RT770E
Replace any parts showing excessive wear and any spring
whose length is shorter than the minimum shown in the
applicable hoist Service Manual.
Reassemble the brake and hoist and repeat the above steps.
When testing is complete, reattach the brake release line to
the brake release port.

HOIST TO BOOM ALIGNMENT

Preparation

Boom alignment must be completed before attempting hoist
alignment Figure 5-5. If the hoist is not properly aligned, the
cable can be damaged or fine control could be affected.
The crane must be set on outriggers fully extended and the
crane must be leveled. The boom must be over the front.

Tools Required

Two foot square
Mason cord
Chalk
Protractor
Procedure
The hoist mounting location will determine the alignment
procedure used. Shift one side of the hoist back or forward to
align the hoist with the boom sheave for cranes that have the
hoist mounted either directly to the boom or on a mount
attached to the boom. It may be necessary to shim under
one side of the hoist to make it level.
The hoist must be checked in two directions, one at 0 degree
and the other is above 45 degrees boom angle on any crane
that the hoist is not mounted directly to the boom, stationary
mounted.
Check the hoist at 0 degree to see if the hoist is aligned to
the boom nose sheave. The main hoist is aligned to the right
hand sheave and the auxiliary hoist is aligned to the center
sheave.
NOTE:
The hoist cable will have gaps in it during spooling
if the alignment is not correct.
NOTE:
The hoist is not level if the cable is piling up on one
side of the drum.
1.
The boom must be extended one half of full extension on
all hoist alignments. This length is used because when
the main hoist cable is positioned on the top right hand
boom nose sheave, the cable must leave the center of
GROVE
the drum at a 90 degree angle. The boom has the ability
to extend, retract, and change the angle of departure
from the drum. Extend the boom half way to provide a
center point of adjustment to check the fleet angle of the
cable.
2.
All the cable must be removed from the hoist drum to
check the fleet angle. Using mason cord or cat gut
fishing line you will be able to pull the line tight to make
an accurate measurement of the fleet angle. Find the
centerline of the hoist drum by using a square and
drawing a line horizontal on the drum. Put a line vertical
to the horizontal line in the absolute center of the drum
by using a tape measure. With the boom at 0 degree, tie
the line tight to the boom nose and have it in the center
of the right hand boom nose sheave.
NOTE:
3.
Tie the line around the hoist drum so that the line is very
tight and the line is crossing the absolute center of the
drum at the centerline mark you put on the drum.
4.
Using a protractor, lay it on the vertical line on the hoist
drum so the string line is in the center of the protractor.
The string line will be at the 90 degree mark on the
protractor if the hoist is straight with the boom nose
sheave. If it is not at the 90 degree mark, the hoist
mounting bolts will have to be loosened and the hoist
moved so it is.
NOTE:
Do not alter holes or stop blocks on the crane mounting
plate, as very small adjustments result in large angular
changes. Extreme care should be taken to avoid over-
correction. Damage to the hoist or wire rope may result.
5.
Elevate the boom above 45 degrees boom angle to
check if the hoist is level. Reposition the hoist drum and
tighten the cord so you can have the cord in the center of
the protractor at the 90 degree mark. If the cord is not at
the 90 degree mark, the hoist will have to be shimmed
until the cord is at the 90 degree mark.
NOTE:
Published 11/26/2014, Control # 447-05
HOIST AND COUNTERWEIGHT
If this special equipment is not available, sufficient
accuracy in locating a centerline may be obtained
by using a steel square against the machine's inner
surfaces of both flanges. It is advisable to avoid
using any cast surfaces in this procedure unless a
check from both flanges indicates that the resultant
line is straight.
This test is for cable leaving gaps while spooling.
CAUTION
This test is for cable piling up on one side of the
hoist drum.
5
5-9
