TABLE OF CONTENTS INTRODUCTION ..........................9 GETTING TO KNOW YOUR VEHICLE ..................13 GETTING TO KNOW YOUR INSTRUMENT PANEL ............95 SAFETY ............................118 STARTING AND OPERATING ....................167 IN CASE OF EMERGENCY ...................... 211 SERVICING AND MAINTENANCE ..................241 TECHNICAL SPECIFICATIONS .................... 286 MULTIMEDIA ..........................
Page 4 INTRODUCTION HEAD RESTRAINTS ..........31 SENTRY KEY............19 Key Programming ..........20 Front Head Restraint Adjustment ....31 INTRODUCTION ............9 Replacement Keys ...........20 Rear Head Restraint Adjustment ....31 HOW TO USE THIS MANUAL ........ 10 General Information.........20 Front Head Restraint Removal......32 Essential Information........10 VEHICLE SECURITY ALARM ........20 Rear Head Restraint Removal......32 Symbols.............10...
Page 5 GARAGE DOOR OPENER — IF EQUIPPED ..68 EXTERIOR LIGHTS ..........39 CLIMATE CONTROLS ..........47 Multifunction Lever ..........39 Manual Climate Control Overview ....47 Before You Begin Programming HomeLink® ... 69 Headlight Switch..........39 Automatic Climate Control Overview ....55 Programming A Rolling Code......69 Headlights............40 Automatic Temperature Control (ATC) —...
Page 6 TRI-FOLD TONNEAU COVER — IF EQUIPPED ..89 WARNING LIGHTS AND MESSAGES ....109 OCCUPANT RESTRAINT SYSTEMS ....129 Tri-Fold Tonneau Cover Removal ....89 Red Warning Lights........109 Occupant Restraint Systems Features ..129 Tri-Fold Tonneau Cover Installation ....91 Yellow Warning Lights ........111 Important Safety Precautions ......
Page 7 STARTING AND OPERATING PARKSENSE FRONT AND REAR LIMITED-SLIP DIFFERENTIAL ......180 FUEL SAVER TECHNOLOGY — 5.7L ENGINES PARK ASSIST ............187 STARTING THE ENGINE ........167 ONLY (IF EQUIPPED) ........... 180 ParkSense Sensors........187 Automatic Transmission ....... 167 ParkSense Warning Display ......188 POWER STEERING ..........
Page 8 IN CASE OF EMERGENCY TRAILER TOWING ..........195 MANUAL PARK RELEASE — 8 - SPEED Common Towing Definitions......195 TRANSMISSION ...........236 HAZARD WARNING FLASHERS ......211 Trailer Hitch Type and Maximum Trailer FREEING A STUCK VEHICLE ......237 ASSIST AND SOS MIRROR — IF EQUIPPED ..211 Weight ............
Page 9 DEALER SERVICE ..........248 DEPARTMENT OF TRANSPORTATION UNIFORM FUEL REQUIREMENTS ........287 Engine Oil — Gas Engine ......248 TIRE QUALITY GRADES ........280 3.6L Engine ........... 287 Engine Oil Filter ..........250 5.7L Engine ........... 287 Treadwear............280 Engine Air Cleaner Filter ......250 Reformulated Gasoline ........
Page 10 CUSTOMER ASSISTANCE SAFETY AND GENERAL INFORMATION ....318 RADIO OPERATION AND MOBILE PHONES ..337 Safety Guidelines .......... 318 Regulatory And Safety Information ....337 SUGGESTIONS FOR OBTAINING SERVICE FOR UCONNECT 3.0 .............319 UCONNECT VOICE RECOGNITION QUICK TIPS ...338 YOUR VEHICLE ............344 Introduction ...........
Page 11: Introduction
INTRODUCTION INTRODUCTION Dear Customer, congratulations on selecting your new vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality. This is a specialized utility vehicle. It can go places and perform tasks that are not intended for conventional passenger vehicles. It handles and maneuvers differently from many passenger vehicles both on-road and off-road, so take time to become familiar with your vehicle.
Page 12: How To Use This Manual
HOW TO USE THIS MANUAL CONSUMER INFORMATION — TRUCK-CAMPER LOADING This information is provided in fulfillment of the requirement by the United SSENTIAL NFORMATION States Government, Department of Transportation, National Highway Traffic Consult the Table of Contents to determine which section contains the Safety Administration, that “every manufacturer of trucks that are capable of information you desire.
Page 13 NOTE: The camper Center of Gravity falls within the specified zone. A — Forward Limit of Camper CG B — Rearward Limit of Camper CG...
Page 14: Warnings And Cautions
WARNINGS AND CAUTIONS When the truck is used to carry a slide-in camper, the total cargo load of the truck consists of the manufacturer’s camper weight figure, the weight of This Owner’s Manual contains WARNINGS against operating procedures that installed additional camper equipment not included in the manufacturer’s could result in a collision, bodily injury and/or death.
Page 15: Getting To Know Your Vehicle
GETTING TO KNOW YOUR VEHICLE VEHICLE USER GUIDE — IF EQUIPPED NOTE: Features/Benefits Vehicle User Guide features are not available while Pre-installed on your Uconnect touchscreen  Access your Owner’s Information right through your the vehicle is moving. If you try to access while the radio Uconnect 4C or 4C NAV touchscreen system (if vehicle is in motion, the system will display the...
Page 16: Keys
GETTING TO KNOW YOUR VEHICLE KEYS The emergency key allows for entry into the vehicle using a key fob with integrated key. The key fob should the battery in the vehicle or the key fob does not need to be pointed at the vehicle to become depleted.
Page 17 GETTING TO KNOW YOUR VEHICLE To Lock The Doors And Tailgate Using The Panic Alarm Do not touch the battery terminals that are on  the back housing or the printed circuit board. Push and release the lock button on the key fob to To turn the Panic Alarm feature on or off, push the 1.
Page 18 GETTING TO KNOW YOUR VEHICLE Programming Additional Key Fobs 3. Remove the battery by turning the back cover over (battery facing downward) and tapping it Programming the key fob may be performed by an lightly on a solid surface such as a table or authorized dealer.
Page 19: Ignition Switch
GETTING TO KNOW YOUR VEHICLE IGNITION SWITCH Le présent appareil est conforme aux CNR GNITION EMINDER d`Innovation, Science and Economic Development Opening the driver's door when the key fob is in the applicables aux appareils radio exempts de (IGNM) — GNITION ODULE ignition with the ignition switch in the OFF or ACC...
Page 20: Remote Start Abort Message
GETTING TO KNOW YOUR VEHICLE System not disabled from previous remote start The instrument cluster display message stays  EMOTE TART event active until the ignition is placed in the ON/RUN ITHOUT RIVING EHICLE position. Vehicle security alarm not active ...
Page 21: General Information
GETTING TO KNOW YOUR VEHICLE NOTE: 1. l'appareil ne doit pas produire de brouillage, only key fobs that are programmed to the vehicle The Remote Start Comfort System can be acti- can be used to start and operate the vehicle. The system cannot reprogram a key fob obtained from vated and deactivated through the Uconnect 2.
Page 22: Key Programming
GETTING TO KNOW YOUR VEHICLE La operación de este equipo está sujeta a las All of the key fobs provided with your new vehicle ENERAL NFORMATION have been programmed to the vehicle electronics. siguientes dos condiciones: The following regulatory statement applies to all 1.
Page 23: To Arm The System
GETTING TO KNOW YOUR VEHICLE YSTEM ISARM YSTEM EARMING YSTEM Follow these steps to arm the vehicle security The vehicle security alarm can be disarmed using The vehicle security alarm will rearm itself after the alarm: any of the following methods: 15 additional minutes of headlights and vehicle security light flashing, if the system has not been 1.
Page 24: Power Door Locks - If Equipped
GETTING TO KNOW YOUR VEHICLE — I OWER OCKS QUIPPED WARNING! The power door lock switches are on each front Before exiting a vehicle, always shift the auto-  door trim panel. Use these switches to lock or matic transmission into PARK or REVERSE, unlock the doors.
Page 25: Keyless Enter-N-Go - Passive Entry - If Equipped
GETTING TO KNOW YOUR VEHICLE If you push the power door lock switch while the The vehicle security alarm can be armed/ NOTE:  key fob is in the ignition, and any front door is open, disarmed by pushing the Passive Entry key fob If “Unlock All Doors 1st Press”...
Page 26 GETTING TO KNOW YOUR VEHICLE General Information Passive Entry key fobs. If one of the vehicle's Passive Entry key fobs is detected inside the The following regulatory statement applies to all vehicle, and no other valid Passive Entry key fobs Radio Frequency (RF) devices equipped in this are detected outside the vehicle, the Passive Entry vehicle:...
Page 27: Automatic Door Locks -If Equipped
GETTING TO KNOW YOUR VEHICLE La operación de este equipo está sujeta a las Automatic Doors Unlock Programming — siguientes dos condiciones: If Equipped 1. es posible que este equipo o dispositivo no The Automatic Doors Unlock feature can be cause interferencia perjudicial y enabled or disabled as follows: 2.
Page 28: Seats
GETTING TO KNOW YOUR VEHICLE While sitting in the seat, pull up on the handle and WARNING! WARNING! slide the seat forward or rearward. Release the bar once you have reached the desired position. Then, Avoid trapping anyone in a vehicle in a collision. Do not allow people to ride in any area of your ...
Page 29: Manual Rear Seat Adjustment
GETTING TO KNOW YOUR VEHICLE 40-20-40 Front Bench Seat — If Equipped The seat is divided into three segments. The outboard seat portions are each 40% of the total width of the seat. On some models, the back of the center portion (20%) easily folds down to provide an armrest/center storage compartment.
Page 30 GETTING TO KNOW YOUR VEHICLE Tilting The Seat Up Or Down CAUTION! The angle of the seat cushion can be adjusted in Do not place any article under a power seat or four directions. Pull upward or push downward on impede its ability to move as it may cause the front or rear of the seat switch, the front or rear damage to the seat controls.
Page 31: Power Passenger Seat Adjustment
GETTING TO KNOW YOUR VEHICLE — I OWER ASSENGER EATED EATS QUIPPED Press the heated seat button once to turn  the HI setting on. — I DJUSTMENT QUIPPED On some models, the front and rear seats may be equipped with heaters located in the seat cushions Press the heated seat button a second time ...
Page 32: Ventilated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE NOTE: If your vehicle is not equipped with a touchscreen, If your vehicle is equipped with a touchscreen, the this feature can be programmed through the front ventilated seats control buttons are also Once a heat setting is selected, heat will be felt ...
Page 33: Plastic Grocery Bag Retainers
GETTING TO KNOW YOUR VEHICLE LASTIC ROCERY ETAINERS WARNING! EGULAR ODELS All occupants, including the driver, should not  Retainer hooks which will hold plastic grocery bag operate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper handles are built into the back panel of the cab, positions in order to minimize the risk of neck behind the rear seat.
Page 34: Front Head Restraint Removal
GETTING TO KNOW YOUR VEHICLE RONT ESTRAINT EMOVAL ESTRAINT EMOVAL To remove the head restraint, raise it up as far as To remove the head restraint, push the adjustment it can go. Then, push the adjustment button and button and the release button while pulling upward the release button at the base of each post while on the whole assembly.
Page 35: Steering Wheel
GETTING TO KNOW YOUR VEHICLE STEERING WHEEL Press the heated steering wheel button once  WARNING! to turn the heating element on. Do not adjust the steering column while driving. TEERING OLUMN Press the heated steering wheel button  Adjusting the steering column while driving or second time to turn the heating element off.
Page 36: Driver Adjustable Pedals -If Equipped
GETTING TO KNOW YOUR VEHICLE NOTE: WARNING! Always adjust the pedals to a position that  Do not place anything on the steering wheel allows full pedal travel.  that insulates against heat, such as a blanket Further small adjustments may be necessary to ...
Page 37: Mirrors
GETTING TO KNOW YOUR VEHICLE MIRRORS — UTOMATIC IMMING IRROR CAUTION! QUIPPED — To avoid damage to the mirror during cleaning, NSIDE IGHT IRROR The mirror head can be adjusted up, down, left, never spray any cleaning solution directly onto QUIPPED the mirror.
Page 38: Outside Mirrors
GETTING TO KNOW YOUR VEHICLE WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side convex mirror could cause you to collide with another vehicle or other object.
Page 39: Power Folding Outside Mirrors For Standard And Trailer Tow -If Equipped
GETTING TO KNOW YOUR VEHICLE NOTE: The power fold mirrors are designed to operate  while the vehicle is stationary or traveling at moderate speeds. If you attempt to power fold the mirrors at high speeds they may not fully open or close.
Page 40: Trailer Towing Mirrors -If Equipped
GETTING TO KNOW YOUR VEHICLE — NOTE: IRRORS EVERSE CAUTION! Fold the trailer towing mirrors rearward prior to QUIPPED entering an automated car wash. It is recommended to fold the mirrors into the full rearward position to resist damage when Tilt Side Mirrors In Reverse provides automatic A small blindspot mirror is located next to main entering a car wash or a narrow location.
Page 41: Exterior Lights
GETTING TO KNOW YOUR VEHICLE EADLIGHT WITCH The headlight switch is located on the left side of the instrument panel, next to the steering wheel. The headlight switch controls the operation of the headlights, parking lights, instrument panel lights, cargo lights and fog lights (if equipped). Illuminated Vanity Mirror “Slide-On-Rod”...
Page 42: Headlights
GETTING TO KNOW YOUR VEHICLE (DRL ) — To minimize the possibility of scratching the lenses mirror. This camera detects vehicle specific light AYTIME UNNING IGHTS and reducing light output, avoid wiping with a dry and automatically switches from high beams to low QUIPPED cloth.
