Media
Compartment
Slack Absorber
Intermec EasyCoder 601 XP – Installation & Operation Ed. 3
The media compartment becomes accessible when the right-hand
door is opened. Being held by a magnetic lock, this door can be
pened 180 , or be removed completely by pushing it rearwards.
Ribbon Rewind Spool
Ribbon Supply Spool
Refer to chapter 10 "Options" for information on possible optional
devices fitted inside the printer's media compartment.
Chapter 3
Installation
Paper Supply
19
