HYDRAULIC SYSTEM
7
Item
1 Port 1A - Load Sense
2 Port 1B - Priority Flow
3 Inlet Port
4 Outlet Port
5 Port 2A - Work Port
2-36
6
5
9
8
2200 2200
4
10
3
8
Swing/Steer Valve Assembly
Description
Published 11/26/2014, Control # 447-05
2
1
2500
7
2
5
1
6
6671-2
Item
6 Port 2B - Work Port
7 Steer Priority Flow Divider
8 Swing WP Relief Valve
9 Swing WP Relief Valve
10 Swing Directional Valve
3
6671-3A
9
4
FIGURE 2-19
Description
RT770E
