ELECTRICAL SYSTEM
Ignition key switch is in the ACC and RUN positions.
ACC Relay #2 is not energized while in START position.
1
2
Item
1 Power Relay (K301)
2 Start Relay (K303)
3 Grid Heater Relay (K302)
4 250 Amp Fuse (F53)
5 100 Amp Fuse (F54)
6 100 Amp Fuse (F55)
7 100 Amp Fuse (F56)
8 100 Amp Fuse (F52)
9 250 Amp Fuse (F51)
10 Fuse and Relay Panel (see Figure 3-7)
3-6
7
6
9
5
3
Description
FIGURE 3-6
Published 11/26/2014, Control # 447-05
.
8
8
9
4
10
Item
1 ECM, 30 Amp Fuse (F1)
2 Cranestar, 5 Amp Fuse (F2)
3 Carrier, Rear Module, 25 Amp Fuse (F3)
4 Carrier, Rear Module, 30 Amp Fuse (F4)
5 Carrier, Front Module, 30 Amp Fuse (F5)
6 Power Control Relay, 5 Amp Fuse (F6)
7 120 Ohm Resistor, Starter Lockout Circuit
8 Relay KC1, Power Control Relay
9 Relay KC2, Remote Crank Relay
RT770E SERVICE MANUAL
1
2
3
4
5
6
7
7860
Description
FIGURE 3-7
