UBI EasyCoder 601 E – User's Manual
PAPER LOAD – EXTERNAL PAPER SUPPLY
1 2
The printer can be supplied with paper from e.g. an
external label roll or a box of fan-fold tickets via the The lower intake slot is preferred when the supply is
upper or lower slot in the rear plate. placed lower than the printer.
3
4
As an option, the printer can be fitted with a set of
fan-fold guides in either intake slot.
The outer guide is adjustable for different paper widths.
5
When an external paper supply is used, take precautions
to protect the paper stock from sand, grit and other hard
particles, that may damage the printhead!
The fan-fold guide can be supplemented with an
additional guide shaft which replaces the label slack
absorber. Thread the paper as illustrated from either
intake slot.
15
