Manitowoc Grove RT770E Service Maintenance Manual page 261

RT770E
4
6
2
3
Item Description
1 Exhaust Tube
2 Clamp
3 Muffler Clamp
4 Elbow
5 Flex Tube
6 Elbow
GROVE
3
2
2
7
10
Tier 3 Muffler
Published 11/26/2014, Control # 447-05
1
2
5
2
7844
11
Item Description
7 Exhaust Elbow
8 Muffler
9 Mounting Band
10 Exhaust Bracket
11 Bracket
POWER TRAIN
8
9
FIGURE 7-8
7-15
7
