BOOM
20. Remove the four nuts (75) and two flat washers (74)
securing the two bolts (76), which pass through the
anchor plate (73), to the rear of tele 1 (2) (see
Figure 4-4).
60
74 75 76
8008-31
21. Remove the five bolts (62) and flat washers (61)
securing the trunnion plate (60) to the inside of tele 1 (2)
(left and right sides) (see Figure 4-4).
22. Slightly extend tele 2 (3).
23. Using an adequate lift and sling, slightly raise the front of
tele 2 (3) for the purpose of removing the wear pads
from the front of tele 1 (2).
24. Remove the three bolts (19), six flat washers (16), three
lock washers (17), and three nuts (18) securing the
keeper plate (15) to the front of tele 1 (2) (left and right
sides).
25. Remove the two bolts (27) and nuts (28) securing the
upper wear pad (11) to the front of tele 1 (2) (left and
right sides).
26. Remove the two bolts (69), four flat washers (67), and
two nuts (18) securing the anchor plate (64) to the top of
tele 1 (2) (see Figure 4-5).
4-14
61 62
27. Remove the nuts (66) securing the anchor plate (64) to
FIGURE 4-4
28. Remove the four tele 3 retract cables (65) from the slots
29. Slightly lower the front of tele 2 (3).
30. Remove the two bolts (58), four washers (16), two lock
31. Remove the bolts (19), flat washers (16), lock washers
32. Remove the front lower wear pads (54, 55) and shims
33. Remove tele 2 (3) from tele 1 (2); set tele 2 (3) on
Published 11/26/2014, Control # 447-05
RT770E SERVICE MANUAL
8008-30
the studs of the retract anchor weldment (63) (see
Figure 4-6).
63
64
66
8008-29
of the retract anchor weldment (63) (see Figure 4-54).
washers (17), and two nuts (18) securing the stop block
(56) and shim (57) to the front of tele 1 (2) (left and right
sides).
(17), and nuts (18) securing the left, right, and bottom
keeper plates (2x-14, 13) to the front of tele 1 (2).
(53) from the bottom of tele 1 (2).
adequate supports.
64 2
FIGURE 4-5
65
FIGURE 4-6
