Figure 75 Step 5: New waveform number will turn green when usersre-click the"RefresherList"

8.13.5 Command Explanations

Code (1
Parameter1(2 bytes)
Byte)
1 Stop none
2 SPT 0～65000 (ms)
3 SPR 0～65000(W/ms)
Wait
1
signal low level
Wait
4 WAIT 2
signal high level
Wait
3
signal rising
Figure 74 Step 4: After editing all commands, click"Write Laser"
Table 16 Command explanations in laserworkingstatus
for sync
for sync
for sync
Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
Parameter 2 (4 bytes)
none
0～65000W
0～65000W
Null
Null
Null
69
Note
The program end command. the last
command must be this command.
Change power to 2 in time 1
Change power to 2 in power change
ratio 1
