65: Character Set Selection

Purpose: Enables you to make a special selection of the ASCII
character set to convert EBCDIC (SCS/LU1) or DSC
(LU3) to ASCII.
Syntax: Z65,n
n =
1 Roman 8 character set
2 Code Page 850 character set (default)
Example: &%Z65,2
Selects the Code Page 850 character set.
Notes: The character set substitutions defined in commands
70 and 71 must be adjusted if the ASCII character set
is changed. All previously defined substitutions are
lost from saved memory when the character set
selection is changed.
This is the character set that the printer uses in
printing. You must also select this character set on the
4630 or 4830 printer using the menu panel.
Refer to the character set summary tables at the end of
the self test to confirm which ASCII character is
printed for each of the 3270 hex codes. Both the
EBCDIC and DSC tables are provided.

66: Output Port

Purpose: Selects the output port. Currently, only the serial port
setting is available for this command.
Syntax: Z66,n
n =
0 Parallel port
1 Serial port (default, required)
2 Parallel port and initialization string
3 Serial port and initialization string
Example: &%Z66,1
Selects the printer serial port.
1
