HP Visualize c3650 Supplementary Manual page 66

troubleshooting
selftest failures
Table 3-2. Chassis Codes for th HP Workstation C-Class
Ostat Code FRU
FLT 3n09 SYS BD
WRN 3n1A SYS BD
TST 3n1B SYS BD
WRN 3n1B SYS BD
FLT 3n1B SYS BD
TST 3n1C SYS BD
WRN 3n1C SYS BD
FLT 3n1C SYS BD
INI 3n2s SYS BD
FLT 3nBC IO BD
TST 3nBC IO BD
INI 3nBC SYS BD
FLT 3nCD IO BD
TST 3nCD SYS BD
INI 3nCD SYS BD
FLT 3nCD SYS BD
FLT 3nEC SYS BD
FLT 3nF4 SYS BD
FLT 3nFC SYS BD
TST 4n00 SYS BD
66
Message
bad sys mde byte
hversion mismtch
chck model strng
model str msmtch
fatal model str
test software ID
update sw ID
update sw ID err
Invoke LDB: s
tick timeout
test sys clocks
init sys clocks
RTC tick timeout
check defaults
init defaults
init EEPROM err
bad sys config
EEPROM boot limt
bad sys bd id
CPU n start lst
Description
CPU n detected an unsupported system
mode.
Stable store hardware version doesn't
match system.
Check model string with version in stable
store.
Model string doesn't match that in stable
store.
Error reading model string from stable
store.
Check LANIC address.
Update LANIC address.
Error updating LANIC address.
CPU n is awaiting the low-level debugger
for s more seconds.
The real-time clock is ticking too slowly or
not at all.
CPU n is verifying processor clocks with
the real-time clock.
CPU n has initialized the processor clocks.
The real time clock is ticking too slowly or
not at all.
CPU n is initializing stable store values to
system defaults.
CPU n finished initializing stable store
values.
CPU n detected an error writing to stable
store.
CPU n detected an illegal CPU board
configuration.
CPU n detected a fatal error writing the
EEPROM.
CPU n cannot identify CPU board.
CPU n is starting its late (with memory)
self-tests.
Chapter 3