Page 43: Flash-To-Pass
GETTING TO KNOW YOUR VEHICLE To Activate LASH ARKING IGHTS ANEL IGHTS 1. The Automatic High Beams are enabled You can signal another vehicle with your headlights To turn on the parking lights and through the Uconnect system. Refer to by lightly pulling the multifunction lever toward you.
Page 44: Headlight Delay
GETTING TO KNOW YOUR VEHICLE NOTE: EADLIGHT ELAY If either light remains on and does not flash, or To aid in your exit, your vehicle is equipped with a there is a very fast flash rate, check for a defective headlight delay that will leave the headlights on for outside light bulb.
Page 45: Battery Saver
GETTING TO KNOW YOUR VEHICLE If the vehicle’s speed is 0 mph (0 km/h), these NOTE: lights can also be turned on using the switch Battery saver mode is canceled if the ignition is ON. located just inside the pickup box. A telltale will If the headlights remain on while the ignition is illuminate in the instrument cluster display when placed in the OFF position, the exterior lights will...
Page 46 GETTING TO KNOW YOUR VEHICLE NOTE: Dimmer Control The courtesy/reading lights will remain on until the The brightness of the instrument panel as well as switch is pushed a second time, so be sure they the ambient lighting can be regulated by rotating have been turned off before exiting the vehicle.
Page 47: Illuminated Approach
GETTING TO KNOW YOUR VEHICLE Parade Mode The illuminated entry system will not operate if the Rotate the end of the lever upward, to the first dimmer control is in the “Dome OFF” position detent past the intermittent settings for low-speed When the headlights are on you can supplement (rotate vertical thumb wheel all the way to the wiper operation.
Page 48: Rain Sensing Wipers - If Equipped
GETTING TO KNOW YOUR VEHICLE resume the intermittent interval previously the windshield. The wash function must be used in The Rain Sensing feature may not function prop-  selected. If the washer knob is pushed while in the order to spray the windshield with washer fluid. erly when ice, or dried salt water is present on off position, the wiper will turn on and cycle the windshield.
Page 49: Climate Controls
GETTING TO KNOW YOUR VEHICLE CLIMATE CONTROLS ANUAL LIMATE ONTROL VERVIEW The Climate Control System allows you to regulate the temperature, air flow, and direction of air circulating throughout the vehicle. The controls are located on the touchscreen (if equipped) and on the instrument panel below the radio.
Page 50 GETTING TO KNOW YOUR VEHICLE Icon Description Temperature Control Temperature Control regulates the temperature of the air forced through the Climate Control system. The temperature increases as you turn the temperature control knob clockwise. The temperature decreases as you turn the temperature control knob counterclockwise.
Page 51 GETTING TO KNOW YOUR VEHICLE Icon Description Floor Mode Floor Mode Air comes from the floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. Mix Mode Mix Mode Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the windshield.
Page 52 GETTING TO KNOW YOUR VEHICLE Uconnect 4C/4C NAV With Manual Temperature Controls...
Page 53 GETTING TO KNOW YOUR VEHICLE Icon Description MAX A/C Button Press and release the MAX A/C button on the touchscreen to change the current setting to the coldest output of air. The MAX A/C indicator illuminates when MAX A/C is on. Pressing the button again will cause the MAX A/C operation to exit. NOTE: The MAX A/C button is only available on the touchscreen.
Page 54 GETTING TO KNOW YOUR VEHICLE Icon Description Temperature Control Provides the driver and passenger with independent temperature control. Push the red button on the faceplate or touchscreen or press and slide the temperature bar towards the red arrow button on the touchscreen for warmer temperature settings. Push the blue button on the faceplate or touchscreen or press and slide the temperature bar towards the blue arrow button on the touchscreen for cooler temperature settings.
Page 55 GETTING TO KNOW YOUR VEHICLE Icon Description Panel Mode Panel Mode Selecting this mode from the touchscreen causes air to flow from the outlets in the instrument panel. Each of these outlets can be individually adjusted to direct the flow of air. The air vanes of the center outlets and outboard outlets can be moved up and down or side to side to regulate airflow direction.
Page 56 GETTING TO KNOW YOUR VEHICLE Icon Description Faceplate OFF Button Climate Control OFF Button Touchscreen OFF Button Press and release the OFF button on the touchscreen, or push the OFF button on the faceplate to turn the Climate Control ON/OFF.
Page 57: Automatic Climate Control Overview
GETTING TO KNOW YOUR VEHICLE UTOMATIC LIMATE ONTROL VERVIEW Uconnect 3 With 5–inch Display With Automatic Temperature Controls...
Page 58 GETTING TO KNOW YOUR VEHICLE Uconnect 4C/4C NAV With Automatic Temperature Controls...
Page 59 GETTING TO KNOW YOUR VEHICLE NOTE: Icons and descriptions can vary based upon vehicle equipment. Icon Description MAX A/C Press and release the MAX A/C button on the touchscreen to change the current setting to the coldest output of air. The MAX A/C indicator illuminates when MAX A/C is on.
Page 60 GETTING TO KNOW YOUR VEHICLE Icon Description Faceplate AUTO Button AUTO Button Set your desired temperature and press AUTO. AUTO will achieve and maintain your desired temperature by automatically adjusting the blower speed and air distribution. AUTO mode is highly recommended for efficiency. You can press and release this button on Touchscreen AUTO the touchscreen, or push the button on the faceplate, to turn AUTO on.
Page 61 GETTING TO KNOW YOUR VEHICLE Icon Description Uconnect 3 Driver and Passenger Temperature Up and Down Buttons Provides the driver and passenger with independent temperature control. Push the up arrow button on the faceplate, press the up arrow button on the touchscreen, or press and slide the temperature bar towards the red arrow button on the touchscreen for Uconnect 4C/4C NAV warmer temperature settings.
Page 62 GETTING TO KNOW YOUR VEHICLE Icon Description Faceplate Blower Knob Blower Control Blower Control regulates the amount of air forced through the climate system. There are seven blower speeds available. The speeds can be selected using either the blower control knob on the faceplate or the buttons on the touchscreen. Touchscreen Blower Faceplate: The blower speed increases as you turn the blower control knob clockwise from the lowest blower setting.
Page 63 GETTING TO KNOW YOUR VEHICLE Icon Description Bi-Level Mode Bi-Level Mode Air comes from the instrument panel outlets and floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the floor outlets.
Page 64: Automatic Temperature Control (Atc)
GETTING TO KNOW YOUR VEHICLE Winter Operation The temperature can be displayed in U.S. or UTOMATIC EMPERATURE ONTROL  Metric units by selecting the U.S./Metric (ATC) — I To ensure the best possible heater and defroster QUIPPED customer-programmable feature. Refer to the performance, make sure the engine cooling “Uconnect Settings”...
Page 65: Windows
GETTING TO KNOW YOUR VEHICLE WINDOWS Operating Tips Chart CAUTION! WEATHER CONTROL SETTINGS — I Failure to follow these cautions can cause OWER INDOWS QUIPPED damage to the heating elements: Set the mode control to Use care when washing the inside of the rear on, and blower ...
Page 66 GETTING TO KNOW YOUR VEHICLE NOTE: To open the window part way, push the switch to WARNING! the first detent and release it when you want the The Key Off Power Delay feature will allow the window to stop. power windows to operate for up to 10 minutes There is no anti-pinch protection when the after the ignition is placed in the OFF position.
Page 67: Wind Buffeting
GETTING TO KNOW YOUR VEHICLE Window Lockout Switch (4–Door Models Power Sliding Rear Window — If Equipped UFFETING Only) The switch for the power sliding rear window is Wind buffeting can be described as the perception located on the overhead console. The window lockout switch on the driver's door of pressure on the ears or a helicopter-type sound in allows you to disable the window control on the...
Page 68: Opening Sunroof
GETTING TO KNOW YOUR VEHICLE Manual Close PENING UNROOF WARNING! Push and hold the switch forward and the sunroof Express Open Never leave children unattended in a vehicle,  will close from any position and stop at the full or with access to an unlocked vehicle. Never Push the switch rearward and release it within closed position.
Page 69: Pinch Protect Feature
GETTING TO KNOW YOUR VEHICLE HOOD INCH ROTECT EATURE This feature will detect an obstruction in the closing of the sunroof during the Express Close operation. If an obstruction in the path of the To open the hood, two latches must be released. sunroof is detected, the sunroof will automatically 1.
Page 70: Tailgate
GETTING TO KNOW YOUR VEHICLE GARAGE DOOR OPENER — IF EQUIPPED CAUTION! WARNING! HomeLink® replaces up to three hand-held To prevent possible damage, do not slam the Your motorized door or gate will open and  transmitters that operate devices such as garage hood to close it.
Page 71: Before You Begin Programming Homelink
GETTING TO KNOW YOUR VEHICLE If you have any problems, or require assistance, 1. Place the ignition switch in the ON/RUN EFORE EGIN ROGRAMMING  please call toll-free 1-800-355-3515 or, on the position. ® Internet at HomeLink.com for information or NOTE: assistance.
Page 72: Programming A Non-Rolling Code
GETTING TO KNOW YOUR VEHICLE Reprogramming A Single HomeLink® NOTE: 5. On the garage door opener (in the garage), locate the “LEARN” or “TRAINING” button. This Button (Rolling Code) It may take up to 30 seconds or longer in  can usually be found where the hanging some cases for the channel to train.
Page 73: Canadian/Gate Operator Programming
GETTING TO KNOW YOUR VEHICLE 2. Place the hand-held transmitter 1 to 3 inches Reprogramming A Single HomeLink® ANADIAN PERATOR (3 to 8 cm) away from the HomeLink® button Button (Canadian/Gate Operator) ROGRAMMING you wish to program. To reprogram a channel that has been previously For programming transmitters in Canada/United 3.
Page 74: Using Homelink
GETTING TO KNOW YOUR VEHICLE ® Push the LEARN button on the garage door SING  ENERAL NFORMATION opener to complete the training for a rolling To operate, push and release the programmed The following regulatory statement applies to all code.
Page 75: Internal Equipment
GETTING TO KNOW YOUR VEHICLE La operación de este equipo está sujeta a las siguientes dos condiciones: 1. es posible que este equipo o dispositivo no cause interferencia perjudicial y 2. este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
Page 76 GETTING TO KNOW YOUR VEHICLE Door Storage WARNING! Front Door Storage — If Equipped This armrest is not a seat. Anyone seated on  Storage areas and bottle holders (driver’s side the armrest could be seriously injured during only) are located in the door trim panels. vehicle operation, or a collision.
Page 77 GETTING TO KNOW YOUR VEHICLE WARNING! Do not operate this vehicle with a console compartment lid in the open position. Driving with the console compartment lid open may result in injury in a collision. The center console is equipped with a front storage bin located next to the cupholders.
Page 78 GETTING TO KNOW YOUR VEHICLE To open in-floor storage bin, lift upward on the handle of the latch and open the lid. NOTE: The front seat may have to be moved forward to fully open the lid. Storage Bin Unfolding The Load Floor Fold Flat Load Floor —...
Page 79 GETTING TO KNOW YOUR VEHICLE Unfolding The Load Floor/Crew Cab 3. Lift the front panel until the load floor unfolds WARNING! into position. 1. Lift the 60/40 seat cushion(s) to the upward Do not drive with the load floor in the up position.
Page 80: Electrical Power Outlets
GETTING TO KNOW YOUR VEHICLE Below Rear Seat Storage (Crew Cab/ The auxiliary power outlets can be found in the LECTRICAL OWER UTLETS following locations: Quad Cab) The auxiliary 12 Volt (13 Amp) power outlets can Lower left and lower right of the center stack ...
Page 81 GETTING TO KNOW YOUR VEHICLE When the vehicle is turned off, be sure to unplug any equipment as to not drain the battery of the vehicle. All accessories connected to the outlet(s) should be removed or turned off when the vehicle is not in use to protect the battery against discharge.
Page 82: Cigar Lighter And Ash Receiver - If Equipped
GETTING TO KNOW YOUR VEHICLE The power inverter is designed with built-in overload CAUTION! WARNING! protection. If the power rating of 150 Watts is exceeded, the power inverter will automatically shut To avoid serious injury or death: Accessories that draw higher power (i.e., ...
Page 83: Pickup Box
For further information on using the auxiliary weight of the load to the pickup box floor or switches, please refer to the Ram Body Builder’s You can carry wide building materials (sheets of vehicle damage may result. The use of proper Guide by accessing www.rambodybuilder.com and...
Page 84: Rambox Integrated Box Side Storage Bins
GETTING TO KNOW YOUR VEHICLE To open a storage bin with the RamBox unlocked, The interior of the RamBox will automatically NTEGRATED push and release the button located on the lid. The illuminate when the lid is opened. In addition to the TORAGE RamBox lid will open upward to allow hand access.
Page 85: Locking And Unlocking Rambox
GETTING TO KNOW YOUR VEHICLE RamBox Storage Bin Cover Emergency OCKING NLOCKING AFETY ARNING Release Lever — If Equipped Push and release the lock or unlock button on the Carefully follow these warnings to help prevent As a security measure, a Storage Bin Cover key fob to lock and unlock all doors, the tailgate personal injury or damage to your vehicle: Emergency Release is built into the storage bin...
Page 86 GETTING TO KNOW YOUR VEHICLE Storage Position 2. With the side gates open, position the 4. Rotate the center handle horizontally to secure extender fully forward in the bed against the the side gates in the closed position. The storage position for the bed extender is at the front panel.
Page 87 GETTING TO KNOW YOUR VEHICLE To install the bed extender into a divider position, 5. Lock the center handle to secure the panel perform the following: into place. 1. Make sure the center handle is unlocked Extender Position using the vehicle key and rotate the center The extender position allows you to load the bed of handle vertically to release the extender side the truck beyond the tailgate.
