Heartland VALUE Series Assembly Manual

Classic 12' x 10' 365,8 x 304,8 cm
Hide thumbs Also See for VALUE Series:

Advertisement

Quick Links

Download this manual
For questions on assembly or for general inquiries, you may contact us in the following ways:
Call a Recruiter Today! 734-365-7000
Flexible schedule
*based on number of completed installations
Call Us First!
DO NOT RETURN TO STORE.
Call customer service: 1-877-743-3400
AVOID THE WAIT!
visit us online at
help.backyardproducts.com
Submit a help request
Answers to frequently asked questions
Live chat with an agent
Did you enjoy building your shed?
JOIN OUR TEAM
AND MAKE UP TO $1,500/WEEK*
No selling,
just building
Bonus incentives
available
16615-G

Advertisement

loading

Related Manuals for Heartland VALUE Series

Summary of Contents for Heartland VALUE Series

  • Page 1 16615-G Call Us First! DO NOT RETURN TO STORE. For questions on assembly or for general inquiries, you may contact us in the following ways: Call customer service: 1-877-743-3400 AVOID THE WAIT! visit us online at help.backyardproducts.com Submit a help request Answers to frequently asked questions Live chat with an agent Did you enjoy building your shed?
  • Page 2 Win $500 A new winner is selected every 2 months. Review your product for the chance to win a $500 Visa Gift Card. Open camera. How to Enter: Aim. Tap. Scan Click Find your product. Submit your review. QR code above. ‘write a review’...

  • Page 3: Assembly Manual

    16615-G 06-09-2022 ASSEMBLY MANUAL VALUE SERIES CLASSIC 12' x 10' (365,8 x 304,8 cm) ACTUAL FLOOR SIZE 12' x 10' (365,8 x 304,8 cm) KEEP THIS MANUAL FOR FUTURE REFERENCE 12' x 10' IMPORTA NT ! READ INSTRUCTIONS THOROUGHLY PRIOR TO BEGINNING ASSEMBLY.
  • Page 4 TOOLS Required Optional K Phillips K Tool Belt/ K Utility Knife Screwdriver Nail Pouch K Shingle Blades K Drill / Driver K Tin Snips K 3/8" Drill Bit K Caulk Gun (for drip edge) K #2 Philips Drive Bit K Chalk Line K Hammer K Paint Tools K Level...

  • Page 5: Additional Materials

    ADDITIONAL MATERIALS FOUNDATION OR FLOOR MATERIALS • If you purchased a separate floor kit, use instructions and materials in that kit to construct your floor. • See the FLOOR LEVELING section on page 10 for recommended methods and suggested materials to properly level your floor, as this will vary depending on your specific site.

  • Page 6: Optional Materials

    ADDITIONAL MATERIALS COMPLETING YOUR SHED You will need these additional materials: 3-TAB SHINGLES (Bundles)..... 6 PAINT FOR TRIM ......1 Quart Use 100% acrylic latex exterior paint. CAULK ........3 Tubes PAINT FOR SIDING (Gallons)....3 Use acrylic latex exterior caulk that is paintable. Use 100% acrylic latex exterior paint.
  • Page 7 PARTS IDENTIFICATION AND SIZES WOOD SIZE CONVERSION CHART Double letter part identification Nominal Board Size Actual Size is stamped on some parts. 2 x 4 ....1-1/2" x 3-1/2" (3,8 x 8,9 cm) 1 x 4 ....3/4" x 3-1/2" (1,9 x 8,9 cm) •...
  • Page 8 PANEL & DOORS PARTS NOTE: Panel parts are not stamped with part identification. 3/8 x 48 x 84" 3/8 x 48 x 84" 3/8 x 23-7/8 x 84" (1 x 121,9 x 213,4 cm) (1 x 121,9 x 213,4 cm) (1 x 121,9 x 213,4 cm) 3/8"...
  • Page 9 SHELVING PARTS Shelf panels are 7/16" (1,1 cm) thick. 2 x 3 x 10" 1 x 3 x 23-78" 1 x 3 x 96" (2,5 x 7,6 x 243,9 cm) (5,1 x 7,6 x 25,4 cm) (2,5 x 7,6 x 60,6 cm) 1 x 4 x 23-78"...
  • Page 10 NAIL BOXES (Shown Actual Size) BOXES 3" (7,6 cm) BOXES 2" (5,1 cm) WINDOW AND TRIM PARTS 19/32" x 3" x 8-1/2" (1,5 x 7,6 x 21,6 cm) 19/32" x 3" x 21" (1,5 x 7,6 x 53,3 cm) 19/32" x 2-1/2" x 26-5/8" (1,5 x 7,6 x 67,6 cm) 19/32"...
  • Page 11 CONCRETE FOUNDATION If you choose to install your kit on a concrete slab refer to the diagram below. Attach the sill plates on the foundaton as shown, and continue on to page 13. Treated Sill Plate Caulk between sill plate and concrete.
  • Page 12 OPTIONAL WOOD FRAME FLOOR LEVELING OPTIONS There are multiple ways to level your floor frame. Our recommended leveling method is shown below. Leveling materials are not included in this kit. PREFERRED METHOD - 4x4 TREATED RUNNERS (Typical for 10' x 12' Kit) Runners are generally 12"...
  • Page 13 LEVELING & SQUARING THE FLOOR FRAME (Not Included) LEVEL AND SQUARE FLOOR FRAME Before attaching fl oor decking, it is important to level and square the fl oor frame. A level and square fl oor frame is required to correctly construct your shed. See page 10 for the preferred f oor leveling method.
  • Page 14 IMPORTANT! I M P O R T A N T ! Ensure the foor frame is level after installing foor panels. Re-level if needed. • The foor should used as a stable work surface for wall construction. • Organize your assembly procedure during the build process to avoid over-handling of the walls.

