Figure 4-20. Removing the Fan and Speaker from the I/O Area
Speaker Cable
Clips
Fan Power
Cable
Bracket
CD Drive Chassis
5. To remove the speaker from the mounting bracket, push a finger through the access
hole and spread the two retaining clips. The speaker will pop free of the mounting clips.
Figure 4-21. Removing the Fan and Speaker from the Bracket
Speaker
Mounting
Clip
Speaker
Cable
Speaker
Chapter 4
Fan
Bracket Stop
Bracket Mounting Clip
field replaceable units
FRU removal and replacement
Speaker
Bracket Mounting
Clip
Mounting Clip
Retainer Hole
Fan
Power Cable
Channel
Mounting
Bracket
Fan
Mounting
Clip
Fan Key
115