Page 88: Bed Rail Tie-Down System - If Equipped
GETTING TO KNOW YOUR VEHICLE — I 3. Fit the end of the side gate ends onto the pin YSTEM WARNING! and handle. QUIPPED To reduce the risk of potential injury or property damage: CAUTION! Cargo must be secured.  The maximum load per cleat should not exceed Do not exceed cargo load rating of your ...
Page 89 GETTING TO KNOW YOUR VEHICLE Each cleat must be located and tightened down in Cleat Removal (Standard Box Rail) Cleat Removal (Without Tonneau Cover) one of the detents, along either rail, in order to To remove the cleats from the utility rail, slide the Remove the end cap by pushing upward on the keep cargo properly secure.
Page 90: Easy-Off Tailgate
GETTING TO KNOW YOUR VEHICLE EASY-OFF TAILGATE 2. Remove the connector bracket from the sill by 6. Tape the tailgate harness and bracket against pushing the locking tab in. the forward-facing surface of the tailgate. This To simplify mounting of a camper unit with an will prevent damaging the connector and overhang, the tailgate can be removed.
Page 91: Locking Tailgate
GETTING TO KNOW YOUR VEHICLE TRI-FOLD TONNEAU COVER — IF EQUIPPED 3. Position the tailgate on a 45 degree angle. 4. Raise the right side of the tailgate until the Your vehicle may be equipped with a Tri-Fold right side pivot clears the hanger bracket. Tonneau Cover which consists of different 5.
Page 92 GETTING TO KNOW YOUR VEHICLE NOTE: 3. From the released position, send the clamps to the Stowed Position by pushing from the When folding the center and rear panels, the yellow bumper up. Listen for a “clicking” sound sections MUST be held together to avoid damage to confirm the clamp has been properly to the cover material.
Page 93: Tri-Fold Tonneau Cover Installation
GETTING TO KNOW YOUR VEHICLE NOTE: 9. With two people, remove the Tonneau Cover. Fold the panels gently. It is not recommended to NOTE: allow the panels to drop under their own weight. Be sure the Tonneau Cover has been folded 6.
Page 94 GETTING TO KNOW YOUR VEHICLE NOTE: 3. Push clamp wires up and under the flange of the box (or flange of the Ram Box rail, if Once clamped, be sure the clamps are not equipped) to the semi clamped position.
Page 95 10. Push clamp handles upward to the clamped position to properly engage the clamps. Stowed Position 9. Push clamp wires up and under the flange of box (or flange of Ram Box rail, if equipped) to the semi clamped position. Fully Unfolded Position Clamped Position...
Page 96: Tri-Fold Tonneau Cover Cleaning
GETTING TO KNOW YOUR VEHICLE CAUTION! It is the driver’s responsibility to ensure the Tonneau Cover is properly installed on the vehicle. Failure to follow this procedure can result in detachment of the Tonneau Cover from the vehicle and/or damage to the vehicle/ Tonneau Cover.
Page 97: Getting To Know Your Instrument Panel
GETTING TO KNOW YOUR INSTRUMENT PANEL BASE INSTRUMENT CLUSTER Base Instrument Clusters...
Page 98: Base Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL 5. Temperature Gauge NSTRUMENT LUSTER CAUTION! The temperature gauge shows engine ESCRIPTIONS  Driving with a hot engine cooling system could coolant temperature. Any reading within the damage your vehicle. If the temperature gauge 1.
Page 99: Premium Instrument Cluster
GETTING TO KNOW YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER Premium Instrument Clusters...
Page 100: Premium Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL 3. Oil Pressure Gauge 7. Temperature Gauge REMIUM NSTRUMENT LUSTER The pointer should always indicate some oil The temperature gauge shows engine ESCRIPTIONS   pressure when the engine is running. A coolant temperature. Any reading within the 1.
Page 101: Instrument Cluster Display
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DISPLAY Trip B  Audio  Your vehicle will be equipped with an instrument Trailer Tow  cluster display, which offers useful information to the driver. With the ignition in the OFF mode, Stored Messages ...
Page 102: Oil Life Reset
GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: 2. Push and release the down arrow button to Down Arrow Button  scroll downward through the main menu to Use the steering wheel instrument cluster display Push and release the down arrow “Vehicle Info.”...
Page 103 GETTING TO KNOW YOUR INSTRUMENT PANEL Vehicle Info Trip A / Trip B Audio Push and release the up or down arrow button until Push and release the up or down arrow button until Push and release the up or down arrow button until the Vehicle Info menu item is highlighted in the the Trip menu item is highlighted in the instrument the Audio display icon is highlighted in the...
Page 104 GETTING TO KNOW YOUR INSTRUMENT PANEL Time Time Odometer   Range To Empty Range To Empty No Decimals (Default Setting)    Average MPG Average MPG Decimals    Current MPG Current MPG Restore Defaults   Trip A Distance Trailer Brake Gain Cancel (Default Setting)
Page 105 GETTING TO KNOW YOUR INSTRUMENT PANEL Setting Names Abbreviated Setting Names Submenus (Right Submenu Layer) (Left Submenu Layer) English, Spanish, French, Italian, German, Dutch, Portuguese, Arabic Language Select Language (If Equipped) Units Units US.; Metric Notification — Sound Only; Sound & Display ...
Page 106 GETTING TO KNOW YOUR INSTRUMENT PANEL Setting Names Abbreviated Setting Names Submenus (Right Submenu Layer) (Left Submenu Layer) Sound Horn with Remote Lock Horn w/ Remote Lock Off; 1st Press; 2nd Press Remote Unlock Sequence Remote Unlock Driver Door; All Doors Key Fob Linked to Memory Key in Memory On;...
Page 107 GETTING TO KNOW YOUR INSTRUMENT PANEL Setting Names Abbreviated Setting Names Submenus (Right Submenu Layer) (Left Submenu Layer) Trailer # (# is equal to slot position)  Boat   Cargo  Dump  Equipment  Flatbed  Trailer Name Trailer Name Gooseneck ...
Page 108: Battery Saver On/Battery Saver Mode Message - Electrical Load Reduction Actions - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL Turn Menu Off — If Equipped Load reduction is only active when the engine is The electrical loads that may be switched off (if running. It will display a message if there is a risk equipped), and vehicle functions which can be Push and release the right arrow button to exit the of battery depletion to the point where the vehicle...
Page 109 GETTING TO KNOW YOUR INSTRUMENT PANEL Installing options like additional lights, upfitter What to do when an electrical load reduction After a trip:  electrical accessories, audio systems, alarms action message is present (“Battery Saver On” or Check if any aftermarket equipment was ...
Page 110: Instrument Cluster Display Programmable Features
GETTING TO KNOW YOUR INSTRUMENT PANEL NSTRUMENT LUSTER ISPLAY ROGRAMMABLE EATURES The instrument cluster display can be used to view or change the following settings. Push the up or down arrow button until System Setup displays, then push the right arrow button. Scroll through the settings using the up or down arrow button. Push the right arrow button to change the setting. Push the left arrow button to scroll back to a previous menu or submenu.
Page 111: Warning Lights And Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING LIGHTS AND MESSAGES Refer to “Occupant Restraint Systems” in “Safety” case, the light will remain on until the condition has been corrected. If the problem is related to the for further information. The warning/indicator lights will illuminate in the brake booster, the ABS pump will run when Air Bag Warning Light instrument panel together with a dedicated...
Page 112 GETTING TO KNOW YOUR INSTRUMENT PANEL Engine Coolant Temperature Warning Oil Pressure Warning Light Vehicles equipped with the Anti-Lock Brake System (ABS) are also equipped with Electronic Brake Light This warning light will illuminate to Force Distribution (EBD). In the event of an EBD indicate low engine oil pressure.
Page 113: Yellow Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: Trailer Brake Disconnected Warning Light ELLOW ARNING IGHTS This light may turn on if the accelerator and brake This warning light will illuminate when Engine Check/Malfunction Indicator pedals are pressed at the same time. the Trailer Brake has been Warning Light (MIL) If the light continues to flash when the vehicle is...
Page 114 GETTING TO KNOW YOUR INSTRUMENT PANEL Low Washer Fluid Warning Light — go out with the engine running. If the “ESC WARNING! Indicator Light” comes on continuously with the If Equipped engine running, a malfunction has been detected A malfunctioning catalytic converter, as This warning light will illuminate when in the ESC system.
Page 115 GETTING TO KNOW YOUR INSTRUMENT PANEL Each tire, including the spare (if provided), should Please note that the TPMS is not a substitute for CAUTION! proper tire maintenance, and it is the driver’s be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle responsibility to maintain correct tire pressure, The TPMS has been optimized for the original...
Page 116: Yellow Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL If the ABS light remains on or turns on while not functioning properly and that service is ELLOW NDICATOR IGHTS driving, then the Anti-Lock portion of the brake required. We recommend you drive to the nearest Cargo Light —...
Page 117: Green Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 4WD Lock Indicator Light — If Equipped NEUTRAL Indicator Light — If Equipped NOTE: A continuous chime will sound if the vehicle is This light alerts the driver that the This light alerts the driver that the 4WD ...
Page 118: White Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Stop/Start Active Indicator Light — If any of these systems require service, the OBD II NDICATOR IGHTS system will turn on the Malfunction Indicator Light If Equipped High Beam Indicator Light (MIL). It will also store diagnostic codes and other This indicator light will illuminate when information to assist your service technician in This indicator light will illuminate to...
Page 119: Programs
GETTING TO KNOW YOUR INSTRUMENT PANEL For states that require an Inspection The MIL will flash for about 10 seconds and  WARNING! and Maintenance (I/M), this check then return to being fully illuminated until you verifies the “Malfunction Indicator Light turn OFF the ignition or start the engine.
Page 120: Safety
SAFETY SAFETY FEATURES You also may experience the following when ABS WARNING! activates: (ABS) Pumping of the Anti-Lock Brakes will diminish RAKE YSTEM  The ABS motor noise (it may continue to run for  their effectiveness and may lead to a collision. a short time after the stop) The Anti-Lock Brake System (ABS) provides Pumping makes the stopping distance longer.
Page 121: Electronic Brake Control (Ebc) System
SAFETY Anti-Lock Brake Warning Light Your vehicle may also be equipped with Trailer WARNING! Sway Control (TSC) and Hill Descent Control (HDC). The yellow “Anti-Lock Brake Warning Light” will The Brake Assist System (BAS) cannot prevent Brake System Warning Light turn on when the ignition is placed in the ON/RUN the natural laws of physics from acting on the mode and may stay on for as long as four seconds.
Page 122 SAFETY Electronic Stability Control (ESC) sufficient to potentially cause wheel lift, it then The “ESC Activation/Malfunction Indicator Light” applies the appropriate brake and may also reduce located in the instrument cluster will start to flash The Electronic Stability Control (ESC) system engine power to lessen the chance that wheel lift as soon as the ESC system becomes active.
Page 123 SAFETY Partial Off Full Off — If Equipped WARNING! The “Partial Off” mode is intended for times when This mode is intended for off-highway or off-road Vehicle modifications, or failure to properly  a more spirited driving experience is desired. This use only and should not be used on any public maintain your vehicle, may change the mode may modify TCS and ESC thresholds for...
Page 124 SAFETY and the vehicle has been driven several miles The “ESC OFF Indicator Light” indicates WARNING! (kilometers) at speeds greater than 30 mph the customer has elected to have the (48 km/h), see an authorized dealer as soon as Electronic Stability Control (ESC) in a With the ESC switched off, the enhanced ...
Page 125 SAFETY Activating HDC NOTE: Disabling HDC During HDC the +/- shifter input is used for HDC Once HDC is enabled it will activate automatically HDC will be deactivated and disabled if any of the target speed selection, but will not affect the gear if driven down a grade of sufficient magnitude.
Page 126 SAFETY Towing With HSA The cluster icon and switch lamp will flash for The park brake must be off.   several seconds then extinguish when HDC The driver door must be closed. HSA will also provide assistance to mitigate roll ...
Page 127 SAFETY If disabling HSA using Uconnect Settings, refer Trailer Sway Control (TSC)  WARNING! to “Uconnect Settings” in “Multimedia” for Trailer Sway Control (TSC) uses sensors in the further information. If TSC activates while driving, slow the vehicle vehicle to recognize an excessively swaying trailer down, stop at the nearest safe location, and For vehicles not equipped with an instrument and will take the appropriate actions to attempt to...
Page 128: Auxiliary Driving Systems
SAFETY AUXILIARY DRIVING SYSTEMS The TPMS will continue to warn the driver of low approximately 27 psi (186 kPa), but the TPMS tire pressure as long as the condition exists, and Warning Light will still be on. In this situation, the will not turn off until the tire pressure is at or above TPMS Warning Light will turn off only after the tires RESSURE...
Page 129 SAFETY NOTE: NOTE: It is particularly important for you to check the tire The TPMS is not intended to replace normal tire  pressure in all of the tires on your vehicle monthly care and maintenance or to provide warning of and to maintain the proper pressure.
Page 130 SAFETY SERVICE TPMS WARNING A system fault can occur due to any of the Vehicles With Non-Matching Full Size Spare Or following: Compact Spare If a system fault is detected, the “TPMS Warning Signal interference due to electronic devices or The non-matching full size spare or compact Light”...
Page 131: Occupant Restraint Systems
SAFETY For each subsequent ignition switch cycle, a 1. This device may not cause harmful NOTE:  chime will sound, the TPMS Warning Light will interference, and Changes or modifications not expressly approved flash on and off for 75 seconds and then remain by the party responsible for compliance could void 2.
Page 132: Seat Belt Systems
SAFETY 7. The driver and front passenger seats should Here are some simple steps you can take to YSTEMS minimize the risk of harm from a deploying air bag: be moved back as far as practical to allow the Buckle up even though you are an excellent driver, front air bags room to inflate.