  • Page 15: Parts Required

    DOOR HEADER Assemble this door header before building any walls! Any wall with a door will require this assembly. PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 67" (5,1 x 10,2 x 170,2 cm) 7/16 x 3-1/4 x 66-3/4" (1,1 x 8,3 x 170,2 cm) BEGIN Place (1) AM and OSB end-to-end on fl at surface, fl ush in middle.
  • Page 16 WALL PANEL INSTALLATION HINTS & EXAMPLES PARTS REQUIRED: 2" (5,1 cm) 2x3" TEMP. SPACER 3/4" GAUGE BLOCK 3/8 x 48 x 84" (1 x 121,9 x 213,4 cm ) Ensure your wall is square by installing one panel and squaring frame. Install all wall panels with the primed side facing up.
  • Page 17 12' FRONT WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 7" (5,1 x 10,2 x 17,8 cm) Pre Assembled Header 3" (7,6 cm) 2 x 4 x 34" (5,1 x 10,2 x 86,4 cm) x1 SG 2 x 4 x 60-1/2" (5,1 x 10,2 x 153,7 cm) x1 BG 2 x 4 x 68"...
  • Page 18 12' FRONT WALL PARTS REQUIRED: 3" (7,6 cm) x150 2" (5,1 cm) Temporary Brace 48 x 84" (121,9 x 213,4 cm ) 69" (175,3 cm) Door Stiffener 1-1/2" Flush (3,8 cm) 3/4" Install the left door panel BEGIN HERE (1,9 cm) on wall frame, 1-1/2"...
  • Page 19 10' GABLE WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 24" (5,1 x 10,2 x 61 cm) 2 x 4 x 78-1/2" (5,1 x 10,2 x 199,4 cm) 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) Build (2) identical 10' gable walls.
  • Page 20 10' GABLE WALL PARTS REQUIRED: x136 2" (5,1 cm) 48 x 84" 23-7/8" x 84" (121,9 x 213,4 cm ) (60,6 x 213,4 cm ) 1-1/2" (3,8 cm) 3/4" BEGIN HERE (1,9 cm) Install 48" x 84" panel 1-1/2" from the top plate. Use a 2x3 spacer for consistent measurement.
  • Page 21 12' BACK WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 44-3/8" (5,1 x 10,2 x 112,7 cm) 2 x 4 x 92-5/8" (5,1 x 10,2 x 235,3 cm) 2 x 4 x 68-1/2" (5,1 x 10,2 x 174 cm) 2 x 4 x 78-1/2"...
  • Page 22 12' BACK WALL PARTS REQUIRED: x120 2" (5,1 cm) 48 x 84" (121,9 x 213,4 cm ) 3/4" BEGIN HERE (1,9 cm) 3-1/2" Install 48" x 84" panel (8,9 cm) 1-1/2" from the top plate. 1-1/2" (3,8 cm) Use a 2x3 spacer for consistent measurement.
  • Page 23 STANDING YOUR WALLS The following steps show how to stand and secure your walls for a 10' x 12' shed.
  • Page 24 10' WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 69" (175,3 cm) Door Stiffener 3" (7,6 cm) 2" (5,1 cm) BEGIN 1-1/2" (3,8 cm) Center 10' wall on the 120" (304,8 cm) fl oor dimension. 1-1/2" (3,8 cm) overlap is to the top. Use OO as a temporary brace.
  • Page 25 12' WALL INSTALLATION PARTS REQUIRED 2" (5,1 cm) 3" (7,6 cm) 2" (5,1 cm) 1-1/2" (3,8 cm) 3" (7,6 cm) BEGIN Fig. B Place 12' wall centered on fl oor. 1-1/2" (3,8 cm) overlap is to the top. 2" (5,1 cm) Secure wall with (1) 2"...
