Raycus ABP Series User Manual page 31

Pin
Pin No. Pin Name
A1
Laser request
Programming
A2
mode execution
A3
Internal model
A4
Reset
A5
Guide laser
A6
Analog control
A7 Stop editing
Program number
A8
selects address
Program number
A9~A14
selects address1-
6
A15 Synchronization
A16
COM
The laser drive
C1
power on
C2 Null
Optical gate
C3~C6
selection
Currently
reserved
C7
(intended as an
enabling signal in
QCW mode)
C8~C16
/
Table 6 XP1 Hardwire interface definition
Type
Input signal and request laser, laser will receive other commands
Input
only after this bit is valid
Rising edge will initiate the laser source to emit laser power
according to the pre-downloaded programming commands.
Program number is determined by Pin A8~A14.
1) if the program number is 0000000 and Pin A6 is high, the laser
power is set by AD analog value;
Input 2) if the program number is 0000000 and Pin A6 is low, the laser
power is set by Raycus Laser Control System (Raycus House-
made Software);
3) if the program number is 0000000 and Pin A6 is low and A3 is
high, the laser emission is controlled by Raycus Laser Control
System (Raycus House-made Software)
Input High level enables the Raycus Laser Control System
Effective high level and clear the laser alarm bit, the effective high-
Input
level time will last at least 1ms
Input Valid until guide laser on.
Input signal, it is valid after be able to simulate the input signal
Input
(Program num = 0000000)
Input Stop editing immediately once in high level.
Input Input signal, low level
Input Input signal, high bits 1 ~ 6s, select program number
Input Backup
The reference
for all signals
Input signal, rising edge to turn on the main power, falling edge to
Input
turn off the main power.
/
Input signal:C3is low level, C6 is high level;
0000 - Optical Gate closed
0001 - Optical Gate 1 is open
Input 0010 - Optical Gate 2 is open
0011- Optical Gate 3 is open
(Only working for laser source featuring Optical Gate function,
and as standby for normal models. )
Input signal, enabling QCW mode
Input
(Only working for laser source featuring QCW mode)
/ Backup
Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
Descriptions
27
/
/
