3.5" SBC with Intel® Atom™ N270 Processor, VGA/LVDS,
Dual PCIe GbE, CF type II, SATA and Audio
Quick Installation Guide
Package Contents
WAFER-ATOM package includes the following items:
1 x WAFER-ATOM Single Board Computer
1 x 4 RS-232 Cable
2 x SATA cable
1x KB/MS Cable
1x Audio Cable
1 x Enclosure Heatsink
1 x Mini Jumper Pack
1 x Utility CD
1 x QIG (Quick Installation Guide)
WAFER-ATOM
Version 1.0
Oct. 09, 2008
©2006 Copyright by IEI Technology corp.
All rights reserved.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the WAFER-ATOM and is the answer not in the manual?

Questions and answers

Summary of Contents for IEI Technology WAFER-ATOM

  • Page 1 Dual PCIe GbE, CF type II, SATA and Audio WAFER-ATOM Quick Installation Guide Version 1.0 Oct. 09, 2008 Package Contents WAFER-ATOM package includes the following items: 1 x WAFER-ATOM Single Board Computer 1 x 4 RS-232 Cable 2 x SATA cable 1x KB/MS Cable 1x Audio Cable...
  • Page 2 Specifications CPU: On board Intel® Atom™ N270 1.6GHz/512KB L2 Cache with a 533MHz FSB System Chipset: Intel® 945GSE +ICH7M BIOS: AMI BIOS, SPI 8Mbit Flash ROM System memory: 1 x 200-pins 533/400MHz DDR2 SDRAM SO-DIMM (max. 2GB) Ethernet: Dual Realtek RTL8111CP GbE Controllers I/O Interface: 2 x SATA 6 x USB 2.0 (2 on rear side, 4 by pin-header)
  • Page 3 Weight: GW: 700g; NW: 230g Ordering Information WAFER-ATOM-N270-R10: 3.5" SBC with Intel® Atom™ N270 1.6GHz, VGA/LVDS, Dual GbE, CFII, USB, SATA and Audio 32000-070301-RS: Dual port USB cable 32200-026500-RS: RS-232/422/485 cable 32100-043403-RS: ATX Power Cable 32100-088600-RS: SATA Power Cable IO-KIT-4COM-R10: 4 COM Ports Adapter Borad...
  • Page 4 J_LCD_TYPE1: LVDS1 Panel Resolution Selection DESCRIPTION Open Open Open Open 640X480 (18-bit) Open Open Open Short 800X480 (18-bit) 800X600 (18-bit) Open Open Short Open (Default) Open Open Short Short 1024X768 (18-bit) Open Short Open Open 1280X1024 (36-bit) Open Short Open Short 1400X1050 (36-bit) Open Short Short Open 1400X900 (36-bit)
  • Page 5 Table of Connectors LABEL FUNCTION VGA1 VGA 15-pin Female Connector USB_C45 2 Port USB Connector LAN1 RJ-45 LAN Connectors LAN2 KB_MS1 Keyboard & Mouse Connector COM1 COM Port Connector (RS-232) COM2 Internal Serial Port Connectors (RS-232/422/485) Internal Serial 4 Port Connectors (RS-232) USB01 Internal 4 Port USB Connectors USB23...
  • Page 6 USB_C45: USB Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC (+5V) VCC (+5V) DATA4- DATA5- DATA4+ DATA5+ LAN1、LAN2: RJ-45 LAN Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDIA3- MDIA1+ MDIA3+ MDIA2+- MDIA2- MDIA0- MDIA1- MDIA0+ KB_MS1: 6-pin Keyboard/Mouse Connector PIN NO. DESCRIPTION VCC (+5V) Mouse Data...
  • Page 7: Transmit Data

    COM2 : Internal Serial Port Connector (RS-232/422/485) PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA CARRIER DATA SET READY DETECT (DCD#) (DSR#) RECEIVE DATA REQUEST TO SEND (RXD) (RTS#) TRANSMIT DATA CLEAR TO SEND (TXD) (CTS#) DATA TERMINAL RING INDICATOR READY (DTR#) (RI#) TXD485+ TXD485#...
  • Page 8 USB01, USB23: Internal USB Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC (+5V) DATA- DATA+ DATA+ DATA- VCC (+5V) AUDIO1 : AC’97 audio Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LINEIN_R LINE_OUTR GND_AUDIO GND_AUDIO LINE_OUTL LINEIN_L GND_AUDIO GND_AUDIO MICIN MICIN SATA1 &...
  • Page 9 LVDS1: LVDS Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION GND1 GND2 A_Y0 A_Y0# A_Y1 A_Y1# A_Y2 A_Y2# A_CK A_CK# GND3 GND4 B_Y0 B_Y0# B_Y1 B_Y1# B_Y2 B_Y2# B_CK B_CK# GND5 GND6 VCC_LCD VCC_LCD VCC_LCD VCC_LCD INVERTER1: 5-pin Header Inverter Connector PIN NO.
  • Page 10 CF1 : CF Card Interface Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION CD1# CE2# VS1# IOR# IOW# CSEL# VS2# RESET# WAIT# INPACK# REG# BVD2 BVD1 IOCS16# CD2# GND2 DIO1 : Digital Input / Output Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC (+5V) Output 3...
  • Page 11 CN4: PCIe Mini Card Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCIE_WAKE# VCC3 1.5V CLKREQ# LFRAME# LAD3 CLK- LAD2 CLK+ LAD1 LAD0 PCIRST# VCC3 PCIRST# PERN2 3VDual PERP2 1.5V SMBCLK PETN2 SMBDATA PETP2 USBD- USBD+ RF_LINK# BLUELED# 1.5V VCC3 LED_C1: 6-pin LED Indicators and +5V Output connector PIN NO.
  • Page 12 Board Layout: Jumper and Connector Locations...