Page 133 SAFETY Initial Indication Change of Status Lap/Shoulder Belts If the driver is unbuckled when the ignition switch If the driver or outboard front seat passenger (if All seating positions except the Quad Cab and Crew equipped with outboard front passenger seat is first in the START or ON/RUN position, a chime Cab front center seating position have will signal for a few seconds.
Page 134 SAFETY WARNING! WARNING! WARNING! A lap belt worn too high can increase the risk It is dangerous to ride in a cargo area, inside A seat belt that is worn under your arm is    of injury in a collision. The seat belt forces or outside of a vehicle.
Page 135 SAFETY Lap/Shoulder Belt Operating Instructions 5. Position the shoulder belt across the shoulder and chest with minimal, if any slack so that it 1. Enter the vehicle and close the door. Sit back is comfortable and not resting on your neck. and adjust the seat.
Page 136 SAFETY Adjustable Upper Shoulder Belt Anchorage NOTE: First Row Center Seat Belt Operating The adjustable upper shoulder belt anchorage is Instructions (Regular Cab Only) In the driver and outboard front passenger seats, equipped with an Easy Up feature. This feature the top of the shoulder belt can be adjusted The first row center seat belt (Regular Cab only) allows the shoulder belt anchorage to be adjusted...
Page 137 SAFETY too tight, pull on the lap belt. A snug seat belt WARNING! reduces the risk of sliding under the seat belt in a collision. If the mini-latch plate and mini-buckle are not  properly connected when the seat belt is used 8.
Page 138 SAFETY Seat Belt Extender Seat Belts And Pregnant Women Seat Belt Pretensioner If a seat belt is not long enough to fit properly, even The front outboard seat belt system is equipped when the webbing is fully extended and the with pretensioning devices that are designed to adjustable upper shoulder belt anchorage (if remove slack from the seat belt in the event of a...
Page 139 SAFETY Switchable Automatic Locking Retractors In Automatic Locking Mode, the shoulder belt is automatically pre-locked. The seat belt will still (ALR) — If Equipped retract to remove any slack in the shoulder belt. The seat belts in the passenger seating positions Use the Automatic Locking Mode anytime a child may be equipped with a Switchable Automatic restraint is installed in a seating position that has...
Page 140: Supplemental Restraint Systems (Srs)
SAFETY How To Disengage The Automatic Locking Mode The air bag system must be ready to protect you in The ORC contains a backup power supply system a collision. The Occupant Restraint Controller that may deploy the air bag system even if the Unbuckle the combination lap/shoulder belt and (ORC) monitors the internal circuits and battery loses power or it becomes disconnected...
Page 141 SAFETY NOTE: WARNING! If the speedometer, tachometer, or any engine related gauges are not working, the Occupant Never install a rear-facing child restraint in the  Restraint Controller (ORC) may also be disabled. In front seat of a vehicle. Only use a rear-facing this condition the air bags may not be ready to child restraint in the rear seat.
Page 142 SAFETY Knee Impact Bolsters including some that may produce substantial WARNING! vehicle damage — for example, some pole The Knee Impact Bolsters help protect the knees collisions, truck underrides, and angle offset No objects should be placed over or near the ...
Page 143 SAFETY Supplemental Side Air Bag Inflatable Curtains The SABIC deploys downward, covering the side windows. An inflating SABIC pushes the outside (SABICs) edge of the headliner out of the way and covers the This vehicle is equipped with Supplemental Side window.
Page 144 SAFETY Side Impacts WARNING! WARNING! The Side Air Bags are designed to activate in Occupants, including children, who are up Relying on the Side Air Bags alone could lead  certain side impacts. The Occupant Restraint  against or very close to Side Air Bags can be to more severe injuries in a collision.
Page 145 SAFETY The SABICs may help reduce the risk of partial or If A Deployment Occurs As the air bags deflate, you may see some  complete ejection of vehicle occupants through smoke-like particles. The particles are a normal The front air bags are designed to deflate side windows in certain rollover or side impact by-product of the process that generates the immediately after deployment.
Page 146 SAFETY NOTE: NOTE: Your vehicle may also be designed to perform any of these other functions in response to the After an accident, remember to cycle the ignition to Air bag covers may not be obvious in the interior  Enhanced Accident Response System: the STOP (OFF/LOCK) position and remove the key trim, but they will open during air bag deployment.
Page 147 SAFETY Maintaining Your Air Bag System Event Data Recorder (EDR) WARNING! This vehicle is equipped with an event data WARNING! Do not attempt to modify any part of your air  recorder (EDR). The main purpose of an EDR is to bag system.
Page 148: Child Restraints
SAFETY NOTE: There are different sizes and types of restraints for HILD ESTRAINTS children from newborn size to the child almost EDR data are recorded by your vehicle only if a Everyone in your vehicle needs to be buckled up at large enough for an adult safety belt.
Page 149 SAFETY Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Children who are two years old or younger and who Either an Infant Carrier or a Convertible Child Infants and Toddlers have not reached the height or weight limits of their Restraint, facing rearward in a rear seat of the child restraint...
Page 150 SAFETY Infant And Child Restraints WARNING! WARNING! Safety experts recommend that children ride Never place a rear-facing child restraint in  rear-facing in the vehicle until they are two years front of an air bag. A deploying passenger old or until they reach either the height or weight front air bag can cause death or serious injury limit of their rear-facing child restraint.
Page 151 SAFETY Older Children And Child Restraints 2. Do the child’s knees bend comfortably over WARNING! the front of the vehicle seat – while the child is Children who are two years old or who have still sitting all the way back? After a child restraint is installed in the ...
Page 152 SAFETY Recommendations For Attaching Child Restraints Use Any Attachment Method Shown With An “X” Below Combined Weight of LATCH – Lower Restraint Type the Child + Child LATCH – Lower Seat Belt + Top Tether Seat Belt Only Anchors + Top Tether Restraint Anchors Only Anchor...
Page 153 SAFETY Lower Anchors And Tethers For CHildren Your vehicle is equipped with the child restraint LATCH Positions For Installing Child anchorage system called LATCH, which stands for (LATCH) Restraint System Restraints In This Vehicle Lower Anchors and Tethers for CHildren. The LATCH system has three vehicle anchor points for installing LATCH-equipped child seats.
Page 154 SAFETY Crew Cab 60/40 Split Bench LATCH Positions Quad Cab LATCH Positions Crew Cab Full Bench LATCH Positions Top Tether Anchorage Symbol Top Tether Anchorage Symbol Top Tether Anchorage Symbol Lower Anchorage Symbol (2 Anchorages Per Lower Anchorage Symbol (2 Anchorages Per Lower Anchorage Symbol (2 Anchorages Per Seating Position) Seating Position)
Page 155 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage system until the What is the weight limit (child’s weight + weight of combined weight of the child and the child restraint the child restraint) for using the LATCH anchorage 65 lbs (29.5 kg) is 65 lbs (29.5 kg).
Page 156 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH The child seat may touch the back of the front Can the rear-facing child restraint touch the back of passenger seat if the child restraint manufacturer the front passenger seat? also allows contact.
Page 157 SAFETY Center Seat LATCH Regular Cab, Quad Cab Or Crew Cab Full Bench Rear Seat: No Lower Center LATCH Anchorages Available WARNING! Do not install a child restraint in the center  position using the LATCH system. This position is not approved for installing child seats using the LATCH attachments.
Page 158 SAFETY vehicle, you may wish to move it to its restraint using the LATCH system, buckle the seat WARNING! rear-most position to make room for the child belt behind the child restraint and out of the child’s seat. You may also move the front seat forward reach.
Page 159 SAFETY Installing Child Restraints Using The “Automatic Locking Mode” description in “Switchable Automatic Locking Retractors (ALR)” Vehicle Seat Belt under “Occupant Restraint Systems” for additional Child restraint systems are designed to be secured information on ALR. The cinching latch plate is in vehicle seats by lap belts or the lap belt portion designed to hold the lap portion of the seat belt of a lap/shoulder belt.
Page 160 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s weight + weight of Always use the tether anchor when using the seat the child restraint) for using the Tether Anchor with belt to install a forward facing child restraint, up to Weight limit of the Child Restraint the seat belt to attach a forward facing child the recommended weight limit of the child...
Page 161 SAFETY Installing A Child Restraint With A For Regular Cab Models 8. If the child restraint has a top tether strap and the seating position has a top tether Switchable Automatic Locking Retractor Place the child seat in the center of the anchorage, connect the tether strap to the (ALR): seating position.
Page 162 SAFETY 6. Test that the child restraint is installed tightly Installing Child Restraints Using The Top 1. Place the child seat in the center of the seating position. If the second row seat can by pulling back and forth on the child seat at Tether Anchorage be reclined, you may recline the seat and/or the belt path.
Page 163 SAFETY Regular Cab Trucks: 2. Route the tether strap to provide the most Right Or Left Outboard Seats: direct path between the anchorage and the In the regular cab truck, the top tether anchorages 1. Raise the head restraint and reach between child seat.
Page 164 SAFETY 2. Place a child restraint on the seat and adjust the tether strap so that it will reach over the seat back, under the head restraint, through the tether strap loop behind the seat and over to the tether strap loop behind the center seat. 3.
Page 165: Transporting Pets
SAFETY Installing Three Child Restraints: WARNING! 1. Place a child restraint on each outboard rear An incorrectly anchored tether strap could  seat. Route the tether straps following the lead to increased head motion and possible directions for right and left seating positions, injury to the child.
Page 166: Safety Tips
SAFETY SAFETY TIPS Whenever a change is noticed in the sound of the XHAUST exhaust system, when exhaust fumes can be detected inside the vehicle, or when the underside RANSPORTING ASSENGERS WARNING! or rear of the vehicle is damaged, have a NEVER TRANSPORT PASSENGERS IN THE CARGO Exhaust gases can injure or kill.
Page 167 SAFETY Air Bag Warning Light Floor Mat Safety Information WARNING! Always use floor mats designed to fit your vehicle. The Air Bag warning light will turn on for four to ALWAYS REMOVE THE EXISTING FLOOR MAT  Only use a floor mat that does not interfere with the eight seconds as a bulb check when the ignition operation of the accelerator, brake or clutch FROM THE VEHICLE...
Page 168: Periodic Safety Checks You Should Make Outside The Vehicle
SAFETY Lights WARNING! WARNING! Have someone observe the operation of brake ONLY use the passenger’s side floor mat on It is recommended to only use mild soap and   lights and exterior lights while you work the the passenger’s side floor area. water to clean your floor mats.
Page 169: Starting And Operating
STARTING AND OPERATING STARTING THE ENGINE Starting the vehicle in NEUTRAL is not possible  WARNING! unless the Manual Park Release has been acti- Before starting your vehicle, adjust your seat, vated. For the Manual Park Release operation Do not leave the key fob in or near the vehicle, ...
Page 170 STARTING AND OPERATING NOTE: If the driver shifts into PARK while moving, the WARNING! vehicle may AutoPark. For Keyless Enter-N-Go equipped vehicles, the engine will turn off and the ignition switch will Driver inattention could lead to failure to place ...
Page 171: If Engine Fails To Start
STARTING AND OPERATING The message “AutoPark Not Engaged” will be If the engine shows no sign of starting after a 10 WARNING! second period of engine cranking with the displayed in the instrument cluster. A warning chime will continue until you shift the vehicle into accelerator pedal held to the floor, wait 10 to 15 Do not attempt to push or tow your vehicle to ...
Page 172: Engine Break-In Recommendations
STARTING AND OPERATING WARNING! CAUTION! Remember to disconnect the engine block Never use Non-Detergent Oil or Straight Mineral heater cord before driving. Damage to the Oil in the engine or damage may result. 110-115 Volt electrical cord could cause electrocution. NOTE: A new engine may consume some oil during its first ENGINE BREAK-IN RECOMMENDATIONS...
Page 173: Automatic Transmission
STARTING AND OPERATING locking mechanism may make it difficult to move WARNING! WARNING! the gear selector out of PARK. The parking brake should always be applied whenever the driver is Always fully apply the parking brake when Unintended movement of a vehicle could injure ...
Page 174: Key Ignition Park Interlock - If Equipped
STARTING AND OPERATING NOTE: mode (engine running, for vehicles with WARNING! eight-speed transmission) and the brake pedal You must press and hold the brake pedal while must be pressed. shifting out of PARK. Never leave children alone in a vehicle, or with ...
Page 175 STARTING AND OPERATING The electronically-controlled transmission adapts When parking on a level surface, you may shift the its shift schedule based on driver inputs, along transmission into PARK first, and then apply the with environmental and road conditions. The parking brake. transmission electronics are self-calibrating;...
Page 176 STARTING AND OPERATING WARNING! WARNING! WARNING! Your vehicle could move and injure you and Unintended movement of a vehicle could injure Do not leave the key fob in or near the vehicle    others if it is not in PARK. Check by trying to those in or near the vehicle.
Page 177 STARTING AND OPERATING REVERSE (R) DRIVE (D) Transmission Limp Home Mode This range is for moving the vehicle backward. This range should be used for most city and Transmission function is monitored electronically Shift into REVERSE only after the vehicle has come highway driving.
Page 178 STARTING AND OPERATING 3. Turn the ignition to the OFF position. On You can switch between DRIVE and ERS mode at WARNING! vehicles with Keyless Enter-N-Go, push and any vehicle speed. When the transmission gear hold the ignition switch until the engine turns selector is in DRIVE, the transmission will operate Do not downshift for additional engine braking OFF.
