RT770E
8. Secure the radiator return tube to the top of the engine
using nuts, washers and a muffler clamp.
9. Reconnect the charge air cooler (CAC) tubes to the
radiator using hose
recommended installation torque of the spring loaded
hose clamp is 11.3 Nm (100 lb-in). Do not compress
spring completely, clamp may be damaged from thermal
expansion of CAC tube.
10. Secure the charge air cooler tubes with nuts, washers
and muffler clamps to the left and right side of the fan
shroud.
11. Tighten the drain cock at the bottom of the radiator.
12. Install the hood assembly.
13. Mount the surge tank to the side of the engine hood
using the capscrews, washers, flatwashers and nuts.
14. Connect the hoses between the surge tank and engine
and the surge tank and the radiator.
GROVE
clamps and bellows. The
Published 11/26/2014, Control # 447-05
15. Install the capscrews, nuts and washers holding the rear
engine hood panel to the engine hood.
16. Install the transmission filter to the mounting bracket on
the left side of the engine hood.
17. Connect the air filter tubing at the engine and air cleaner.
18. Connect the hourmeter wiring.
19. Install the hood top door assembly.
20. Fill the radiator per the following instructions.
21. Start the engine, operate all systems and check for
leaks. Make any repairs needed.

Radiator Fill and Servicing

Refer to Lubrication, page 9-1 for complete fill and service
procedures.
POWER TRAIN
7
7-21
