Interfaces
Breaker
AC Input
Figure 9.a - Rear panel (RFL-1500/1500,2000/2000)
Interfaces
Breaker
AC Input
Picture 9.b - Rear view of RFL-3000/3000,4000/2000,2000/4000,4000/4000
Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
19
Air Conditioner
Water Inlet
Outlet for Delivery Cable
Water Inlet
Filter
Outlet for Laser Source
Air Conditioner
Water Inlet
Outlet for Delivery Cable
Water Inlet
Filter
Outlet for Laser Source
