Step 2 Take the SSD/HDD bracket and its screws from the accessory box, then screw the
SSD/DD to the bracket.
Step 3 Align the connector of the SSD/HDD with the SATA slot (#1), then insert the SSD/HDD
into the bay and screw the bracket. Installation is complete.
Step 4 Take the NVMe bracket, thermal pads and its screws from the accessory box and
stick a thermal pad on socket, then insert the SSD into the socket (#2) and
tighten the screws. Stick another pad on SSD.
