Raycus ABP Series User Manual page 50

No high reflection
Bit 3
High reflection Abnormal
External AD mode=off
Bit 4
External AD mode=on
Power Correction Mode=off
Bit 5
Power Correction Mode=on
Normal
Bit 6
Sub-controlling
abnormal
Normal
Bit 7
Sub-module abnormal
Guidelaser=off
Bit 8
Guidelaser=on
The laser is not ready
Bit 9
The laser is ready
QCW mode=off
Bit 10
QCW mode=on
Module Main Power=off
Bit 11
Module Main Power=on
Modulation mode=off
Bit 12
Modulation mode=on
Normal
Bit 13
Leakage sensors 1 leaking
Normal
Bit 14
Leakage sensors 2 leaking
No laser
Bit 15
Laser is power on
Gate mode=off
Bit 16
Gate mode=on
AC input normal
Bit 17
AC input abnormal
External Emission control=off
Bit 18
External Emission control=on
Normal
Bit 19
Laser fault
Slow up slow down mode off
Bit 20
Slow up slow down mode on
A laser operates in ON" mode
Bit 21
A laser operates in REM" mode
Bit 22 Wave mode off
Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
communication
46