  • Page 26 2nd 10' WALL INSTALLATION PARTS REQUIRED: 2" (5,1 cm) 3" (7,6 cm) 2" (5,1 cm) 3" (7,6 cm) 1-1/2" (3,8 cm) 1-1/2" (3,8 cm) Fig. B BEGIN Place 2nd 10' wall centered on fl oor. 1-1/2" (3,8 cm) overlap is to the top. 2"...
  • Page 27 12' DOOR WALL INSTALLATION PARTS REQUIRED 2" (5,1 cm) 3" (7,6 cm) 2" (5,1 cm) 3" (7,6 cm) 1-1/2" (3,8 cm) Fig. B BEGIN Place 12' wall on fl oor centered between 10' walls. 2" (5,1 cm) Screw Secure wall with 2" screws into top and bottom plates (Fig.
  • Page 28 10' x 12' WALL DOUBLERS INSTALLATION PARTS REQUIRED: 3" (7,6 cm) x2 JBD 2 x 4 x 20-3/8" (5,1 x 10,2 x 51,8 cm) 2 x 4 x 48" (5,1 x 10,2 x 121,9 cm) 3" (7,6 cm) 2 x 4 x 92-5/8" (5,1 x 10,2 x 235 cm) 2 x 4 x 96"...
  • Page 29 RAFTERS PARTS REQUIRED: x144 2" (5,1 cm) 6 x 24" (15,2 x 60,9 cm) 2 x 4 x 65" (5,1 x 10,2 x 165,1 cm) Temporary Support 69" (175,3 cm) Door Stiffener Build (2) rafter assemblies with (1) gusset (Fig. B). BEGIN Place (2) rafter-halves AD in the corner of back and side walls, fl ush to panels and studs.
  • Page 30 RAFTER INSTALLATION PARTS REQUIRED: 3" (7,6 cm) Two-Gusset Preassembled One-Gusset Preassembled BEGIN Align rafters over the wall studs. Check that you have the measurements shown. Secure rafters with (2) 3" screws angled at each end (Fig. A, Fig. B). Secure rafters on opposite side. Maintain the measurements between rafters.
  • Page 31 GABLE UNITS PARTS REQUIRED: 1-1/2" (3,8cm) 2 x 4 x 18-1/8" (5,1 x 10,2 x 46 cm) Install gable panels with the primed side facing up. BEGIN Orient parts AF on the flat side, as shown. Measure and mark the center of the middle gable panel. Secure with 1-1/2" nails spaced 6" apart along edge. 1-1/2"...
  • Page 32 GABLE INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) Pre - assembled BEGIN Measure 2-1/2" down from top plate doubler and mark at each side as shown. Set gable unit on top plate. Fasten with (1) 2" nail on each side. BE SURE GABLE IS CENTERED ON WALL BEFORE NAILING.
  • Page 33 10' x 12' ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 7/16 x 48 x 96" (1,1 x 121,9 x 243,8 cm) Roof panels may cause serious injury until securely fastened. Note: Install all roof panels with the rough side up (painted grid lines). BEGIN Place the 48"...
  • Page 34 10' x 12' ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 7/16 x 48 x 96" (1,1 x 121,9 x 243,8 cm) Install a 48" x 47-7/8" roof panel flush to the Flush at installed panel and flush at peak (Fig. B). peak Fig.
