BOOM
Detail B
3
Item
1
Capscrew
2
Locknut
3
Shaft
4
Capscrew (2)
4-44
1
2
A
Description
Published 11/26/2014, Control # 447-05
6
4, 5
8
B
Item
5
Washer (2)
6
Stop Plate
7
Shaft
8
Grease Fitting (2)
RT770E SERVICE MANUAL
Detail A
8
FIGURE 4-60
Description
7