Page 179: If Equipped
STARTING AND OPERATING The “TOW/HAUL Indicator Light” will illuminate in OSITION LECTRONICALLY the instrument cluster and a light on the switch to Two-Wheel Drive High Range — This range is for HIFTED RANSFER indicate that TOW/HAUL mode has been activated. normal street and highway driving on dry hard Pushing the switch a second time restores normal This is an electronically shifted transfer case and is...
Page 180 STARTING AND OPERATING will have greater fuel economy benefits as the front If all of the following shift conditions are met: The “SVC 4WD Warning Light” monitors the axle is not engaged in 2WD. electronically shifted transfer case. If this light 1.
Page 181 STARTING AND OPERATING Because four-wheel drive provides improved Shifting Procedure NOTE: traction, there is a tendency to exceed safe turning The four-wheel drive system will not allow shifts NOTE: and stopping speeds. Do not go faster than road between 2WD/4WD LOCK if the front and/or rear If any of the requirements to select a new ...
Page 182: Limited-Slip Differential
STARTING AND OPERATING LIMITED-SLIP DIFFERENTIAL Alternate Procedure Care should be taken to avoid sudden accelerations when both rear wheels are on a 1. Bring the vehicle to complete stop. The limited-slip differential provides additional slippery surface. This could cause both rear wheels 2.
Page 183: Speed Control
STARTING AND OPERATING If the Steering icon is flashing, it indicates that the If the condition persists, see an authorized NOTE:  vehicle needs to be taken to the dealer for service. dealer for service. In order to ensure proper operation, the Speed It is likely the vehicle has lost power steering Control system has been designed to shut down if SPEED CONTROL...
Page 184: To Set A Desired Speed
STARTING AND OPERATING Metric Speed (km/h) Metric Speed (km/h) ESIRED PEED Pushing the RES (+) button once will result in a Pushing the SET (-) button once will result in a   Turn the Speed Control on. When the vehicle has 1 km/h increase in set speed.
Page 185: To Resume Speed
STARTING AND OPERATING The following conditions will also deactivate the ParkSense can be active only when the gear WARNING! Speed Control without erasing the set speed from selector is in REVERSE. If ParkSense is enabled at memory: this gear selector position, the system will remain Speed Control can be dangerous where the active until the vehicle speed is increased to system cannot maintain a constant speed.
Page 186: Parksense Warning Display
STARTING AND OPERATING ENSE ARNING ISPLAY The ParkSense Warning screen is located within the instrument cluster display. It provides visual warnings to indicate the distance between the rear fascia/bumper and the detected obstacle. Refer to “Instrument Cluster Display” in “Getting To Know Your Instrument Panel”...
Page 187: Enabling And Disabling Parksense
STARTING AND OPERATING The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS Rear Distance Greater than 79 inches 79-45 inches...
Page 188: Cleaning The Parksense System
STARTING AND OPERATING information. When the gear selector is moved to Clean the ParkSense sensors regularly, taking ENSE YSTEM SAGE  REVERSE and the system has detected a faulted care not to scratch or damage them. The RECAUTIONS condition, the instrument cluster display will show sensors must not be covered with ice, snow, the "PARKSENSE UNAVAILABLE WIPE REAR slush, mud, dirt or debris.
Page 189: Parksense Front And Rear Park Assist
STARTING AND OPERATING ParkSense can be active only when the gear WARNING! CAUTION! selector is in REVERSE or DRIVE. If ParkSense is enabled at one of these gear selector positions, Drivers must be careful when backing up even ParkSense is only a parking aid and it is ...
Page 190: Parksense Warning Display
STARTING AND OPERATING obstacle, the display will show the single arc ENSE ARNING ISPLAY moving closer to the vehicle and the tone will The ParkSense Warning screen is located within change from a single 1/2 second tone to slow, to the instrument cluster display.
Page 191: Enabling And Disabling Front And/Or Rear Parksense
STARTING AND OPERATING The vehicle is close to the obstacle when the display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS Rear Distance Greater than 79 inches 79-45 inches 45-31 inches...
Page 192: Service The Parksense Park Assist System
STARTING AND OPERATING The Front or Rear ParkSense switch LED will be on properly. These arc alerts will interrupt the ENSE YSTEM SAGE when Front or Rear ParkSense is disabled or "PARKSENSE UNAVAILABLE WIPE REAR RECAUTIONS requires service. The Front or Rear ParkSense SENSORS", "PARKSENSE UNAVAILABLE WIPE switch LED will be off when the Front or Rear FRONT SENSORS", or "PARKSENSE UNAVAILABLE...
Page 193: Parkview Rear Back Up Camera
STARTING AND OPERATING Clean the ParkSense sensors regularly, taking  WARNING! CAUTION! care not to scratch or damage them. The sensors must not be covered with ice, snow, Drivers must be careful when backing up even ParkSense is only a parking aid and it is ...
Page 194 STARTING AND OPERATING The ParkView Camera is located to the left of the A touchscreen button "X" to disable display of the WARNING! tailgate handle. camera image is made available when the vehicle is not in REVERSE gear. Drivers must be careful when backing up even When the vehicle is shifted out of REVERSE (with when using the ParkView Rear Back Up Camera.
Page 195: Refueling The Vehicle - Gas Engine
STARTING AND OPERATING NOTE: CAUTION! If snow, ice, mud, or any foreign substance builds up on the camera lens, clean the lens, rinse with Damage to the fuel system or emissions  water, and dry with a soft cloth. Do not cover the control system could result from using an lens.
Page 196: Loose Fuel Filler Cap Message
STARTING AND OPERATING VEHICLE LOADING WARNING! The tire size on the Vehicle Certification Label Always place container on the ground before  ROSS EHICLE EIGHT ATING represents the actual tire size on your vehicle. filling. (GVWR) Replacement tires must be equal to the load Keep the pump nozzle in contact with the ...
Page 197: Trailer Towing
STARTING AND OPERATING TRAILER TOWING The entire vehicle should first be weighed on a The recommended way to measure GTW is to put commercial scale to ensure that the GVWR has not your fully loaded trailer on a vehicle scale. The In this section you will find safety tips and been exceeded.
Page 198 STARTING AND OPERATING Weight-Carrying Hitch WARNING! WARNING! A weight-carrying hitch supports the trailer tongue It is important that you do not exceed the An improperly adjusted weight distributing  weight, just as if it were luggage located at a hitch maximum front or rear GAWR.
Page 199 STARTING AND OPERATING RECOMMENDED DISTRIBUTION HITCH 5. Install and adjust the tension in the weight distributing bars per the manufacturers’ ADJUSTMENT recommendations so that the height of the 1. Position the truck to be ready to connect to front fender is approximately (H2-H1)/2+H1 the trailer (do not connect the trailer).
Page 200: Trailer Hitch Type And Maximum Trailer Weight
STARTING AND OPERATING RAILER ITCH YPE AND AXIMUM RAILER EIGHT The following chart provides the maximum trailer weight a given factory equipped trailer hitch type can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. Trailer Hitch Type and Maximum Trailer Weight Hitch Type Max.
Page 201: Towing Requirements
STARTING AND OPERATING OWING EQUIREMENTS WARNING! WARNING! To promote proper break-in of your new vehicle Improper towing can lead to a collision. Follow Vehicles with trailers should not be parked on  drivetrain components, the following guidelines these guidelines to make your trailer towing as a grade.
Page 202 STARTING AND OPERATING Towing Requirements — Tires Integrated Trailer Brake Module — An electronically actuated trailer brake  controller is required when towing a trailer with If Equipped Do not attempt to tow a trailer while using a  electronically actuated brakes. When towing a compact spare tire.
Page 203 STARTING AND OPERATING The user interface consists of the following: GAIN Adjustment Buttons (+/-) the ITBM, braking functions will not be available), the GAIN setting will illuminate and Manual Brake Control Lever Pushing these buttons will adjust the brake control the correct type of trailer must be selected power output to the trailer brakes in Slide the manual brake control lever to the left to...
Page 204 STARTING AND OPERATING Light Electric Heavy Electric Light EOH Heavy EOH Electric over Hydraulic Trailer Electric over Hydraulic Trailer Type of Trailer Brakes Electric Trailer Brakes Electric Trailer Brakes Brakes Brakes *Under 10,000 lbs *Above 10,000 lbs *Under 10,000 lbs *Above 10,000 lbs Load (4,536 kgs)
Page 205: Towing Tips
STARTING AND OPERATING OWING Before setting out on a trip, practice turning, stopping, and backing up the trailer in an area located away from heavy traffic. Automatic Transmission The DRIVE range can be selected when towing. The transmission controls include a drive strategy to avoid frequent shifting when towing.
Page 206: Snowplow
STARTING AND OPERATING Tow/Haul Mode Cooling System WARNING! To reduce potential for automatic transmission To reduce potential for engine and transmission Snowplows and other aftermarket equipment overheating, activate TOW/HAUL mode when overheating, take the following actions: should not be added to the front end of your driving in hilly areas, or select a lower gear range City Driving vehicle.
Page 207: Recreational Towing (Behind Motorhome, Etc.)
STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) OWING EHICLE EHIND NOTHER EHICLE Towing Condition Wheels OFF The Ground Two-Wheel Drive Models Four-Wheel Drive Models See Instructions Transmission in PARK  Flat Tow NONE NOT ALLOWED Transfer case in NEUTRAL (N) ...
Page 208: Recreational Towing - Two-Wheel
STARTING AND OPERATING — T ECREATIONAL OWING HEEL CAUTION! CAUTION! RIVE ODELS Towing with the rear wheels on the ground will Tow only in the forward direction. Towing this   cause severe transmission damage. Damage DO NOT flat tow this vehicle. Damage to the vehicle backwards can cause severe damage drivetrain will result.
Page 209 STARTING AND OPERATING Shifting Into NEUTRAL (N) 4. Shift the transfer case into NEUTRAL: 10. Shift the transmission into PARK. On 8-speed transmissions the gear selector will automat- With manual shift transfer case, shift the Use the following procedure to prepare your ...
Page 210 STARTING AND OPERATING A flashing NEUTRAL (N) position indicator light With electronically shifted transfer case 10. Release the parking brake.   indicates that shift requirements have not been with push-button selector switch, push and 11. Shift the transmission into gear, release the met.
Page 211: Driving Tips
STARTING AND OPERATING DRIVING TIPS Flowing/Rising Water WARNING! WARNING! Driving through standing water limits your RIVING LIPPERY URFACES  vehicle’s braking capabilities, which increases Do not drive on or across a road or path where Acceleration stopping distances. Therefore, after driving water is flowing and/or rising (as in storm through standing water, drive slowly and Rapid acceleration on snow covered, wet, or other...
Page 212: Off-Road Driving Tips
STARTING AND OPERATING If you must back down a hill, back straight down Check for accumulations of plants or brush.  CAUTION! using REVERSE gear. Never back down in These things could be a fire hazard. They might NEUTRAL or diagonally across the hill. hide damage to fuel lines, brake hoses, axle Driving through standing water may cause ...
Page 213: In Case Of Emergency
IN CASE OF EMERGENCY HAZARD WARNING FLASHERS ASSIST AND SOS MIRROR — IF EQUIPPED NOTE: Your vehicle may be transmitting data as autho-  The Hazard Warning Flashers button is located on rized by the subscriber. the upper switch bank just below the radio. The SOS and ASSIST buttons will only function if ...
Page 214 IN CASE OF EMERGENCY SOS Call 5. The SOS operator may attempt to contact WARNING! appropriate emergency responders and 1. Push the SOS Call button on the Rearview provide them with important vehicle ALWAYS obey traffic laws and pay attention to Mirror.
Page 215 IN CASE OF EMERGENCY If the SOS Call system detects a malfunction, any Even if the SOS Call system is fully functional, WARNING! of the following may occur at the time the factors beyond FCA US LLC’s control may prevent malfunction is detected, and at the beginning of or stop the SOS Call system operation.
Page 216: General Information
IN CASE OF EMERGENCY NOTE: Le présent appareil est conforme aux CNR WARNING! d`Innovation, Science and Economic Development Changes or modifications not expressly approved applicables aux appareils radio exempts de by the party responsible for compliance could void ALWAYS obey traffic laws and pay attention to licence.
Page 217: Fuses
IN CASE OF EMERGENCY FUSES otherwise the cavity number of each fuse is WARNING! stamped on the inside cover that corresponds to the following chart. If the replaced fuse blows again, contact an WARNING!  authorized dealer. When replacing a blown fuse, always use an ...
Page 218 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description 20 Amp Blue (1500 LD/ – Emissions Diesel – If Equipped Cummins Diesel) – Aux Relay Output- Special Services Only 40 Amp Green 40 Amp Green (Special Services – Diesel Fuel Heater – If Equipped Vehicle &...
Page 219 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description 30 Amp Pink – Antilock Brakes / Stability Control Module / Valves 20 Amp Blue – Trailer Tow Backup Lights – If Equipped 20 Amp Blue – Trailer Tow Parking Lights – If Equipped 30 Amp Pink –...
Page 220 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description – 20 Amp Yellow Trailer Tow – Left Turn/Stop Lights - If Equipped – 20 Amp Yellow Adjustable Pedals - If Equipped – 15 Amp Blue Additional Diesel Content - If Equipped –...
Page 221 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description – 10 Amp Red Coolant Temperature Valve Actuator – 10 Amp Red Antilock Brakes / Electronic Stability Control - If Equipped – 10 Amp Red Drivetrain Control Module/Front Axle Disconnect Module –...
Page 222 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description – 10 Amp Red Rear Camera / Park Assist - If Equipped – 10 Amp Red Rear Seat Heater Switch - If Equipped – 25 Amp Clear Rear Heated Seats & Heated Steering Wheel – If Equipped –...
