Display
Emergency stop
REM
Red laser external
control
Red laser
Output fiber Interlock
status
External control
model
Power correction
AD model
Monitoring model
InterLock1 make
InterLock2 make
Programming model
Power slow rise & fall
mode

8.3.3 Laser Power-up, Mode Selection, Laser Emission Control Area

Laser power-up, mode selection, laser emission control display area is as Figure 40, the display content
is as in Table 14.
Table 13 The laser main displayarea clarification
Content explanation
Red: emergency stop button on front panel is pressed
Gray: emergency stop button is reset
Green: laser works in REM mode
Gray: laser works in ON mode
Green: laser works in red laser external control mode
Gray: laser works in red laser internal mode. Laser on/off controllable by software
Green: red laser is on
Gray: red laser is off
Green: Interlock spot at output fiber end is make
Gray: Interlock spot at output fiber end is break
Green: Laser works in external control mode
Gray: laser works in internal control mode. Laser on/off is controllable by software
Green: Laser operates in power linear correction mode, in which control system automatically
adjusts the laser's emission power. It makes the emission power linear, with a longer response
time for AD analog in this mode, longer than 1mS.
Gray：laser operates in non-correction mode, and the external 0-10V analog voltage is linear
only with the current of the pump auxiliary tube. The response time for this mode AD
simulation is less than 100uS
Green: Laser power is determined by the 0-10V analog voltage on XP4 when laser works in
AD mode.
Gray: laser power is set by Raycus Laser Control Software or communication commands.
Green: Raycus Laser Control Software is in monitoring mode. Users can monitor laser status
only, but not able to take control of laser. Monitoring model is activated when interface 10001
of laser occupied.
Gray: Raycus Laser Control Software operate in normal mode
Green: XP2 leg 17,18 on safety interface make
Gray: XP2 leg 17,18 on safety interface break
Green: XP2 leg 19,20 on safety interface make
Gray: XP2 leg 19,20 on safety interface break
Green: Laser is in program mode
Gray: Laser is not in program mode
Green: laser works in power slow rise & fall mode
Gray: laser does not work in power slow rise & fall mode
