Memory Card

Power On

Intermec EasyCoder 601 XP – Installation & Operation Ed. 3
If you want to use a memory card, you must insert it into the slot in
the printer's rear plate before you turn on the power. The memory
card can be an SRAM card complying with the JEIDA-4 standard
or Flash Memory card from Intermec. There are three types of Flash

Memory Cards:

• A Font Card provides additional fonts as long as it remains
inserted in the printer.
• A Font Install Card permanently installs additional fonts in the
printer which can be used even after the card has been removed.
• A Firmware Card automatically replaces the printer's firmware,
e.g. with an updated version.
Important!
Always turn off the power before inserting or removing a memory
card!
Do not start the printer before you have made the necessary con-
nections, inserted any memory card you want to use, and checked
that the printhead is lowered and the optional cutter is in closed
position.
Turn on the power by means of the main switch on the rear plate.
The "Power" LED control lamp on the front panel lights up when
the power is on. Wait for a few moments, while the printer loads the
program and runs some self-diagnostic tests. If the printer is fitted
with a paper cutter, it will rotate to home position. Finally, some
kind of message will appear in the display window, depending on
startup file.
