i) PH value of liquid: 5.5 ~ 9.
j) Filter element/cartridge is needed for the cooling system, and the size of the solid residual particles
should be ≤ 100 μm; replace the filter element/cartridge once a month.
k) Maximum temperature of liquid: 45 ℃.
Minimum temperature of liquid: 5 ℃ above the saturated dew-point.
l)
m) Additive to the liquid: satisfies the requirements of PH value and size of solid residual particles as
above.
n) Radius of the bending of the armored pipe: off-work state (i.e., transportation and reservation):
minimum radius of bending ≥ 15 cm; in-work state: minimum radius of bending ≥ 20 cm.
o) Long-term vibration < 2 G; Impact < 10 G.

3.3.3 Other Requirements:

a) When initiating the cooling system before using the product each time, check the entire water system
and joints to prevent the water leakage. The external water pipe must be installed and connected
according to the water inlet (IN) and water outlet (OUT) identified on the rear panel of the product.
Otherwise, the product may not work properly.
b) If the product is not used for a long time, the cooling water inside the cooling system and the product
should be drained totally, and then both the inlet and outlet must be covered with proper caps.
Otherwise, the product may be damaged due to the frozen.
c) Please use compressed gas below 0.5 MPa when draining the water from the product. Failure to do
so may cause permanent and irrecoverable damage to the cooling system.
CAUTION:
a) Set the water temperature of the cooling system correctly according to the
ambient temperature. If the water temperature was set too high, it will result in
the product de-functioning. If the water temperature was set too low, it will cause
condensation inside the product or the laser fiber delivery cable, which will cause
damage to the product as well;
b) Before turning on the product, the cooling system must be working properly and
the water temperature should be suitable for the temperature.
