WAFER-JL-N5105 SBC

3.1.3 External Interface Panel Connectors

The table below lists the connectors on the external I/O panel.
Connector
External 2.5GbE RJ-45 connectors
External USB 3.2 Gen 2x1 Type-A
connector
External DisplayPort connector
External HDMI connector

Table 3-2: Rear Panel Connectors

3.2 Internal Peripheral Connectors

The section describes all of the connectors on the WAFER-JL-N5105.

3.2.1 Clear CMOS Button

CN Label:
CN Type:
CN Location:
CN Pinouts:
To clear the CMOS Setup (for example if you have forgotten the password, you should
clear the CMOS and then reset the password), you should disconnect the RTC battery
and press the button for about 3 seconds. This will set back to normal operation mode.
Type
RJ45
USB 3.2 Gen 2 Type-A
DP
HDMI
J_CMOS1
Button
See Figure 3-2
See Table 3-3
Label
LAN1, LAN2,
LAN3
USB1
DP1
HDMI1
