Figure 4-24. Removing the CD Drive Bracket and Blank
5. Read the CAUTION statement at the beginning of this section. Next remove the CD
Drive from its shipping container, and using the four T-10 screws mount the disk drive
to the bracket as shown in Figure 4-24.
Chapter 4
Blank Filler Screws
(T-10 Torx Screws)
field replaceable units
FRU removal and replacement
CD Drive Bracket
Blank
Bracket
Bracket Screws
