POWER TRAIN
1
7841
Item
1 Air Cleaner Assembly
2 Mounting Bracket
3 Clamp
4 Service (Restriction) Indicator
5 Reducer
6 Clamp
7 Muffler Clamp
8 Mounting Bracket
7-10
2
3
5
4
6
7
Air Intake Installation - Typical
Description
Published 11/26/2014, Control # 447-05
8
9
6
10
Item
9 Air intake Tube
10 Adapter
11 Bracket
12 Air Intake Tube
13 Elbow
14 T-bolt clamp
15 Adapter
RT770E
14
15
7
12
11
FIGURE 7-3
Description
14
13
6
