Drive Train - Manitowoc Grove RT770E Service Maintenance Manual

LUBRICATION
Lube Point
Item
Description

Drive Train

20a a. Engine
Crankcase
20b b. Filter
21a a. Transmission,
Torque
Converter,
Dipstick
21b b. Filter
NOTE:
• Check the transmission fluid level with engine running at 850 rpm idle and the converter oil at 83°C to 93°C (180°F to 200°F). Do
not attempt an oil level check with cold oil. To bring the oil temperature to this range, it is necessary to either work the crane or
stall the converter. Converter stall should be accomplished by engaging shift lever in forward high range with the brakes applied
and then accelerating the engine to half or three-quarter throttle. Hold the stall until the required converter temperature is
reached and stabilized. (Do not operate the converter at stall condition for longer than 30 seconds at one time. Shift to neutral for
15 seconds and repeat the procedure until the desired temperature is reached. Excessive temperature, i.e, 120°C (250°F)
maximum will cause damage to transmission clutches, fluid, converter and seals.)
• Drain the oil at 65°C to 93°C (150°F to 200°F).
• Transmission filters are located on the outside left hand frame in the area of the hydraulic oil cooler inside left hand engine cover.
• To add fluid:
a. Fill to FULL mark on dipstick
b. Run engine at 850 rpm to prime torque converter and lines
c. Check oil level with engine running at 850 rpm and converter oil at 82°C to 93°C (180°F to 200°F). Add oil to bring
oil level to FULL mark on dipstick.1
Engine Cooling
22 System and SCA
Levels
Coolant Strainer
23
(Cab Heater)
9-12
Figure Approved
No. Lubricant
EO-15W/40
Engine Oil
SAE 15W-40
Figure 9-3
T3 Engine -
6829003483
T4 Engine -
6829104182
HYDO
Figure 9-3 Hydraulic Oil
6829006444
AFC 50/50
50/50 Blended
Fully
Formulated
Antifreeze
Figure 9-3
Coolant
6829101130
SCA
6829012858
Figure 9-3 ---
Published 11/26/2014, Control # 447-05
Lube
Lube Interval
Capacity
• Check level every 10
hours or daily
• Drain, fill and replace
filter every: 500 hours
18.9 L
(0-500 ppm sulfur fuel);
(20 qt)
400 hours
(500-5000 ppm sulfur
fuel); 250 hours
(>5000 ppm sulfur fuel)
• Check level every 10
hours or daily
• Drain and refill every
1000 hours or 6
37.9 L
months
(40 qt)
• Change transmission
filter after first 50 and
100 hours of service,
then every 500 hours
thereafter
• Check coolant level
every 10 hours or daily
• Check SCA levels
every 500 hours or 3
37.9 L
months
40 qt
• Check coolant for
contamination every
1000 hours or 6
months
Clean strainer screen
after first 100 hours and
--- every 2000 hours or 12
months intervals
thereafter.
RT770E
Application
• Through fill cap to
FULL mark on
dipstick
• Filter located on
left side of frame
beneath radiator
Through fill pipe to
FULL mark on
dipstick
See Service Manual
Close shutoff valves.
Unscrew hex plug to
clean filter.