Page 223: Bulb Replacement
IN CASE OF EMERGENCY BULB REPLACEMENT EPLACEMENT ULBS All of the inside bulbs are brass or glass-wedge base. Aluminum base bulbs are not approved. Interior Bulbs Bulb Name Bulb Number Overhead Console Lamps TS 212–9 Dome Lamp 7679 NOTE: For lighted switches, see an authorized dealer for replacement instructions. Exterior Bulbs Bulb Name Bulb Number...
Page 224 IN CASE OF EMERGENCY Exterior Bulbs Bulb Name Bulb Number Front Turn Signal Lamp (Premium Headlamp) LED (Serviced at an authorized dealer) Fog Lamp (Horizontal shape) 9145 Fog Lamp (Vertical shape) 9006 Center High Mounted Stop Lamp (CHMSL) 921K Rear Cargo Lamp LED Center High Mounted Stop Lamp (CHMSL)/Cargo Lamp LED (Serviced at an authorized dealer) Base Rear Tail/Turn and Stop Lamp...
Page 225: Replacing Exterior Bulbs
IN CASE OF EMERGENCY 7. Reach into the front wheel house ahead of the 11. Replace bulb(s) as necessary. EPLACING XTERIOR ULBS front wheel, remove the fastener, and lift the Base Quad / Premium Bi-Halogen: Low CAUTION! cover over the access hole in the front of the Beam Headlamp, High Beam Headlamp, wheel house splash shield.
Page 226 IN CASE OF EMERGENCY Center High Mounted Stop Lamp (CHMSL) CAUTION! With Cargo Lamp Do not contaminate the bulb glass by touching it 1. Remove the two screws holding the housing/ with your fingers or by allowing it to contact other lens to the body as shown.
Page 227: Jacking And Tire Changing
IN CASE OF EMERGENCY JACKING AND TIRE CHANGING 3. Turn the desired bulb socket a quarter turn OCATION and remove the socket and bulb from housing. The jack and jack tools are stored under the front WARNING! 4. Pull the desired bulb straight from the socket. passenger seat.
Page 228 IN CASE OF EMERGENCY Assembled For Spare Tire Lowering/Raising CAUTION! Damage to the lug wrench, extensions and  winch mechanism may occur from improper tool assembly. Assembled For Jack Operation Jack And Tools Release the tool bag straps from the jack and Assembled For Spare Tire Lowering/Raising remove tools from bag.
Page 229: Removing The Spare Tire
IN CASE OF EMERGENCY WARNING! After using the jack and tools, always reinstall them in the original carrier and location. While driving you may experience abrupt stopping, rapid acceleration or sharp turns. A loose jack, tools, bracket or other objects in the vehicle may move around with force, resulting in serious injury.
Page 230: Preparations For Jacking
IN CASE OF EMERGENCY 5. Pull the spare tire out from under the vehicle to 7. Pull the retainer through the center of the 2. Turn on the Hazard Warning Flashers. gain access to the spare tire retainer. wheel. 3. Apply the parking brake. 4.
Page 231: Jacking Instructions
IN CASE OF EMERGENCY 1. Remove the spare tire, jack, and tools from ACKING NSTRUCTIONS WARNING! the stored location. If working on or near a roadway, be extremely  WARNING! 2. Using the lug wrench, loosen the wheel nuts careful of motor traffic. (but do not remove), by turning them counter- Carefully follow these tire changing warnings to clockwise one turn while the wheel is still on...
Page 232 IN CASE OF EMERGENCY Front Jacking Location When changing a rear wheel, assemble the extension with jack hook to the jack and There is a jack location indicator on the rear connect the extension tubes. Place the jack portion of the front lower control arm. under the axle between the wheel and the shock bracket with the extension with jack hook extending to the rear.
Page 233: To Stow The Flat Or Spare
IN CASE OF EMERGENCY 5. By rotating the lug wrench clockwise, raise the WARNING! WARNING! vehicle until the wheel just clears the surface. A loose tire or jack thrown forward in a collision A loose tire or jack thrown forward in a collision WARNING! or hard stop, could endanger the occupants of or hard stop could endanger the occupants of...
Page 234: Reinstalling The Jack And Tools
IN CASE OF EMERGENCY NOTE: 2. Lift the spare tire with one hand to give clearance to tilt the retainer at the end of the The winch mechanism is designed for use with the cable and position it properly across the wheel extension tube only.
Page 235: Jump Starting
IN CASE OF EMERGENCY 3. Secure the tool bag straps to the jack. WARNING! Do not attempt jump starting if the battery is frozen. It could rupture or explode and cause personal injury. CAUTION! Do not use a portable battery booster pack or any other booster source with a system voltage greater Jack And Tools than 12 Volts or damage to the battery, starter...
Page 236: Jump Starting Procedure
IN CASE OF EMERGENCY 1. Apply the parking brake, shift the automatic Connecting The Jumper Cables transmission into PARK (P) and turn the 1. Connect the positive (+) end of the jumper ignition OFF. cable to the positive (+) post of the discharged 2.
Page 237: If Your Engine Overheats
IN CASE OF EMERGENCY 5. Start the engine in the vehicle that has the If frequent jump starting is required to start your You can also turn the temperature control to  vehicle you should have the battery and charging booster battery, let the engine idle a few maximum heat, the mode control to floor and minutes, and then start the engine in the...
Page 238: Manual Park Release - 8 - Speed
IN CASE OF EMERGENCY MANUAL PARK RELEASE — 8 - SPEED 3. Using a small screwdriver or similar tool, remove the Manual Park Release access TRANSMISSION cover, which is located to the lower left of the steering column. WARNING! Always secure your vehicle by fully applying the parking brake before activating the Manual Park Release.
Page 239: Freeing A Stuck Vehicle
IN CASE OF EMERGENCY To Reset The Manual Park Release: NOTE: CAUTION! For trucks equipped with 8-speed automatic trans- 1. Apply firm pressure to the brake pedal while mission: Shifts between DRIVE (D) and REVERSE Racing the engine or spinning the wheels may ...
Page 240: Towing A Disabled Vehicle
IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. If the transmission and drivetrain are operable, disabled vehicles may also be towed as described under “Recreational Towing” in the “Starting And Operating” section. Towing Condition Wheels OFF The Ground 2WD Models...
Page 241: Two-Wheel Drive Models
IN CASE OF EMERGENCY If the transmission is not operable, or the vehicle HEEL RIVE ODELS HEEL RIVE ODELS must be towed faster than 30 mph (48 km/h) or The manufacturer recommends towing your The manufacturer recommends towing with all farther than 15 miles (24 km) for 6–speed vehicle with all four wheels OFF the ground using a wheels OFF the ground.
Page 242: Emergency Tow Hooks - If Equipped
IN CASE OF EMERGENCY EVENT DATA RECORDER (EDR) — MERGENCY OOKS CAUTION! QUIPPED This vehicle is equipped with an Event Data Tow hooks are for emergency use only, to rescue Recorder (EDR). The main purpose of an EDR is to a vehicle stranded off road.
Page 243: Servicing And Maintenance
SERVICING AND MAINTENANCE SCHEDULED SERVICING An authorized dealer will reset the oil change Severe Duty indicator message after completing the scheduled NOTE: Your vehicle is equipped with an automatic oil oil change. Change Engine Oil at 4,000 miles (6,500 km) or change indicator system.
Page 244: Maintenance Plan
SERVICING AND MAINTENANCE AINTENANCE Required Maintenance Refer to the Maintenance Plan on the following pages for required maintenance. More frequent maintenance may be needed in severe conditions, such as dusty areas and very short trip driving. In some extreme conditions, additional maintenance not specified in the maintenance schedule may be required. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Change the oil and filter.
Page 245 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV/Universal joints. Inspect front suspension, tie rod ends, and replace if necessary. Inspect the front and rear axle surfaces. If gear oil leakage is suspected, check the fluid level.
Page 246 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first. Inspect the transfer case fluid, change for any of the following: police, taxi, fleet, or frequent trailer towing.
Page 247: Engine Compartment
SERVICING AND MAINTENANCE ENGINE COMPARTMENT 3.6L E NGINE 1 — Air Cleaner Filter 5 — Battery 2 — Engine Oil Dipstick 6 — Washer Fluid Reservoir Cap 3 — Engine Oil Fill 7 — Power Distribution Center (Fuses) 4 — Brake Fluid Reservoir 8 —...
Page 248: L Engine
SERVICING AND MAINTENANCE 5.7L E NGINE 1 — Air Cleaner Filter 6 — Washer Fluid Reservoir Cap 2 — Engine Oil Fill 7 — Power Distribution Center (Fuses) 3 — Engine Oil Dipstick 8 — Coolant Pressure Cap 4 — Brake Fluid Reservoir Cap 9 —...
Page 249: Checking Oil Level - Gas Engine
SERVICING AND MAINTENANCE — G HECKING EVEL NGINE DDING ASHER LUID AINTENANCE ATTERY To ensure proper lubrication of your vehicle's The fluid reservoir is located under the hood and Your vehicle is equipped with a maintenance-free engine, the engine oil must be maintained at the should be checked for fluid level at regular battery.
Page 250: Pressure Washing
SERVICING AND MAINTENANCE DEALER SERVICE NOTE: CAUTION! Under no circumstances should oil change An authorized dealer has the qualified service intervals exceed 10,000 miles (16,000 km), It is essential when replacing the cables on  personnel, special tools, and equipment to 12 months or 350 hours of engine run time, the battery that the positive cable is attached perform all service operations in an expert...
Page 251 SERVICING AND MAINTENANCE American Petroleum Institute (API) Engine The engine oil filler cap also shows the Synthetic Engine Oils recommended engine oil viscosity for your engine. Oil Identification Symbol You may use synthetic engine oils provided the For information on engine oil filler cap location, recommended oil quality requirements are met, This symbol means that the oil has been refer to the “Engine Compartment”...
Page 252: Engine Oil Filter
SERVICING AND MAINTENANCE Engine Air Cleaner Filter Inspection and NGINE ILTER WARNING! Replacement The engine oil filter should be replaced with a new The air induction system (air cleaner, hoses, Inspect engine air cleaner filter for dirt and or filter at every engine oil change. etc.) can provide a measure of protection in the debris, if you find evidence of either dirt or debris Engine Oil Filter Selection...
Page 253: Air Conditioner Maintenance
SERVICING AND MAINTENANCE 2. Lift the air cleaner cover to access the air ONDITIONER AINTENANCE cleaner filter. For best possible performance, your air conditioner should be checked and serviced by an authorized dealer at the start of each warm season. This service should include cleaning of the condenser fins and a performance test.
Page 254 SERVICING AND MAINTENANCE Refrigerant Recovery And Recycling 1. Open the glove compartment and remove all CAUTION! contents. R-1234yf — If Equipped Do not use chemical flushes in your air 2. With the glove compartment door open, R-1234yf Air Conditioning Refrigerant is a hydroflu- conditioning system as the chemicals can remove the glove compartment tension tether oroolefin (HFO) that is endorsed by the...
Page 255 SERVICING AND MAINTENANCE 3. There are glove compartment travel stops on both sides of the glove compartment door, push inward on both sides of the glove compartment to release the glove compartment travel stops. Filter Cover Finger Tab 6. Remove the cabin air filter by pulling it straight out of the housing.
Page 256: Accessory Drive Belt Inspection
SERVICING AND MAINTENANCE 7. Install the cabin air filter with the arrow on the 9. Pull the tension tether outward and reinstall CCESSORY RIVE NSPECTION filter pointing toward the floor. When installing the glove compartment past the travel stops by the filter cover, press on each end until you pushing in on the glove compartment sides.
Page 257: Body Lubrication
SERVICING AND MAINTENANCE Some conditions can be caused by a faulty INDSHIELD IPER LADES component such as a belt pulley. Belt pulleys Clean the rubber edges of the wiper blades and the should be carefully inspected for damage and windshield periodically with a sponge or soft cloth proper alignment.
Page 258 SERVICING AND MAINTENANCE If a wiper blade or wiper arm is damaged, replace 2. To disengage the wiper blade from the wiper the affected wiper blade or arm with a new unit. Do arm, flip up the locking tab. not attempt to repair a wiper blade or arm that is damaged.
Page 259: Exhaust System
SERVICING AND MAINTENANCE 4. Slide the wiper blade up into the hook on the WARNING! wiper arm until it is latched (engagement will be accompanied by an audible click). Fold Exhaust gases can injure or kill. They contain  down the latch release tab and snap it into its carbon monoxide (CO), which is colorless and locked position.
Page 260: Cooling System
SERVICING AND MAINTENANCE To minimize the possibility of catalytic converter CAUTION! WARNING! damage: Damage to the catalytic converter can result if When working near the radiator cooling fan,  Do not interrupt the ignition when the transmis-   your vehicle is not kept in proper operating disconnect the fan motor lead or turn the igni- sion is in gear and the vehicle is in motion.
Page 261 SERVICING AND MAINTENANCE Cooling System — Drain, Flush And Refill system will need to be drained, flushed, and Please review these recommendations for using refilled with fresh OAT coolant (conforming to Organic Additive Technology (OAT) engine coolant NOTE: MS.90032), by an authorized dealer as soon as (antifreeze) that meets the requirements of FCA Some vehicles require special tools to add coolant possible.
Page 262 SERVICING AND MAINTENANCE could lead to severe internal engine damage. If any To check the coolant level: WARNING! coolant is needed to be added to the system, 1. Open the coolant reservoir. please contact a local authorized dealer. Do not use a pressure cap other than the one ...
Page 263: Brake System
SERVICING AND MAINTENANCE The radiator normally remains completely full, so If frequent engine coolant (antifreeze) additions  WARNING! there is no need to remove the radiator cap unless are required, the cooling system should be pres- checking for engine coolant (antifreeze) freeze sure tested for leaks.
