Hyundai R80CR-9 Manual

Table of Contents

Advertisement

Quick Links

Download this manual

Foreword ---------------------------------------------------------

Before servicing this machine -------------------------- 0-2

EC regulation approved ----------------------------------- 0-3

Table to enter S/No and distribution ---------------------- 0-4

Safety labels ---------------------------------------------------- 0-5

Machine data plate ------------------------------------------- 0-14

Guide (direction, S/No, Symbol) ----------------------- 0-15

1. SAFETY HINTS

1. Before operating the machine -------------------- 1-1

2. During operating the machine -------------------- 1-16

3. During maintenance ---------------------------------- 1-23

4. Parking -----------------------------------------------------

2. SPECIFICATIONS

1. Major components ------------------------------------ 2-1

2. Specifications -------------------------------------------- 2-2

3. Working range ------------------------------------------- 2-3

4. Weight ------------------------------------------------------

5. Lifting capacities ---------------------------------------- 2-5

6. Bucket selection guide ------------------------------- 2-6

7. Undercarriage ------------------------------------------- 2-7

8. Specification for major components ----------- 2-8

9. Recommended oils ----------------------------------- 2-11

3. CONTROL DEVICES

1. Cab devices ---------------------------------------------- 3-1

2. Cluster ------------------------------------------------------

3. Switches --------------------------------------------------- 3-13

4. Levers and pedals ------------------------------------- 3-17

5. Air conditioner and heater -------------------------- 3-19

6. Others ------------------------------------------------------- 3-23

1. Suggestion for new machine --------------------- 4-1

2. Check before starting the engine --------------- 4-2

3. Starting and stop the engine ---------------------- 4-3

4. Operation of the working device ----------------- 4-7

5. Traveling of the machine ---------------------------- 4-8

0-1

6. Efficient working method ------------------------------- 4-11

7. Operation in the special work sites ------------- 4-15

8. Normal operation of excavator ------------------- 4-17

9. Attachment lowering ----------------------------------- 4-18

10. Storage -------------------------------------------------- --- 4-19

11. RCV lever operating pattern ---------------------- 4-21

5. TRANSPORTATION

1. Preparation for transportation -------------------- 5-1

2. Dimension and weight ------------------------------- 5-2

3. Loading the machine --------------------------------- 5-4

4. Fixing the machine ------------------------------------ 5-6

1-26

5. Loading and unloading by crane ------------------- 5-7

1. Instruction ------------------------------------------------- 6-1

2. Tightening torque -------------------------------------- 6-6

3. Fuel, coolant and lubricants ----------------------- 6-9

2-4

4. Maintenance check list ------------------------------ 6-11

5. Maintenance chart ------------------------------------ 6-16

6. Service instruction ------------------------------------- 6-18

7. Electrical system --------------------------------------- 6-37

8. Air conditioner and heater -------------------------- 6-40

7. TROUBLESHOOTING GUIDE

1. Engine -------------------------------------------------- ----

2. Electrical system --------------------------------------- 7-2

3-2

3 Others -------------------------------------------------------- 7-3

8. HYDRAULIC BREAKER

1. Selecting hydraulic breaker ------------------------ 8-1

2. Circuit configuration ----------------------------------- 8-2

3. Maintenance --------------------------------------------- 8-3

4. Precaution when operating the breaker ------ 8-4

5. Quick clamp ---------------------------------------------- 8-6

CONTENTS

7-1

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the R80CR-9 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hyundai R80CR-9

Page 1: Table Of Contents
CONTENTS Foreword --------------------------------------------------------- 6. Efficient working method ------------------------------- 4-11 Before servicing this machine -------------------------- 0-2 7. Operation in the special work sites ------------- 4-15 EC regulation approved ----------------------------------- 0-3 8. Normal operation of excavator ------------------- 4-17 Table to enter S/No and distribution ---------------------- 0-4 9.
