Log (In Diagnosticmode); Download Log; Download Record Of Historicalfault - Raycus ABP Series User Manual

The laser interface status indicator interface is as Figure 61. It is convenient to view the interface status
information which represents the input and output status of the XP1 interface on the back panel.

8.11 Log (in DiagnosticMode)

Laser's working log interface is shown as Figure 62. Users can query work log by entering the time to
query and click on the "Search" button.

8.11.1 Download Log

Log download interface is shown as Figure 63.

8.11.2 Download Record of HistoricalFault

Historical fault record download interface is shown as Figure 64.
Figure 62 Laser's workingloginterface
Figure 63 Logdownloadinterface
64
Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
