72: Serial Out Baud Rate

Purpose: Selects the baud rate for data sent from the interface
card to the printer. This setting becomes active the
next time the printer is turned on.
Syntax: Z72,n
n =
0 38,400 baud
1 19,200 baud (default) 5
2 9,600 baud
3 4,800 baud
Example: &%Z72,0
Sets the outgoing baud rate on the interface card to
38,400.

73: Serial Out Word Length

Purpose: Selects the word length of data sent from the interface
card to the printer. This setting becomes active the
next time the printer is turned on.
Syntax: Z73,n
n =
7 7 bits
8 8 bits (default)
&%Z73,7
Example:
Sets the outgoing word length on the interface card to
7 bits.

74: Serial Out Stop Bits

Purpose: Selects the number of stop bits of a data stream sent
from the interface card to the printer. This setting
becomes active the next time the printer is turned on.
Syntax: Z74,n
n =
1 1 bit (default)
2 2 bits
Example: &%Z75,2
Sets the outgoing stop bits on the interface card to 2.
1
Coax Configuration
4 2,400 baud
1,200 baud
6 600 baud
7 300 baud
1-17
