when it can not move on it's own. Tow the machine by other machine after hook the wire rope to the frame as shown in picture at right. Hook the wire rope to the frame and put a support under each part of wire rope to prevent damage.
7. EFFICIENT WORKING METHOD Do the digging work by arm. Use the pulling force of arm for digging and use together with the digging force of the bucket if necessary. D11074OP28 When lowering and raising the boom operate Operate softly for the beginning and the end softly for the beginning and the end.
Page 85
Dig slowly with keeping the angle of boom and arm, 90-110 degree when maximum digging force is required. 90~110 D11074OP30 Operate leaving a small safety margin of cylinder Margin stroke to prevent damage of cylinder when working with the machine. D11074OP31 Keep the bucket to the dumping position and the arm horizontal when dumping the soil from the...
Page 86
Never carry out operations which may damage the machine such as overload or over-impact- load. Never travel while carrying a load. In case you need installing over load warning device for object handling procedure, please Incorrect contact Hyundai distributor. 29074OP35 4-18...
Page 87
BUCKET WITH HOOK When carrying out lifting work, the special lifting hook is necessary. The following operations are prohibited. Hook Lifting loads with a wire rope fitted around the bucket teeth. Lifting loads with the wire rope wrapped directly around the boom or arm. When performing lifting operation, securely hook the wire rope onto the special lifting hook.
8. OPERATION IN THE SPECIAL WORK SITES OPERATION THE MACHINE IN A COLD WEATHER Use proper engine oil and fuel for the weather. Fill the required amount of antifreeze in the coolant. Refer to the starting engine in cold weather. Start the engine and extend the warming up operation.
Page 89
SEA SHORE OPERATION Prevent ingress of salt by securely tightening plugs, cocks and bolts of each part. Wash machine after operation to remove salt residue. Pay special attention to electrical parts and hydraulic cylinders to prevent corrosion. Inspection and lubrication must be carried out more frequently.
9. NORMAL OPERATION OF EXCAVATOR Followings may occur during operation due to the nature of a hydraulic excavator. When rolling in the arm, the roll-in movement stop momentary at point X in the picture shown, then recovers speed again after passing point X. The reason for this phenomenon is that movement by the arm weight is faster than the speed of oil flow into the cylinder.
10. STORAGE Maintain the machine taking care of following to prevent the deterioration of machine when storing the machine for a long time, over 1 month. BEFORE STORAGE CLEANING THE MACHINE Clean the machine. Check and adjust tracks. Grease each lubrication part. LUBRICATION POSITION OF EACH PART Change all oil.
Page 92
Refer to the service instruction, section 6 for the drain plug location. If the machine is stored without carrying out the monthly lubricating operation, consult your Hyundai dealer for service. 4-24...
From ISO Type Arm out Arm in Left Swing right Swing left Boom lower Boom raise Right Bucket out Hyundai Bucket in A Type Boom lower Boom raise Left Swing right Swing left Arm out Arm in Right Bucket out...
12. SWITCHING HYDRAULIC ATTACHMENT CIRCUIT(OPTION) The combined hydraulic attachment circuit is capable of providing single action or double action. The position of 3 way valve selects the single action hydraulic attachment circuit or the double action hydraulic attachment circuit. Before you change the flow mode of hydraulic attachment circuit, place the machine in the servicing position as shown.
TRANSPORTATION 1. PREPARATION FOR TRANSPORTATION When transporting the machine, observe the various road rules, road transportation vehicle Overall laws and vehicle limit ordinances, etc. width Select proper trailer after confirming the weight and dimension from the chapter 2, specification. Check the whole route such as the road width, the height of bridge and limit of weight and etc., which will be passed.
3. LOADING THE MACHINE Load and unload the machine on a flat ground. Use the gangplank with sufficient length, width, thickness and gradient. Place the swing lock lever to the LOCK position before fixing the machine at the bed of trailer and confirm if the machine parallels the bed of trailer.
Page 99
Lower the working equipment gently after the location is determined. Place rectangular timber under the bucket cylinder to prevent the damage of it during transportation. Be sure to keep the travel speed switch on the LOW(turtle mark) while loading and unloading the machine.
4. FIXING THE MACHINE Place the swing lock lever on the LOCK position. Lower down the working device on the loading plate of trailer. Keep the safety lever on the LOCK position. Turn OFF all the switches and remove the key. 11075TA09 Secure all locks.
