External Supply

1
Use the upper slot in the rear plate when the
supply is at the same level as the printer.
Intermec EasyCoder 601 XP – Installation & Operation Ed. 3
The EasyCoder 601 XP can print on labels, tickets, tags, and paper
strip in various forms. This chapter describes the case when an ex-
ternal paper supply is used, e.g. a stack of fan-fold tickets or an
external paper roll.
Even if it is possible to simply let the paper enter the printer through
either of the two slots in the rear plate, it is recommended to fit the
optional Intermec Fan-Fold Kit, which provides better guidance of
the paper web using adjustable paper guides fitted to either the up-
per or lower slot in the rear plate.
When using an external paper supply, take care to protect the paper
from dust, dirt and other foreign particles, that can impair the print-
out quality or cause unneccessary wear to the printhead.
External supply can be used for:
• Tear off operation
• Cut off operation
• Peel off operation (upper slot only)
2
Use the lower slot in the rear plate when the
supply is placed lower than the printer.
Chapter 5 Paper Load
