Manitowoc Grove RT770E Service Maintenance Manual page 353

RT770E
Item Description
1 Pivot Shaft
2 Boom Extension Pins, Clips
3 Boom Nose Pins, Clips
4 Hook Block/Headache Ball
5 Boom Extension Hanger Hardware
6 Hose Connections inside turntable
All Hardware, Clips, Pins, Hose Connections
7
not painted O/R Pins, Clips
8 Turntable Bearing Fasteners
9 O/R Hose Connections
10 Hookblock Tiedown Cable
GROVE
Item
11 O/R Pins, Clips
12 O/R Beam Wear Pad Adjustment Hardware
13 Entire underside of unit
14 Powertrain Hardware Inside Compartment
15 Valve Bank
16 Hoist Hose Connections
17 Tension Spring
18 Wire Rope
19 Counterweight Mounting Hardware
20 Counterweight Pins
21 Hose Connections
22 Mirror Mounting Hardware