Page 264: Automatic Transmission
SERVICING AND MAINTENANCE Special Additives WARNING! WARNING! The manufacturer strongly recommends against Use only manufacturer's recommended brake Do not allow petroleum based fluid to contam-   using any special additives in the transmission. fluid. Refer to “Fluids And Lubricants” in inate the brake fluid.
Page 265: Fluid Level
SERVICING AND MAINTENANCE If you notice fluid leakage or transmission And Lubricants” in “Technical Specifications” for NOTE: malfunction, visit an authorized dealer further information. This inspection should be When refilling an axle with a Limited Slip Differ- immediately to have the transmission fluid level made with the vehicle in a level position.
Page 266: Hoisting
SERVICING AND MAINTENANCE HOISTING Tire Markings the size designation. Example: P215/ 65R15 95H. A conventional floor jack may be used at the European — Metric tire sizing is based jacking locations. Refer to the graphics that show  on European design standards. Tires jacking locations.
Page 267 SERVICING AND MAINTENANCE TIRE SIZING CHART EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on US design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on US design standards, or T or S = Temporary spare tire or 31 = Overall diameter in inches (in)
Page 268 SERVICING AND MAINTENANCE EXAMPLE: Service Description: 95 = Load Index A numerical code associated with the maximum load a tire can carry  H = Speed Symbol A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions ...
Page 269 SERVICING AND MAINTENANCE Tire Identification Number (TIN) The Tire Identification Number (TIN) may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire. Look for the TIN on the outboard side of black sidewall tires as mounted on the vehicle.
Page 270 SERVICING AND MAINTENANCE Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a minimum Cold Tire Inflation Pressure of three hours.
Page 271 SERVICING AND MAINTENANCE Steps For Determining Correct Load Tire And Loading Information Placard Loading Limit— The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your (1) Locate the statement “The combined vehicle.
Page 272 SERVICING AND MAINTENANCE (4) The resulting figure equals the (6) If your vehicle will be towing a trailer, NOTE: available amount of cargo and luggage load from your trailer will be transferred If your vehicle will be towing a trailer, load from ...
Page 273 SERVICING AND MAINTENANCE WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them.
Page 274: Tires - General Information
SERVICING AND MAINTENANCE — G Tread Wear IRES ENERAL NFORMATION WARNING! Improper cold tire inflation pressures can cause Tire Pressure Unequal tire pressures can cause steering  abnormal wear patterns and reduced tread life, Proper tire inflation pressure is essential to the problems.
Page 275 SERVICING AND MAINTENANCE Inflation pressures specified on the placard are Tire Pressures For High Speed Operation Tire Repair always “cold tire inflation pressure”. Cold tire If your tire becomes damaged, it may be repaired if The manufacturer advocates driving at safe inflation pressure is defined as the tire pressure it meets the following criteria: speeds and within posted speed limits.
Page 276 SERVICING AND MAINTENANCE Tread Wear Indicators Life Of Tire condition, please replace the TPM sensor as it is not designed to be reused when driven under run Tread wear indicators are in the original equipment The service life of a tire is dependent upon varying flat mode 14 psi (96 kPa) condition.
Page 277: Tire Types
SERVICING AND MAINTENANCE Keep dismounted tires in a cool, dry place with as capability. Failure to use equivalent replacement CAUTION! tires may adversely affect the safety, handling, and little exposure to light as possible. Protect tires from contact with oil, grease, and gasoline. ride of your vehicle.
Page 278: Spare Tires - If Equipped
SERVICING AND MAINTENANCE Spare Tire Matching Original Equipped Tire Summer tires do not contain the all season authorized tire dealer for recommended safe designation or “mountain/snowflake” symbol on operating speeds, loading and cold tire inflation And Wheel — If Equipped the tire sidewall.
Page 279 SERVICING AND MAINTENANCE Do not install a wheel cover or attempt to mount a Since this tire has limited tread life, the original Full Size Spare — If Equipped conventional tire on the compact spare wheel, equipment tire should be repaired (or replaced) The full size spare is for temporary emergency use since the wheel is designed specifically for the and reinstalled on your vehicle at the first...
Page 280: Wheel And Wheel Trim Care
SERVICING AND MAINTENANCE Your wheels are susceptible to deterioration WARNING! CAUTION! caused by salt, sodium chloride, magnesium chloride, calcium chloride, etc., and other road Limited use spares are for emergency use only. Do not use scouring pads, steel wool, a bristle chemicals used to melt ice or control dust on dirt Installation of this limited use spare tire affects brush, metal polishes or oven cleaner.
Page 281: Tire Chains And Traction Devices
SERVICING AND MAINTENANCE HAINS AND RACTION EVICES CAUTION! CAUTION! Use of traction devices require sufficient To avoid damage to your vehicle or tires, observe Observe the traction device manufacturer’s  tire-to-body clearance. Due to limited clearance, the following precautions: instructions on the method of installation, the following traction devices are recommended.
Page 282: Tire Quality Grades
SERVICING AND MAINTENANCE DEPARTMENT OF TRANSPORTATION depends upon the actual conditions of Refer to the “Maintenance Plan” in this chapter for the proper maintenance intervals. More frequent their use, however, and may depart UNIFORM TIRE QUALITY GRADES rotation is permissible if desired. The reasons for significantly from the norm due to any rapid or unusual wear should be corrected variations in driving habits, service...
Page 283: Temperature Grades
SERVICING AND MAINTENANCE STORING THE VEHICLE The following maintenance recommendations will EMPERATURE RADES enable you to obtain maximum benefit from the The Temperature grades are A (the If you are storing your vehicle for more than 21 corrosion resistance built into your vehicle. highest), B, and C, representing the tire's days, we recommend that you take the following What Causes Corrosion?
Page 284: Preserving The Bodywork
SERVICING AND MAINTENANCE Do not use abrasive cleaning components, CAUTION! CAUTION! solvents, steel wool or other aggressive material to clean the lenses. Do not use abrasive or strong cleaning mate- Do not use scouring pads, steel wool, a bristle  ...
Page 285: Interiors
SERVICING AND MAINTENANCE If your vehicle is damaged due to a collision or To Help Maintain The Appearance Of Your Repairing The Spray-On Bedliner  similar cause that destroys the paint and protec- Spray-On Bedliner, Follow The Steps Below: While extremely tough, it is possible to damage a tive coating, have your vehicle repaired as soon 1.
Page 286: Plastic And Coated Parts
SERVICING AND MAINTENANCE Stain Repel Fabric Cleaning Procedure — If the belts need cleaning, use a mild soap solution LASTIC OATED ARTS or lukewarm water. Do not remove the belts from If Equipped Use Mopar Total Clean to clean vinyl upholstery. the vehicle to wash them.
Page 287: Leather Parts
SERVICING AND MAINTENANCE NOTE: EATHER ARTS LASS URFACES If equipped with light colored leather, it tends to Mopar Total Clean is specifically recommended for All glass surfaces should be cleaned on a regular show any foreign material, dirt, and fabric dye leather upholstery.
Page 288: Technical Specifications
TECHNICAL SPECIFICATIONS IDENTIFICATION DATA BRAKE SYSTEM WHEEL AND TIRE TORQUE SPECIFICATIONS If power assist is lost for any reason (for example, Proper lug nut/bolt torque is very important to EHICLE DENTIFICATION UMBER repeated brake applications with the engine off), ensure that the wheel is properly mounted to the The Vehicle Identification Number (VIN) is found on the brakes will still function.
Page 289: Fuel Requirements
TECHNICAL SPECIFICATIONS Inspect the wheel mounting surface prior to specified by the (R+M)/2 method. The use of higher mounting the tire and remove any corrosion or octane “Premium” gasoline will not provide any loose particles. benefit over “Regular” gasoline in these engines. While operating on gasoline with an octane number of 87, hearing a light knocking sound from the engine is not a cause for concern.
Page 290: Reformulated Gasoline
TECHNICAL SPECIFICATIONS the engine is heard making a heavy knocking Designated TOP TIER Detergent Problems that result from using gasoline sound, see your dealer immediately. Use of Gasoline contains a higher level of containing more than 15% ethanol (E-15) or gasoline with an octane number lower than 87 can detergents to further aide in minimizing gasoline containing methanol are not the...
Page 291: Cng And Lp Fuel System Modifications
TECHNICAL SPECIFICATIONS CNG A LP F NOTE: YSTEM YSTEM AUTIONS Intentional tampering with the emissions control ODIFICATIONS system can result in civil penalties being assessed CAUTION! against you. Modifications that allow the engine to run on Follow these guidelines to maintain your Compressed Natural Gas (CNG) or Liquid Propane ARBON ONOXIDE...
Page 292: Fluid Capacities
TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) Regular Cab Shortbed/Crew Quad Cab Models 26 Gallons 98 Liters Regular Cab Longbed/Crew Quad Cab Models 32 Gallons 121 Liters (Optional) Engine Oil With Filter 3.6L Engine (We recommend you use SAE 5W-20, 6 Quarts 5.6 Liters API Certified)
Page 293: Fluids And Lubricants
TECHNICAL SPECIFICATIONS FLUIDS AND LUBRICANTS NGINE Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000 Mile Engine Coolant (240,000 km) Formula OAT (Organic Additive Technology). We recommend you use API Certified SAE 5W-20 Engine Oil, meeting the requirements of FCA Material Standard MS-6395 such as Mopar, Pennzoil, and Shell Helix.
Page 294: Chassis
TECHNICAL SPECIFICATIONS CAUTION! Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and  may decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is different and should not be mixed with Hybrid Organic Additive Tech- nology (HOAT) engine coolant (antifreeze) or any “globally compatible”...
Page 295: Multimedia
MULTIMEDIA UCONNECT SYSTEMS and performance of your systems or to reduce the NOTE: potential risk of unauthorized and unlawful access FCA US LLC or your dealer may contact you  For detailed information about your Uconnect to your vehicle systems. directly regarding software updates.
Page 296: Uconnect Settings
MULTIMEDIA UCONNECT SETTINGS — Push the Settings button to display the settings USTOMER ROGRAMMABLE EATURES menu screen. In this mode, the Uconnect system CONNECT ETTINGS The Uconnect system uses a combination of allows you to access all of the available buttons on the touchscreen and buttons on the programmable features.
Page 297 MULTIMEDIA Display After pressing the Display button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode Auto Manual Set Language English, Français, Español Touchscreen Beep Fuel Saver Display NOTE: The “Fuel Saver Display” feature will allow you to enable fuel saver mode and will be displayed in the instrument cluster display. Units —...
Page 298 MULTIMEDIA Clock & Date After pressing the Clock & Date button on the touchscreen, the following settings will be available: Setting Name Selectable Options Set Time 12 hour 24 hour NOTE: Within the “Set Time” feature, press the corresponding arrow above and below the current time to adjust, then select AM or PM. Set Date Up Arrow Down Arrow...
Page 299 MULTIMEDIA Safety/Assistance After pressing the Safety/Assistance button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkSense — If Equipped Sound Only Sound and Display NOTE: The ParkSense system will scan for objects behind the vehicle when the transmission gear selector is in REVERSE and the vehicle speed is less than 7 mph (11 km/h).
Page 300 MULTIMEDIA Setting Name Selectable Options Rain Sensing Auto Wipers — If Equipped NOTE: When the “Rain Sensing Auto Wipers” feature is selected, the system will automatically activate the windshield wipers if it senses moisture on the windshield. Hill Start Assist — If Equipped NOTE: When the “Hill Start Assist”...
Page 301 MULTIMEDIA Setting Name Selectable Options Flash Lights With Lock NOTE: When the “Flash Lights With Lock” feature is selected, the exterior lights will flash when the doors are locked or unlocked with the key fob. This feature may be selected with or without the Sound Horn With Lock feature selected. Doors &...
Page 302 MULTIMEDIA Setting Name Selectable Options Sound Horn With Remote Start NOTE: When the “Sound Horn With Remote Start” feature is selected, the horn will sound when the remote start is activated. Memory Linked To Fob — If Equipped NOTE: The “Memory Linked To Fob” feature provides automatic driver seat positioning to enhance driver mobility when entering and exiting the vehicle. ...
Page 303 MULTIMEDIA Auto-On Comfort Systems — If Equipped After pressing the Auto-On Comfort button on the touchscreen, the following setting will be available: Setting Name Selectable Options Auto-On Driver Heated/Ventilated Seat & Steering Wheel With Vehicle Start — If Equipped NOTE: When the “Auto-On Driver Heated/Ventilated Seat &...
Page 304 MULTIMEDIA Trailer Brake After pressing the Trailer Brake button on the touchscreen, the following settings will be available: Setting Name Selectable Options Trailer Select Trailer 1 Trailer 2 Trailer 3 Trailer 4 Trailer Brake Type Light Electric Heavy Electric Light EOH Heavy EOH Audio After pressing the Audio button on the touchscreen, the following settings will be available:...
Page 305 MULTIMEDIA Setting Name Selectable Options Surround Sound — If Equipped NOTE: The “Surround Sound” feature provides simulated surround sound mode. AUX Volume Offset — If Equipped NOTE: The “AUX Volume Offset” feature provides the ability to tune the audio level for portable devices connected through the AUX input. Loudness —...
Page 306 MULTIMEDIA SiriusXM® Setup — If Equipped After pressing the SiriusXM® Setup button on the touchscreen, the following settings will be available: Setting Name Selectable Options Tune Start Channel Skip List of Channels NOTE: SiriusXM® can be programmed to exclude undesirable channels while scanning. To make your selection, press the Channel Skip button on the touchscreen, and select the channels you would like to skip.
Page 307 MULTIMEDIA Restore Settings After pressing the Restore Settings button on the touchscreen, the following setting will be available: Setting Name Selectable Options Restore Settings Cancel NOTE: When the “Restore Settings” feature is selected it will reset the Display, Clock, Audio, and Radio Settings to their default settings. If Yes is selected a pop-up will appear asking, “Are you sure you want to reset your settings to default?”...
