IEI Technology WAFER-RK3568 Quick Installation Manual

Hide thumbs

page of 13

/ 13
Bookmarks

Quick Links

Download this manual

3.5" SBC with Rockchip RK3568 Processor, 2GB/4GB LPDDR4,

32GB eMMC, HDMI 2.0, MIPI DSI & CSI, eDP, M.2 B-key,

Dual 1GbE RJ45, USB 3.0, USB 2.0, RS-232/485, 12V DC-IN,

SIM Slot, microSD Slot, Support Android/Linux, RoHS

Quick Installation Guide

Package List

WAFER-RK3568 package includes the following items:

1 x WAFER-RK3568 single board computer



1 x QIG

WAFER-RK3568

Version 1.0

January 4, 2023

Need help?

Do you have a question about the WAFER-RK3568 and is the answer not in the manual?

Questions and answers

Summary of Contents for IEI Technology WAFER-RK3568

Page 1 SIM Slot, microSD Slot, Support Android/Linux, RoHS WAFER-RK3568 Quick Installation Guide Version 1.0 January 4, 2023 Package List WAFER-RK3568 package includes the following items: 1 x WAFER-RK3568 single board computer   1 x QIG ©2023 Copyright by IEI Integration Corp.
Page 2 Specifications  CPU: Rockchip RK3568 (quad-code Cortex-A55 up to 2.0GHz)  Memory: 2GB/4GB LPDDR4/4x, up to 8GB (option: 2GB SKU only supports Linux)  SD Card: 1 x microSD slot  Flash Memory: 32GB eMMC NAND flash  WLAN 802.11a/b/g/n/ac/ax via board-to-board connector ...
Page 3  Camera: 1 x MIPI CSI (4 lanes, 30-pin, p=0.5)  GPIO: 1 x 14-bit GPIO (7 in / 7 out, 2x8 pin, p=2.0)  Expansions: 1 x M.2 B key (Support 4G (3042) + 5G (3052) module) 1 x NANO SIM card slot ...
Page 4 Jumpers Setting and Connectors LABEL FUNCTION LCD_PWR1 LCD (MIPI) power select jumper IMAGE_SW Maskrom recovery button J_OTG_HOST OTG/Host mode setting switch PWRON Power button RESET_SW Reset button DEBUG_CN Console port connector AUDIO Audio connector BAT1 Battery connector eDP connector GPIO GPIO connector M2_B1 M.2 B key slot...
Page 5 LCD_PWR1: LCD (MIPI) Power Select Jumper PIN NO. DESCRIPTION Short 1 - 2 1.8 V (default) Short 2 - 3 J_OTG_HOST: OTG/Host Mode Setting Switch PIN NO. DESCRIPTION Short A - B Host Mode Short B - C OTG Mode (default) IMAGE_SW: Maskrom Recovery Button PIN NO.
Page 6 GPIO : GPIO Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VIO_3V3 GPIO_12 GPIO_16 GPIO_11 GPIO_15 GPIO_10 GPIO_14 GPIO_5 GPIO_13 GPIO_4 GPIO_8 GPIO_3 GPIO_7 GPIO_2 GPIO_6 LCD1: MIPI DSI Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VLED+ TX_D3N VLED+ TX_D2P TX_D2N TX_CLKP TX_CLKN LED-...
Page 7 EDP: eDP Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LCD_PWM_BL LCD_TE VCC3V3_LCD LCD_RST LCD_ID LCD_PWREN CLKN/AUXN TP_I2C_SCL CLKP/AUXP TP_I2C_SDA TP_INT TP_RST CAMERA: MIPI CSI Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC2V8 VDD1V2 VDD1V8 AVDD2V8 I2C_SDA I2C_CLK CLKOUT CLKP CLKN...
Page 8 MIC: Microphone Connector DESCRIPTION DESCRIPTION MIC1_INP SPK: Speaker Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPKP_OUT SPKN_OUT TP: Touch Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB2_1: USB 2.0 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA+ USB_DATA- USB2_2: USB 2.0 Connector PIN NO.
Page 9 SIM1: SIM Card Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION SIM_VCC SIM_RST SIM_CLK SIM_VPP SIM_CIO CN1: Wi-Fi/Bluetooth Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION UART_RTSn SDMMC_D0 UART_TX SDMMC_D1 UART_RX SDMMC_D2 UART_CTSn SDMMC_D3 SDMMC_CMD I2S_LRCK WIFI2T2R_CLK I2S_SDO I2S_SDI WIFI_REG_ON I2S_SCLK WIFI_WAKE_HOST BT_WAKE_HOST 32KOUT_WIFI HOST_WAKE_BT...
Page 10 PWR1: Power Input Connector (Internal) PIN NO. DESCRIPTION PIN NO. DESCRIPTION PWR-IN PWR-IN DC_IN: Power Input Jack PIN NO. DESCRIPTION PIN NO. DESCRIPTION DCIN_12V M2_B1: M.2 B-key Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION CONFIG_3 +3.3V +3.3V USB_D+ MBK_D USB_D- Module Key Module Key Module Key...
Page 11 PCIE_TXN0 PCIE_TXP0 PCIE_PERSTn PCIE_CLKREQn REFCLKN PCIE_WAKEn REFCLKP SIM_DET RESET_N +3.3V +3.3V +3.3V COM2/1: External Serial Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION RS232_RXD1 RS485_DATA1- RS232_TXD1 RS485_DATA1+ RS232_RXD2 RS485_DATA2- RS232_TXD2 RS485_DATA2+ LAN0, LAN1: External 1GbE RJ-45 Connectors PIN NO. DESCRIPTION PIN NO.
Page 12 HDMI: External HDMI Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION HDMI2_DATA2 HDMI2_DATA2# HDMI2_DATA1 HDMI2_DATA1# HDMI2_DATA0 HDMI2_DATA0# HDMI2_CLK HDMI2_CLK# HDMI2_SCL HDM2I_SDA HDMI2_HPD USB3: External USB 3.0 Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_ DATA+ USB3_RX- USB3_RX- USB3_RX+ USB3_ RX+ USB3_TX- USB3_TX-...
Page 13 Board Layout: Jumper and Connector Locations (Unit: mm)
