IPC972 Series User's Manual
2.4

Installing the Memory Module

The IPC972 comes with four DDR4 U-DIMM sockets. Please refer to the following instructions
and illustrations for the installation of the RAM module.
Step 1 Turn off the system.
Step 2 Disconnect the power connector.
Step 3 Loosen 7 screws to remove the side cover from the chassis.
Step 4 Install the U-DIMM into the socket and push it firmly down until it is fully seated. The
socket latches are clipped onto the edges of the memory module.
The IPC972 supports an optional bracket to avoid memory module bounced off from sockets.
Please refer to the following instructions and illustrations for installation.
Step 5 Take the strengthen bracket and its screws from the accessory box.
38 Hardware Installation
