3.5" SBC with NXP i.MX 8M Plus Processor, 4GB LPDDR4, 16GB
eMMC Flash, HDMI, MIPI DSI, MIPI CSI, GPIO, Dual GbE, USB Type-C,
RS-232/422/485, Android 12 / Yocto 3.2, 0°C ~70°C and RoHS
Quick Installation Guide
Package List
WAFER-IMX8MP package includes the following items:
1 x WAFER-IMX8MP single board computer
1 x Pluggable female terminal block
1 x QIG
WAFER-IMX8MP
Version 1.0
August 10, 2023
©2023 Copyright by IEI Integration Corp.
All rights reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for IEI Technology WAFER-IMX8MP
Summary of Contents for IEI Technology WAFER-IMX8MP
- Page 1 RS-232/422/485, Android 12 / Yocto 3.2, 0°C ~70°C and RoHS WAFER-IMX8MP Quick Installation Guide Version 1.0 August 10, 2023 Package List WAFER-IMX8MP package includes the following items: 1 x WAFER-IMX8MP single board computer 1 x Pluggable female terminal block ...
-
Page 2: Specifications
Specifications Processor: NXP i.MX 8M Plus Quad (quad-core Cortex®-A53 up to 1.8 GHz) GPU: GC7000UL 3D (2 shaders), GC520L NPU: Up to 2.3 TOPS RAM: 4 GB LPDDR4-3200, up to 8GB Flash: 16 GB eMMC NAND flash, up to 128GB 1 x microSD slot Audio: ... -
Page 3: Ordering Information
Wi-Fi & Bluetooth module (2-stream 802.11ac, 2T2R, Bluetooth 5.0, RoHS) IEI Resource Download Center All the drivers and utility for the https://download.ieiworld.com WAFER-IMX8MP are available on IEI Resource Download Center. Type WAFER-IMX8MP and press Enter to find all the relevant software, utilities, and documentation. -
Page 4: Jumpers Setting And Connectors
Jumpers Setting and Connectors LABEL FUNCTION BAT_CN1 RTC battery connector CN16 Debug port connector Download key GPIO connector LTE module slot microSD slot MIPI DSI output connector CN18 MIPI CSI connector U117 SIM slot CN24 Speaker connector RS-232/485 connector Reset button Touch connector CN27 Wi-Fi/Bluetooth module slot... - Page 5 JP3: GPIO Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION EXT_GPIO1 EXT_GPIO2 EXT_GPIO3 EXT_GPIO4 EXT_GPIO5 EXT_GPIO6 EXT_GPIO7 EXT_GPIO8 J1: MIPI DSI Output Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LCD_NC1 MIPI_D3P LCD_VDD LCD_VDD LCD_NC2 LCD_RESET LCD_NC3 LED_PWM MIPI_D0N LCD_NC4 MIPI_D0P LCD_NC5 MIPI_D1N LCD_LED- MIPI_D1P...
- Page 6 CN18: MIPI CSI Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION CAM_LED- CAM_D3 CAM_LED+ CAM_D2 CAM_RST CAM_FREX CAM_HSYNC CAM_STROBE CAM_VSYNC CAM_D1P CAM_I2C_SDA CAM_D1N CAM_I2C_SCL CAM_PWD_N CAM_MCP CAM_MCLK CAM_MCN CAM_DVDD1V5 CAM_DOVDD CAM_MDP1 CAM_AGND CAM_MDN1 CAM_AVDD_2V8 U117: SIM Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION LTE_UIM_PWR SIM_VPP_1...
- Page 7 JP2: RS-232/485 Connector PIN NO. RS-232 RS-485 DATA- DATA+ JP1: Touch Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION A_CPT_I2C_SDA A_CPT_INT TOUCH_VCC A_CPT_RST A_CPT_I2C_SCL D94: LED Indicators STATUS DESCRIPTION Power connected Green No power connected Turned on and boot into OS Not turned on / Failed to boot into OS CN25: RS-232/422/485 Connector PIN NO.
- Page 8 Board Layout: Jumper and Connector Locations (Unit: mm)