  • Page 35 10' x 12' ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 23-1/2" x 47-7/8" (59,7 x 121,9 cm) 3/4" GAUGE BLOCK 23-1/2" x 96" (59,7 x 243,8 cm) Install 23-7/8" x 48" and 13-7/8" x 96" roof panels with a 3/4" measurement on the rafter (Fig A) and flush to the installed panels.
  • Page 36 10' x 12' ROOF PANELS PARTS REQUIRED: x136 2" (5,1 cm) Secure all roof panels with 2" nails spaced 6" apart and 12" apart inside of the 48" wide panels. 6" (15,2 cm) Repeat STEPS to install roof panels on the opposite side. FINISH Your roof panels are now installed.
  • Page 37 GABLE TRIM PARTS REQUIRED: 2" (5,1 cm) 19/32" x 3-1/2" x 71-15/16" (1,5 x 8,9 x 182,7 cm) 19/32" x 3-1/2" x 71-15/16" (1,5 x 8,9 x 182,7 cm) BEGIN Install front gable trim AUR and AUL fl ush to top of roof panel and fl ush at peak, as shown (Fig. A). Secure trim with 2"...
  • Page 38 10' x 12' EAVE TRIM PARTS REQUIRED: 1-1/4" (3,2 cm) 3" (7,6 cm) 2 x 6 x 49-3/4" (5,1 x 15,2 x 126,4 cm) 2 x 6 x 96" (5,1 x 15,2 x 243,8 cm) BEGIN Place VX eave trim fl ush along edge of roof panel (Fig. A). Screw through roof panel into VX with 1-1/4"...
  • Page 39 CORNER TRIM PARTS REQUIRED: 2" (5,1 cm) 3/8" x 1-3/4" x 83-1/2" (1 x 4,5 x 212,1 cm) BEGIN Install gable end 83-1/2" corner trim under gable panel, (Fig. A) and fl ush to eave wall panel (Fig. B). Secure with 2" fi nishing nails spaced evenly. Install eave side 83-1/2"...
  • Page 40 LOFT JOIST ASSEMBLY PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 24" (5,1 x 10,2 x 61 cm) 7/16" (11 mm) Drill Bit 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) ¸ BEGIN Orient parts TP and RL on a fl at surface. Hold parts TP and RL fl ush and aligned.
  • Page 41 LOFT SUPPORTS PARTS REQUIRED: 3" (7,6 cm) x2 AO x1 PYA 5/16" (7,9 mm) Drill Bit 2 x 4 x 22-1/2" 2 x 4 x 19-3/4" (5,1 x 10,2 x 57,1 cm) (5,1 x 10,2 x 50,2 cm) 3" (7,6 cm) x1 LW 2 x 3 x 23-7/8”...
  • Page 42 LOFT JOISTS PARTS REQUIRED: 3" (7,6 cm) 3" (7,6 cm) LOFT JOIST ASSEMBLY 5/16" (7,9 mm) Drill Bit ¸ BEGIN Lift and position the front loft joist on loft supports, fl ush to window frame stud (Fig. C) and at the measurement shown at back wall (Fig.
  • Page 43 WORKBENCH PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) 2 x 3 x 19" 14-1/4 x 22-1/4” (5,1 x 7,6 x 48,3 cm) (36 x 56,5 cm) BEGIN Assemble (5) workbench brackets. Install brackets flush to end of LR. Secure brackets to LR with (4) 2" nails. 19”...
  • Page 44 WORKBENCH PARTS REQUIRED: 2" (5,1 cm) Install (5) bench brackets at measurement shown from floor, level and flush to wall studs (Fig. A). Secure with 2" nails. Flush 2" (5,1 cm) Nails Fig. A Flush Flush 36-1/2" (84,5 cm) FLOOR...
