Intermec EasyCoder 601 XP Installation And Operation Manual page 92

Printhead Replacement,
7
Disconnect the two cables from the printhead.
Note the snap-lock on the white connector. Pull
at the connectors – not the cables!
9
Fit the hooks of the printhead bracket fingers
onto the headlift shaft.
Intermec EasyCoder 601 XP – Installation & Operation Ed. 3
cont'd.
8
Snap-lock
Connect the cables to the replacement print-
head. Blue connector to the left, white connector
10
Close the printhead so the magnet engages the
printhead bracket. Close the locking handle.
Chapter 12 Maintenance
Blue
to the right.
White