5. LOADING AND UNLOADING BY CRANE Check the weight, length, width and height of the machine referring to the chapter 2, specification when you are going to hoist the machine. Wire rope Stay Use long wire rope and stay to keep the distance with the machine as it should avoid touching with the machine.
Do not allow unauthorized personnel to reset them. Ask to your local dealer or Hyundai for the maintenance advice if unknown. Drain the used oil and coolant in a container and handle according to the method of handling for industrial waste to meet with regulations of each province or country.
Page 103
Confirm if the cluster is in the normal condition after completion of service. For more detail information of maintenance, please contact local Hyundai dealer. Be sure to start the maintenance after fully understand the chapter 1, safety hints.
Page 104
RELIEVING THE PRESSURE IN THE HYDRAULIC SYSTEM Spouting of oil can cause the accident when loosening the cap or hose right after the operating of machine as the machine or oil is on the high pressure on the condition. Be sure to relieve the pressure in the system before repairing hydraulic system.
Page 105
PRECAUTION WHEN INSTALLING HYDRAULIC HOSES OR PIPES Be particularly careful that the joint of hose, pipe and functioning item are not damaged. Avoid contamination. Assemble after cleaning the hose, pipe and joint of functioning item. Use genuine parts. Do not assemble the hose in the condition of twisted or sharp radius.
Swing and travel reduction gear SAE 85W-140(API GL-5) Grease Lithium base grease NLGI No. 2 Fuel ASTM D975-No. 2 Coolant Hyundai pre mixed coolant Society of Automotive Engineers American Petroleum Institute International Organization for Standardization NLGI National Lubricating Grease Institute ASTM...
Page 108
RECOMMENDED OILS Use only oils listed below or equivalent. Do not mix different brand oil. Ambient temperature C( F) Capacity Service point Kind of fluid (U.S. gal) (-4) (14) (32) (50) (68) (86) (104) SAE 30 SAE 10W Engine Engine oil 11.50(3.04) oil pan SAE 10W-30...
Page 111
EVERY 250 HOURS SERVICE Check items Service Page Battery (Electrolyte, voltage) Check, Add 6-38 Hydraulic oil return filter Replace 6-29 Drain filter cartridge Replace 6-30 Swing reduction gear oil Change 6-31 Swing reduction gear grease Check, Add 6-31 Replace Swing reduction gear case 6-30 Pilot line filter Replace...
Page 112
7) EVERY 1000 HOURS SERVICE Check items Service Page Travel motor reduction gear oil Change 6-32 Swing reduction gear oil Change 6-31 Swing reduction grease Refill 6-31 Grease in swing gear and pinion Change 6-32 Pilot line filter Replace 6-30 Hydraulic return filter Replace 6-29...
Page 113
WHEN REQUIRED Whenever you have trouble in the machine, you must perform the service of related items, system by system. Check items Service Page Fuel system Fuel tank Drain or Clean 6-25 Water separator Drain or Replace 6-26 Fuel filter element Replace 6-26 Engine lubrication system...
5. MAINTENANCE CHART R130 D11076MI25 Caution 1. Service intervals are based on the hour meter reading. 2. The number of each item shows the lubrication point on the machine. 3. Stop engine while filling oil, and use no open flames. 4.
Page 115
Service Service Capacity Service Description interval action symbol (U.S.gal) points No. Hydraulic oil level Check, Add 100(26.4) Engine oil level Check, Add 11.50(3.04) 10 Hours Radiator coolant Check, Add 20(5.2) or daily Fuel filter & water separator Check, Drain Fan belt tension and damage Check, Adjust Attachment pins and chamber Check, Add...
6. SERVICE INSTRUCTION CHECK ENGINE OIL LEVEL Check the oil level with the machine on a flat ground before starting engine. Pull out the dipstick and wipe with a clean cloth. Check the oil level by inserting the dipstick completely into the hole and pulling out again. If oil level is LOW, add oil and then check again.
Page 117
Apply a light film of lubricating oil to the gasket sealing surface before installing the filters. Fill the filters with clean lubricating oil. 25036MI09 Install the filter to the filter head. Mechanical over-tightening may distort the threads or damage the filter element seal. Install the filter as specified by the filter manufacturer.