  • Page 45 WORKBENCH PARTS REQUIRED: 3" (7,6 cm) 1 x 4 x 20-1/2" (2,5 x 10,2 x 52,1 cm) 2" (5,1 cm) 1 x 4 x 96" (2,5 x 10,2 x 243,9 cm) 19-1/2 x 23-7/8" (49,5 x 60,6 cm) 19-1/2 x 92-1/2" (49,5 x 235 cm) Install 19-1/2"...
  • Page 46 PEGBOARD PARTS REQUIRED: 2" (5,1 cm) 1 x 3 x 96" (2,5 x 7,6 x 243,9 cm) 1 x 3 x 23-78" (2,5 x 7,6 x 60,6 cm) PEGBOARD 23-7/8" x 23-7/8" (60,6 x 60,6 cm) 23-7/8" x 96" (1,1 x 60,6 x 243,9 cm) PEGBOARD BEGIN Install pegboard flush together and flush to bench top.
  • Page 47 SHELF PARTS REQUIRED: 2 x 3 x 10" 3" (7,6 cm) x6 AC (5,1 x 7,6 x 25,4 cm) 1 x 3 x 23-78" (2,5 x 7,6 x 60,6 cm) 2" (5,1 cm) 1 x 3 x 96" (2,5 x 7,6 x 243,9 cm) BEGIN Assemble shelf frame on a flat surface.
  • Page 48 SHELF PARTS REQUIRED: 1 x 4 x 23-78" 3" (7,6 cm) (2,5 x 10,2 x 60,6 cm) 2" (5,1 cm) 1 x 4 x 96" (2,5 x 10,2 x 243,9 cm) 1-1/4" (3,2 cm) 7/16 x 11-1/2 x 23-7/8" 7/16 x 11-1/2 x 96" (1,1 x 29,2 x 60,6 cm) (1,1 x 29,2 x 243,9 cm) Install 11-1/2"...
  • Page 49 SHELF PARTS REQUIRED: 2" (5,1 cm) Reinforce left shelf support from outside. Working outside, measure according to the diagram (Fig. D) and mark location of the shelf support. Secure with (3) 2" nails. Fig. D 15" (38,1 cm) 64-7/8" (164,8 cm) Bottom edge of wall panel.
  • Page 50 LOFT PANELS PARTS REQUIRED: 2" (5,1 cm) 36" x 23-7/8" (40,3 x 60,6 cm) 36" x 96" (60,6 x 244 cm) ¸ BEGIN Install loft panels centered over loft joists and ledger board. Secure with 2" nails spaced evenly (approximately 12" apart). Note: There will be a 1/2"...
  • Page 51 DOORS PARTS REQUIRED: 3" (7,6 cm) 1-1/4" (3,2 cm) 1 x 3 x 5" (2,5 x 7,6 x 12,7 cm) 69" (175,3 cm) Door Stiffener Left Door Right Door BEGIN Place doors on flat surface. 3/8" offset is to top. Look for red (right) and green (left) on hinge board.
  • Page 52 DOORS PARTS REQUIRED: 3" (7,6 cm) TEMPORARY SUPPORT 69" (175,3 cm) Door Stiffener Install OO fl ush under panels. Secure to fl oor frame with (2) 3" screws (Fig. A) . Mark center of door opening. Fig. A Flush against wall panels (2) 3"...
  • Page 53 DOOR STIFFENERS PARTS REQUIRED: 2" (5,1 cm) 69" (175,3 cm) Door Stiffener BEGIN Center OO vertically on the left door in the doorway (Fig. A) overlapping 1" (2,5 cm) along the edge of door (Fig. B). Secure with (7) 2" screws through outside trim into OO. Center OO vertically on the right door in the door opening offset 1"...
  • Page 54 DOORS PARTS REQUIRED: 2" (5,1 cm) 3/4" (1,9 cm) 19/32" x 2-1/2" x 26 5/8" (1,5 x 6,3 x 67,6 cm) 3/4" (1,9 cm) Bagged separately/ 64" Metal Threshold 19/32" x 2-1/2" x 62" (1,5 x 6,3 x 157,5 cm) special coating 19/32"...

