system unit front panel controls

Figure 1-1 shows the location of the system unit front panel controls.

Figure 1-1. System Unit Front Panel Controls

System
LCD Display
System
Power Switch
Storage
Devices

system LCD

The Liquid Crystal Display (LCD) is located on the left side of the front panel. The LCD
displays 2-lines of information, with up to 16-characters per line. It displays messages
about the state of the system, including error codes. Figure 1-2. on page 22, describes the
symbols representing the different system activities. For information about error codes,
refer to Chapter 3 , "troubleshooting," on page 47.
Chapter 1
product information
system unit front panel controls
Security
Lock
