Summary of Contents for Raycus RFL-P20QB
- Page 1 编号 RFL-P20QB～P30QB 密级 阶段标记 页数 名称 RFL-P20QB～P30QB 脉冲光纤激光器英文使用说明书 会签 单位 第二事业部 编写 李科 校对 朱军 审核 施建宏 标审 李其军 批准 黄保 武汉锐科光纤激光技术股份有限公司...
- Page 2 User’s guide Ytterbium Pulsed Fiber Laser RFL-P20QB～P30QB Ver.: 2.0 Ytterbium Pulsed Fiber Laser User’s Guide RFL-P20QB～P30QB Wuhan Raycus Fiber Laser Technologies Co., Ltd.,2018 Proprietary information. All rights reserved Issued 19 October 2018...
- Page 3 Raycus pulsed fiber laser is classified as a high power Class IV laser device. Before supplying the power to the device, please make sure that the correct voltage of 24VDC power source is connected and the anode and cathode are right.
-
Page 4: Table Of Contents
User’s guide Ytterbium Pulsed Fiber Laser RFL-P20QB～P30QB Ver.: 2.0 Content Description ...................... 1 1.1. Product description ......................1 1.2. Actual configuration list ....................1 1.3. Environmental requirements and cautions ..............1 1.4. Specifications ......................... 2 Mounting ......................3 Mounting dimensions ....................3 Method of installation .................... -
Page 5: Description
(1) Caution: Make sure the corresponding wires of the device are properly grounded. (2) All the maintenance to the device should only be done by Raycus, because there is no replacement or accessory provided with the device. Please do not try to damage the labels or open the cover in order to prevent against electric shock, or the warranty will be invalid. -
Page 6: Specifications
User’s guide Ytterbium Pulsed Fiber Laser RFL-P20QB～P30QB Ver.: 2.0 weakened. Therefore, it should be used under normal conditions. (5) Do not install the collimating device into the output head when the laser device is in working. (6) The device has three cooling fans at the rear panel to dissipate heat. In order to guarantee enough airflow to help giving heat off, there must be a space of at least 10cm’s width for... -
Page 7: Mounting
User’s guide Ytterbium Pulsed Fiber Laser RFL-P20QB～P30QB Ver.: 2.0 2. Mounting 2.1 Mounting dimensions (1) Fiber Laser module dimensions (As shown in Fig. 1). Figure 1. Dimension drawing of laser module (Unit: mm). (2) Isolated output isolator (As shown in Fig. 2). - Page 8 User’s guide Ytterbium Pulsed Fiber Laser RFL-P20QB～P30QB Ver.: 2.0 device and output isolator must be packed with suitable soft materials in case of damaging due to vibration during the transportation. (2) Fix the laser device steady on the holder and ensure good ventilation.
-
Page 9: Control Interface
User’s guide Ytterbium Pulsed Fiber Laser RFL-P20QB～P30QB Ver.: 2.0 3. Control Interface There are DB9 and DB25 interfaces at the rear of the laser. The DB9 is a RS232 interface only used for debugging, no needs to connect. And DB25 is the joint interface connecting control system to the laser system, please make sure the connection is reliable before operation. - Page 10 User’s guide Ytterbium Pulsed Fiber Laser RFL-P20QB～P30QB Ver.: 2.0 9,23 Obligate PIN Reserved. (1) The pump current of diode laser and the laser output power are controlled by setting the value of PIN1-PIN8 (TTL level). PIN1-PIN8 can be set from 0～255，corresponding to the laser output power from 0～100％( the actual laser power may not be strictly linear with the...
- Page 11 User’s guide Ytterbium Pulsed Fiber Laser RFL-P20QB～P30QB Ver.: 2.0 Laser system is not ready for High High × emission state High High Obligate alarm × High High High Obligate alarm × (5) PIN 18 is the start signal of the MO. PIN19 is the input for the optical output signal. The electrical level for both PIN18 and PIN19 are 5V.
-
Page 12: Operation Regulations
User’s guide Ytterbium Pulsed Fiber Laser RFL-P20QB～P30QB Ver.: 2.0 4. Operation Regulations 4.1 Pre-inspection (8) Make sure the device appearance is in good condition and the output fiber is neither excessively bended nor broken. (9) Make sure signal line of laser and marking system are properly connected. -
Page 13: Instructions For Warranty, Return And Maintenance
Raycus has the right to choose to repair or replace any product that proves to be defective in materials and workmanship selectively during the warranty period. Only products with particular defects are under warranty.