  • Page 55: Door Hardware

    DOOR HARDWARE PARTS REQUIRED: 3/4” (1,9 cm) BEGIN Install decorative hinges in locations shown. Secure with 3/4" screws. 3/4" (1,9 cm) Screws Flush to hinge FINISH Your decorative door hinges are now installed.
  • Page 56 DOOR HARDWARE PARTS REQUIRED: 5/16" (7,9 mm) Drill Bit 3/4" (1,9 cm) BEGIN Place bolt on OO in open position with bolt end 3/8" (9,5 mm) down from frame. Bolt is open when loop is contacting base (Fig A). Mark and pre-drill holes for screws. Install bolt with screws supplied. Drill 5/16"...

  • Page 57: Right Door

    DOOR HARDWARE PARTS REQUIRED: 1-1/2" (3,8 cm) 3/8" (10,9 cm) Drill Bit 1/4" (0,6 cm) Drill Bit Measure and mark location of hole on outside of right door as shown (Fig. A) . Pre-drill hole with 1/4" drill. Re-drill hole with 3/8 " drill. Keep drilled hole square to trim to avoid breaking edge of door stiffener.
  • Page 58 WINDOW SHUTTERS PARTS REQUIRED: 19/32" x 3" x 8-1/2" (1,5 x 7,6 x 21,6 cm) 19/32" x 3" x 21" (1,5 x 7,6 x 53,3 cm) 1" (2,5 cm) 19/32" x 3" x 21" (1,5 x 7,6 x 53,3 cm) 19/32"...
  • Page 59 WINDOW & SHUTTERS PARTS REQUIRED: 1-1/4" (3,2 cm) Window 22-1/2" x 29-3/4" (57,1 x 75,6 cm) ¸ BEGIN Mark center of window frame as shown. CENTER Seal window with high-quality exterior-grade caulk before installing (Fig. A). Install window with (4) 1-1/4" screws, as shown. Ensure window is level.
  • Page 60 WINDOW & SHUTTERS PARTS REQUIRED: 2" (5 cm) 3/4" (19 mm) 19/32" x 2-1/2" x 28-1/8" (1,5 x 7,6 x 71,4 cm) Mark Locate one shutter centered on marks as shown. Install one shutter using a 2" fi nishing CENTER CENTER nail at "dot".
  • Page 61 COLLAR TIE PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) BEGIN Install collar tie TM to the 3rd rafter from the front with (3) 3" nails at each end. 3" (7,6 cm) Nails Flush to panel Flush to panel...
  • Page 62 HOOK & EYE PARTS REQUIRED: ¸ BEGIN Install hooks in wall and into framing behind (Fig. A). Fig. A Swing door open to locate eye. Hook Install hook into framing, if possible. FINISH You have installed your hook & eyes.
  • Page 63 VENT (Not included in kit.) • Follow directions provided by manufacturer and these instructions. 1/2" (13 mm) 16" x 8" BEGIN Locate and mark for (2) vents in side walls as shown; (1) at top and (1) at bottom. Cut out marked openings. Caulk behind vent fl anges.
  • Page 64 PAINT & CAULK - NOT INCLUDED - • Use acrylic latex caulk that is paintable. Caulk at all horizontal and vertical seams, between the trim and walls, and all around the door trim. • Use a high quality exterior acrylic latex paint. When painting your building, there are a few key areas that can be easily overlooked that must be painted: •...
  • Page 65 SHINGLES - NOT INCLUDED - • Follow directions provided by manufacturer and these instructions. Familiarize yourself with a 3-Tab Shingle. Notch Notch SHINGLE NAIL PATTERN 1/2" 1" Sealing Strip (1,3 cm) 1" (2,5 cm) (2,5 cm) Half A Rain Slot Full Rain Slot NAILS NEVER DRIVE FASTENERS INTO OR ABOVE SEALING STRIPS.
  • Page 66 SHINGLES continued... Beginning at front of shed, install first row of shingles with notch at 1" past roof edge or flush with drip edge. Roof Deck FRONT OF BACK OF SHED SHED 1" (2,5 cm) Flush with starter row. Notch - or - Drip Edge Flush with starter row.
  • Page 67 SHINGLES continued... Continue installing rows of shingles to the peak. At the peak make sure there is a maximum of 5" or less to the rain slot, as shown below. If shingles overlap at ridge cut to peak with a utility knife. 5"...
  • Page 68 SHINGLES - RIDGE CAP • You will finish off the top of the roof with a ridge cap made from shingles. BEGIN Cut shingles in THREE pieces. Hint: Use cut-off pieces first. 2" 2" (5,1 cm) (5,1 cm) 2" 2" 2"...
  • Page 69 SHINGLES - RIDGE CAP continued... Continue installing ridge cap to back of roof. Make sure there is 4" between the shingle-color and edge of shingles. 4" (10,2 cm) Trim cap off f ush to shingles When you have 4" minimum of shingle color cut one piece to cap your roof. Cut at top of rain slot.
  • Page 70 16615-G 10' x 12' Order Form CATEGORY PART DESCRIPTION PART SIZE PART ITEM # BUILDING QTY. PART ID Loft Ledger Board "A" LUM SPF 2X3X96 #2&BTR 12115 Loft Ledger Board "B" 2 X 3 X 23 7/8" Q 23140000000 2 X 3 Bench Support 2 X 3 X 19"...

  • Page 71: Claim Procedure

    LIMITED CONDITIONAL WARRANTY* Backyard Storage Solutions, LLC warrants the following: Every product is warranted from defects in workmanship and manufacturing for 1 year. All accessories, hardware and metal components are warranted for 2 years. All Oriented Strand Board (OSB) is warranted for 2 years Siding and Trim is warranted for 15 years.