Page 118
CHECK COOLANT Check if the level of coolant in reservoir tank is between FULL and LOW. Add the mixture of antifreeze and water after removing the cap of the reservoir tank if coolant is not sufficient. Be sure to add the coolant by opening the cap of radiator when coolant level is below LOW.
Page 119
Wait until the temperature is below 50 C (122 F ) before removing the coolant system pressure cap. Failure to do so can cause personal injury from heated coolant spray. Drain the cooling system by opening the drain valve on the radiator and removing the plug in the bottom of the water inlet.
Page 120
Operate the engine for 5 minutes with the coolant temperature above 80 C(176 F) . Shut the engine off, and drain the cooling system. If the water being drained is still dirty, the system must be flushed again until the water START is clean.
Page 121
CLEAN RADIATOR AND OIL COOLER NOT OK Check, and if necessary, clean and dry outside of radiator and oil cooler. After working in a dusty place, clean radiator more frequently. Visually inspect the radiator for clogged radiator fins. Use 550kPa(80psi) air pressure to blow the dirt 550kPa and debris from the fins.
Page 122
FAN BELT TENSION Measure the belt deflection at the longest span of the belt. Maximum deflection : 12mm(0.5in) D11076MI08 Inspect the drive for damage. NOT OK 13036MI03 Inspect the drive belt, tension bearing and fan hub. D11076MI63 INSPECTION OF COOLING FAN Personal injury can result from a fan blade failure.
Page 123
CLEANING OF AIR CLEANER Primary element Loosen the latch and remove the element. Clean the inside of the body. Clean the element either with pressurized air or washing. Using pressurized air Remove the dust inside of the element by Pressurized air 3kg/cm below the pressurized air(below 3kgf/cm , 40psi)
Page 124
WATER SEPARATOR Drain the water and sediment by loosening the Water separator drain plug. Sediment Retighten the drain plug. Check for leakage. Bleed the air if the air is mingled on the fuel line when draining water. D11076MI62A REPLACEMENT OF FUEL FILTER Clean around the filter head, remove the filter with a filter wrench and clean the gasket surface.
Page 125
BLEEDING THE FUEL SYSTEM Loosen air vent plug 1(Approximately 1.5 turns). Unlock priming pump plunger 2 and operate the pump. When the fuel flows free of air bubbles, lock the priming pump, then tighten the plug. If the vent plug is dosed before the priming pump plunger is locked, fuel pressure acts on the feed pump, resulting in inability to restore the plunger.
Page 126
FILLING HYDRAULIC OIL Stop the engine to the position of level check. Loosen the cap and relieve the pressure in the tank by pushing the top of the air breather. Remove the breather on the top of oil tank and fill the oil to the specified level.
Page 127
CLEAN SUCTION STRAINER Clean suction strainer as follows paying attention Air breather to the cause to be kept during oil filling. Cover Remove the cover on the top of the oil tank. O-ring Tightening torque : 6.9 1.4kgf m (50 10lbf ft) Pull out the strainer in the tank.
Page 128
REPLACEMENT OF ELEMENT IN HYDRAU- LIC TANK BREATHER Loosen the cap and relieve the pressure in the tank by pushing the top of the air breather. Cover Loosen the lock nut and remove the cover. Element Pull out the filter element. Replace the filter element new one.
Page 129
CHECK THE SWING REDUCTION GEAR OIL Pull out the dipstick and clean it. Insert it again. Pull out one more time to check the oil level and fill the oil if the level is not sufficient. 11076MI17 CHANGE SWING REDUCTION GEAR OIL Raise the temperature of oil by swinging the Filling port machine before replace the oil and park the...
Page 130
SWING GEAR AND PINION Filler cover Drain old grease Remove under cover of lower frame. Remove drain cover of lower frame. Remove filler cover of upper frame. Operate full turn(360 ) of swing several times. Front of upper frame 13036MI08 Refill new grease Install drain cover.
Page 131
LUBRICATE RCV LEVER Remove the bellows and with a grease gun grease the joint part(A) and sliding parts(B). 36076MA25 ADJUSTMENT OF TRACK TENSION It is important to adjust the tension of track properly to extend the lifetime of track and 90 ~ 110 traveling device.
Page 132
REPLACEMENT OF BUCKET When knocking the pin in with a hammer, metal particles may fly and cause serious injury, particularly if they get into your eyes. When carrying out this operation, always wear goggles, helmet, gloves, and other protective equipment. When the bucket is removed, place it in a stable condition.
