HP Visualize c3650 Supplementary Manual page 88

field replaceable units
WARNING For all removal and replacement procedures in this chapter, you
must power off the workstation and unplug the workstation power
cord from the AC power outlet.
NOTE To maintain FCC/EMI compliance, verify that all covers are replaced and
that all screws are properly seated.
Use the following tools to remove or replace FRUs:
• Torx T-10 driver
• Torx T-15 driver
• Light duty flat blade screw driver with 6-inch (150mm) blade
• Needle-nose pliers
• ESD equipment (see "electrostatic discharge (ESD) precautions" on page 196)
• Pen knife
NOTE To maintain FCC/EMI compliance, verify that all covers are replaced and
that all gasket material is intact.
Figure 4-1. shows an exploded view of the internal components (FRUs) in the HP
workstation c-class.
Refer to this figure for the locations of the various workstation FRUs while performing the
FRU removal and replacement procedures in this chapter.
88 Chapter 4
