SETUP PARAMETERS
General Information
Parameter
Contrast
2
Ser-Com :
Baudrate
Parity
Char length
Stop bits
Type of flow control:
- RTS/CTS
- ENQ/ACK
- XON/XOFF, data from host
- XON/XOFF, data to host
- Prot addr.
New line
Detection:
LSS adjust
Feed adj:
- Start adjust
- Stop adjust
Service:
Media size:
- X-start
- Width
- Length
Media type:
Print defs:
- Head resist
- Paper type
- Test print
Performance:
Memory alloc:
- Image buff size
2
- Rec buff size
2
- Trans buff size
1
/. "Default" refers to the default setup values in the standard configuration EPROM's. A custom-made printer fitted with
nonstandard configuration EPROM's may have a different combination of setup values.
2
/. The software is able to detect if any of the optional serial interface boards is fitted. If so, the communication parameters
and the size of the buffers are set up separately for each of the serial communication channels "uart1:", "uart2:", and
"uart3:". There is no communication setup for the optional Centronics parallel communication channel.
3
/. Baudrate 38,400 is only available for "uart2:" and "uart3:" (requires an optional interface board).
4
/. Not available for EasyCoder 201 IIS.
5
/. Higher default value for EasyCoder 201 IISA.
The setup allows you to adapt the printer for the desired type of
computer communication and to control the printing. The setup
parameters are:
Options
Variable (0–10)
300 | 600 | 1200 | 2400 | 4800 | 9600 | 19200 | 38400
even | odd | mark | space | none
7 bits | 8 bits
1 bit | 2 bits
Enable | disable (not on "uart2:" when RS 485 interface pcb fitted)
Enable | disable
Enable | disable
Enable | disable
Enable | disable ("uart2:" only, when RS 485 interface pcb fitted)
CR/LF | LF | CR
Variable
Variable
Variable
Variable (6 dots/mm: 0–511; 8 dots/mm: 0 – 639)
Variable (6 dots/mm: 0–512; 8 dots/mm: 0 – 640)
Unlimited
Label (w gaps) | Ticket (w mark) | Ticket (w gaps) |
Fix length strip | Var length strip
Set automatically at startup
See the chapter "Thermal Paper"
A series of test labels can be printed
Normal | High | Ultra high
Variable (max. 250 kbyte)
Variable
Variable
3
4
Default 1
Middle (5)
9600
none
7 bits
2 bits
disable
disable
enable
enable
disable
CR/LF
n.a.
0
0
0/0
512/640
1200/1200
Label (w gaps)
n.a.
RICOH 130LAB/LAM
n.a.
Normal
5
24 kbyte
5
300 byte
300 byte