Page 133
REPLACEMENT OF BUCKET TOOTH Timing of replacement Check wearing condition as shown in the illustration and replace tooth tip before adapter starts to wear. If excessive use, tooth adapter has worn out, replacement may become impossible. Instructions for replacement 11076MI26 Pull out pin by striking pin with punch or hammer, avoiding damage to locking washer.
Page 134
LUBRICATE PIN AND BUSHING Lubricate to each pin of working device Lubricate the grease to the grease nipple according to the lubricating interval. Description Lubrication manifold at boom Boom cylinder pin Boom and arm connection pin Arm cylinder pin(Rod side) Bucket cylinder pin(Head, rod) Bucket link(Control rod) Arm and bucket connection pin...
7. ELECTRICAL SYSTEM WIRING, GAUGES Check regularly and repair loose or malfunctioning gauges when found. 13036MI29 BATTERY Check and repair Check the electrolyte level and fill with distilled water to the prescribed level as necessary. Plug Wash the terminal with hot water if it is contaminated, and apply grease to the Upper level terminals after washing.
Page 136
STARTING THE ENGINE WITH A BOOSTER CABLE Keep following order when you are going to start engine using booster cable. Connection of booster cable Connection of booster cable Use the same capacity of battery for starting. Make sure that the starting switches of the normal machine and trouble machine are both at the OFF position.
Page 137
Welding repair Before start to welding, follow the below procedure. Shut off the engine and remove the starting switch. Disconnect ground cable from battery by master switch. Before carrying out any electric welding on the C -7 machine, the battery cables should be -3 2 L :R :2 1...
TROUBLESHOOTING GUIDE 1. ENGINE This guide is not intended to cover every conditions, however many of the more common possibilities are listed. Trouble Service Remark The engine oil pressure lamp Add the oil to the specified level. lights ON when engine speed is Replace the oil filter cartridge.
2. ELECTRICAL SYSTEM Trouble Service Remark Lamp does not glow brightly even Check for loose terminals and open-circuit wiring. when engine runs at high speed. Adjust belt tension. Lamp flickers while engine runs. Battery charging lamp does not Check the alternator. go out even when engine runs at Check and repair wiring.
3. OTHERS Trouble Service Remark Track slip out of place. Adjust tension of track. Excessive wear of the sprocket. Bucket either rises slowly or not at Add oil to specified level. all. Slow speed of travel, swing, Add oil to specified level. boom, arm and bucket.
One of spool of the main control valve should be connected to the tank. Select the size of pipe laying considering the back pressure. Seamless tube should be used for the piping. The hose and seal should be used Hyundai genuine parts.
3. MAINTENANCE MAINTENANCE OF HYDRAULIC OIL AND FILTER Service interval unit : hours As machine with an hydraulic breaker provides Operating Hydraulic Filter Attachment hydraulic becomes severely rate element contaminated. 100% 2,000 Bucket So, unless frequently maintained, the machine Breaker 100% may easily go out of order.
4. PRECAUTIONS WHILE OPERATING THE BREAKER DO NOT BREAK ROCK WHILE LOWERING Incorrect As the breaker is heavy in comparison with bucket, it must be operated slowly. If breaker is rapidly pushed down, working device may be damaged. D11078BO02 DO NOT USE BREAKER TO CARRY BROKEN Incorrect STONE OR ROCK BY SWING OPERATING This may damage the operation device and swing...
Page 144
DO NOT CONTINUE TO WORKING OVER Incorrect ONE MINUTE AT SAME POSITION OF For one BOOM AND ARM minute This will increase the temperature of the oil, and cause problem in the accumulator and seals. D11078BO06 DO NOT MOVE MACHINE OR BREAKER Incorrect WHILE STRIKING Do not move hammer while striking.
5. QUICK CLAMP FIXING BUCKET WITH QUICK CLAMP Quick clamp switch Before fixing bucket, remove safety pin of the moving hook. Safety button Pulling safety button, press the quick clamp switch to unlock position. Then, the moving hook is placed on release position. Safety pin quick-1 Aligning the arm and bucket, insert static...
Page 146
Be careful to operate the machine equipped with quick clamp. The bucket may hit cab, boom and boom cylinders when it reaches vicinity of them. HYUNDAI will not be responsible for any injury or damage in case that safety pin is not installed properly. q-safety...
