B1 Laser ready
B2
Laser emitting
Internal mode
B3
Indicator
B4
Abnormal
Guide laser
B5
indicator
B6
AD mode
Laser receiving
B7
request signal
B8 Main power on
Waveform mode
B9
Indicator
Waveform mode
B10
execution
finished
Waveform mode
B11
abnormally
finished
Synchronization
B12
signal output
B13 Alarm
B14
Backup
External power
B15
source +
External power
B16
source -
Working optical
D1~D4
gate indicator
D5
Cooler warning
D6
Cooler alarm
D7
QCW mode
Hardware
D8~D11
address
D12~D16
Backup
Output Indicate that the laser is ready for emission.
Output Indicate that the laser is emitting.
Output Indicate that the laser is working in Internal mode.
Output Indicate that the laser is in abnormal condition.
Output Indicate that the laser guide laser is on.
Output Indicate that the laser is working in AD mode.
Output Indicate that the laser receives Request Signal (Pin A1).
Output Indicate the main power is on.
Output Indicate that the laser is working in Waveform mode.
Indicate that the Waveform mode is successfully done. Invalid pin
Output
A2 will reset this pin.
Indicate that the Waveform mode is abnormally finished. Reset (Pin
Output
A4) will reset this pin.
Output High level valid, low level invalid
Output Indicate that the laser is having alarms.
/
/
External power source of 24V. All output pins are effective when
Pin B15 and B16 are connected with 24V external power source.
/
Indicating the current working Optical Gate:
0000- Optical Gate disabled
0001-Optical Gate 1 is working
0010-Optical Gate 2 is working
Output
0011-Optical Gate 3 is working
D1 low level，D4 high level
(Only working for laser source featuring Optical Gate, and as
standby for normal models)
Output Warning for the current cooling water temperature.
Output Alarm for the current cooling water temperature.
Indicate the laser source is working in QCW mode
Output
(Only for model featuring QCW function)
Coding-Cable function
0000- Laser source number 0
Output
0001- Laser source number 1
D8 low level，D11 high level
/
