INTRODUCTION
Description
Sub: Removable Ctwt System
Sub: Add'l Hoist Access Platform Weight w/
Removable Counterweight
Sub: Cwt Stand on Front O/R Box w/
Removable Counterweight
Sub: Aux Hoist (replace IPO Cwt with Aux
Hoist and Cable)
Rem: Removable Counterweight System -
Ctwt only
Rem: Main Hoist Cable (198 m (650 ft) of 3/4
in 6x37)
Rem: Aux Hoist Cable (153 m (502 ft) of 3/4
in 35x7)
Sub: Optional Cable on Main Hoist (199 m
(653 ft) of 3/4 in 35x7)
Sub: Tier 3 Engine
Sub: Kaydon Bearing
1-6
CG From Rear
Axle cm (in)
Substitutions, Deletions, and Removals from Basic Unit Weight
229.13 (90.21)
-213.82 (-84.18)
553.72 (218.00)
-143.00 (-56.30)
-138.84 (-54.66)
-66.04(-26.00)
-149.86 (-59.00)
-66.04 (-26.00)
-35.56 (-14.00)
208.28 (82.00)