Page 308: Customer Programmable Features
MULTIMEDIA — When making a selection, press the button on the USTOMER ROGRAMMABLE EATURES Press the Apps button, then press the touchscreen to enter the desired menu. Once in 4C/4C NAV S CONNECT ETTINGS Settings button on the touchscreen to display the desired menu, press and release the preferred the menu setting screen.
Page 309 MULTIMEDIA Language After pressing the Language button on the touchscreen, the following settings will be available: Setting Name Selectable Options Language English Français Español Display After pressing the Display button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode Auto...
Page 310 MULTIMEDIA Setting Name Selectable Options Controls Screen Time-Out — If Equipped Fuel Saver Display in Cluster — If Equipped Voice After pressing the Voice button on the touchscreen, the following settings will be available: Setting Name Selectable Options Voice Response Length Brief Detailed Show Command List —...
Page 311 MULTIMEDIA Camera After pressing the Camera button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkView Backup Camera Delay NOTE: The “ParkView Backup Camera Delay” setting determines whether or not the screen will display the rear view image with dynamic grid lines for up to 10 seconds after the vehicle is shifted out of REVERSE.
Page 312 MULTIMEDIA Setting Name Selectable Options Rear ParkSense Chime Volume — If Equipped High Tilt Mirrors In Reverse — If Equipped NOTE: When the “Tilt Mirrors In Reverse” feature is selected, the exterior side-view mirrors will tilt downward when the ignition is in the ON/RUN position and the transmission gear selector is in the REVERSE position.
Page 313 MULTIMEDIA Mirrors & Wipers After pressing the Mirror and Wipers button on the touchscreen, the following setting will be available: Setting Name Selectable Options Headlights with Wipers Lights After pressing the Lights button on the touchscreen, the following settings will be available: Setting Name Selectable Options Headlight Off Delay...
Page 314 MULTIMEDIA Setting Name Selectable Options Daytime Running Lights NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned On or Off. The feature is only available if allowed by law in the country of the vehicle purchase. Flash Lights With Lock NOTE: When the “Flash Lights With Lock”...
Page 315 MULTIMEDIA Setting Name Selectable Options Sound Horn With Lock 1st Press 2nd Press Sound Horn With Remote Start — If Equipped 1st Press Of Key Fob Unlocks Driver Door All Doors NOTE: When “1st Press Of Key Fob Unlocks: Driver Door” is programmed, only the driver’s door unlocks on the first press of the key fob unlock button. You must ...
Page 316 MULTIMEDIA Key Off Options After pressing the Key Off Options button on the touchscreen, the following settings will be available: Setting Name Selectable Options Key Off Power Delay – NOTE: When the “Engine Off Power Delay” feature is selected, the power window switches, radio, Uconnect phone system (if equipped), power sunroof (if equipped), and power outlets will remain active for up to 10 minutes after the ignition is cycled to OFF.
Page 317 MULTIMEDIA Audio After pressing the Audio button on the touchscreen, the following settings will be available: Setting Name Selectable Options Balance/Fade Front Rear Left Right NOTE: The “Balance/Fade” feature allows you to adjust the Balance and Fade settings. Press and drag the speaker icon or use the arrows to adjust, tap the C icon to readjust to the center.
Page 318 MULTIMEDIA Phone/Bluetooth® Settings After pressing the Phone/Bluetooth® Settings button on the touchscreen, the following settings will be available: Setting Name Selectable Options Do Not Disturb List of Settings NOTE: Press “Do Not Disturb” to access the available settings. The following settings are: Auto Reply (Both, Text, Call), Auto Reply Message (Custom, Default), and Custom Auto Reply Message (Create Message).
Page 319 MULTIMEDIA Setting Name Selectable Options Channel Skip List of Channels NOTE: SiriusXM® can be programmed to designate a group of channels that are the most desirable to listen to or to exclude undesirable channels while scanning. This feature allows you to select the channels you would like to skip. Subscription Info SIRIUS ID NOTE:...
Page 320: Safety And General Information
MULTIMEDIA Setting Name Selectable Options Clear Personal Data Cancel NOTE: When the “Clear Personal Data” feature is selected it will remove all personal data including Bluetooth® devices and presets. System Information — If Equipped After pressing the System Information button on the touchscreen, the following setting will be available: Setting Name Selectable Options Software License...
Page 321: Uconnect 3.0
MULTIMEDIA UCONNECT 3.0 Safe Usage Of The Uconnect System Exposure To Radio Frequency Radiation The internal wireless radio operates within Read all instructions in this manual carefully  NTRODUCTION guidelines found in radio frequency safety before using your system to ensure proper standards and recommendations, which reflect usage.
Page 322: Radio Mode
MULTIMEDIA 8 — MENU 1 — RADIO ADIO Push the RADIO button on the faceplate to enter Push the MENU button on the faceplate to scroll Operating Radio Mode the Radio Mode. The different tuner modes; AM, between the setting submenus. The radio is equipped with the following modes: FM, and SXM (if equipped) can be selected by 9 —...
Page 323 MULTIMEDIA Enter/Browse And Tune/Scroll Control SiriusXM® Satellite Radio Mode — Setting Presets If Equipped Turn the rotary TUNE/SCROLL control knob The Presets are available for all Radio Modes, and clockwise to increase or counterclockwise to are activated by pushing any of the six PRESET SiriusXM®...
Page 324: Media Mode
MULTIMEDIA Speed Adjusted Volume (if equipped) — Select  EDIA Fast SEEK DOWN Speed Adjusted Volume and push the ENTER/ Operating Media Mode Push and hold the SEEK DOWN button on the BROWSE button. Turn the TUNE/SCROLL knob faceplate and the desired mode will begin to to adjust the setting to Off, 1, 2, or 3.
Page 325: Phone Mode
MULTIMEDIA Bluetooth® Mode Controlling The Auxiliary Device The Uconnect Phone is a voice-activated, hands-free, in-vehicle communications system The control of the auxiliary device (e.g., selecting Bluetooth® Streaming Audio (BTSA) or Bluetooth® with Voice Command Capability. Refer to “Voice playlists, play, fast forward, etc.) cannot be Mode is entered by pairing a Bluetooth®...
Page 326 MULTIMEDIA NOTE: NOTE: WARNING! A phone call can also be made with the Uconnect If there is no phones currently connected with the 3.0 by pushing the phone button on the radio, and system, a pop-up will appear asking if you would ALWAYS drive safely with your hands on the selecting a particular contact in the phone book, or like to pair a mobile phone.
Page 327: Uconnect 3 With 5-Inch Display
MULTIMEDIA UCONNECT 3 WITH 5-INCH DISPLAY NOTE: Phonebook Download — Phonebook Some mobile phones will require you to enter the PIN. Transfer From Mobile Phone NTRODUCTION 9. When the pairing process has successfully If equipped and specifically supported by your completed, the system will prompt you to phone, Uconnect Phone will ask you if you want to choose whether or not this is your favorite...
Page 328: Radio Mode
MULTIMEDIA 4 — MORE Push the RADIO button on the faceplate, to enter ADIO the Radio Mode. The different tuner modes – FM/ Push the MORE button on the faceplate to access Operating Radio Mode AM/SXM (if equipped) – can then be selected by additional options.
Page 329 MULTIMEDIA During a Seek Up function, if the radio reaches the Direct Tune Functions SiriusXM® services require subscriptions, sold separately after the trial included with the new starting station after passing through the entire Press the Tune button on the touchscreen to band two times, the radio will stop at the station vehicle purchase.
Page 330 MULTIMEDIA Setting Presets 3. The Audio Menu shows the following options Speed Adjust Volume — Press the Speed  for you to customize your audio settings: Adjusted Volume button on the touchscreen Presets are available for all radio modes and are to select between OFF, 1, 2 or 3.
Page 331: Media Mode
MULTIMEDIA Audio Source Selection Fast Seek Up EDIA Press and hold the Seek Up button on the Once in Media Mode, press the Source button on Operating Media Mode touchscreen and the desired mode will begin to the touchscreen and the desired mode button on fast forward through the current track until the the touchscreen.
Page 332 MULTIMEDIA Track Info AUX Mode Browse Press the Browse button on the touchscreen to Press the Info button on the touchscreen to display AUX Mode is entered by inserting a AUX device select an Artist, Albums, Genres, Songs, Playlists the current track information. Press the X button using a stereo cable with a 3.5 mm audio jack into or Folders from the USB/iPod®...
Page 333: Phone Mode
MULTIMEDIA The Uconnect Phone is a voice-activated, Display and call contacts from the Recent Calls HONE  hands-free, in-vehicle communications system menu. Operating Phone Mode with voice command capability. Refer to Voice Pair up to 10 phones/audio devices to make ...
Page 334 MULTIMEDIA If “No” is selected and you still would like to 1. Place the ignition in the ACC or ON/RUN audio device can be connected to the position. Uconnect system at a time. If the No button is pair a mobile phone, press the Settings but- selected, simply select “Uconnect”...
Page 335 MULTIMEDIA NOTE: 3. Select the Paired Phones or Paired Audio list Setting A Mobile Phone Or A Bluetooth® The names in the phonebook which do not contain using the corresponding button on the display. Audio Device As A Favorite phone numbers or where both fields (name and 4.
Page 336 MULTIMEDIA NOTE: Deletion Of Phone Data (Phonebook And Recent Calls Recent Calls) If supported, the download and update begins The list of the last calls made for each of the  as soon as the Bluetooth® wireless phone following call types can be displayed: Select "Delete Phone Data"...
Page 337 MULTIMEDIA Answering An Incoming Call NOTE: Ending A Call Not all mobile phones support the management of Call Controls Press the End button on the touchscreen or the an incoming call when another phone conversation PHONE button on the steering wheel controls to The buttons on the display allow the following is active.
Page 338: Steering Wheel Audio Controls
MULTIMEDIA STEERING WHEEL AUDIO CONTROLS — If this function is not supported by the phone, the The left-hand control is a rocker type switch with a corresponding message button is deactivated push-button in the center. The function of the IF EQUIPPED (grayed out) or may only accept incoming left-hand control is different depending on which messages.
Page 339: Ipod®/Usb/Mp3 Control - If Equipped
MULTIMEDIA IPOD®/USB/MP3 CONTROL — IF EQUIPPED Refer to the Uconnect Owner’s Manual The internal wireless radio operates within Supplement, the applicable radio section in this guidelines found in radio frequency safety Located inside the center console upper lid, this manual, or visit UconnectPhone.com for further standards and recommendations, which reflect feature allows an iPod®...
Page 340: Uconnect Voice Recognition Quick Tips
MULTIMEDIA UCONNECT VOICE RECOGNITION QUICK TIPS NOTE: Le présent appareil est conforme aux CNR d`Innovation, Science and Economic Development This equipment has been tested and found to  applicables aux appareils radio exempts de comply with the limits for a Class B digital NTRODUCING CONNECT licence.
Page 341: Basic Voice Commands
MULTIMEDIA 4. Each time you give a Voice Command, you ASIC OICE OMMANDS must first push either the VR or Phone button, The basic Voice Commands below can be given at wait until after the beep, then say your Voice any point while using your Uconnect system.
Page 342: Radio
MULTIMEDIA “Change source to Bluetooth®” “Redial (call previous outgoing phone number)” ADIO   “Change source to AUX” “Call back (call previous incoming phone   Use your voice to quickly get to the AM, FM, or number)” “Change source to USB” SiriusXM®...
Page 343: Climate (4C/4C Nav)
MULTIMEDIA TIP: TIP: PRE-DEFINED VOICE TEXT REPLY Voice Text Reply is not compatible with iPhone®, To start a POI search, push the VR button on the RESPONSES but if your vehicle is equipped with Siri® Eyes Free, steering wheel. After the beep, say: “Find nearest Stuck in you can use your voice to send a text message.
Page 344: Android Auto™ - If Equipped
MULTIMEDIA ® — I Do Not Disturb can automatically reply with a text system, and use your smartphone’s data plan to PPLE QUIPPED message, a call or both, when declining an project your Android™-powered smartphone and a NOTE: incoming call and send it to voicemail. number of its apps onto your Uconnect Feature availability depends on your carrier and touchscreen.
Page 345: General Information
MULTIMEDIA NOTE: Le présent appareil est conforme aux CNR DDITIONAL NFORMATION d`Innovation, Science and Economic Development Requires compatible iPhone®. See dealer for © 2021 FCA US LLC. All rights reserved. Mopar and applicables aux appareils radio exempts de phone compatibility. Data plan rates apply. Vehicle Uconnect are registered trademarks and Mopar licence.
Page 346: Customer Assistance
CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE This is why you should always talk to an authorized EASONABLE EQUESTS dealer service manager first. Most matters can be FOR YOUR VEHICLE If you list a number of items and you must have resolved with this process.
Page 347: Fca Us Llc Customer Center
CUSTOMER ASSISTANCE FCA US LLC C Identification Card in the mail within three weeks USTOMER ENTER USTOMER SSISTANCE of the vehicle delivery date. If you have any EARING PEECH MPAIRED P.O. Box 21–8004 questions about the service contract, call the (TDD/TTY) manufacturer's Service Contract National Auburn Hills, MI 48321–8004...
Page 348: Warranty Information
CUSTOMER ASSISTANCE REPORTING SAFETY DEFECTS To contact NHTSA, you may call the WARNING! Vehicle Safety Hotline toll free at 50 U Engine exhaust (internal combustion engines NITED TATES 1-888-327-4236 (TTY: only), some of its constituents, and certain , D.C. 1-800-424-9153); or go to http:// ASHINGTON vehicle components contain, or emit, chemicals www.safercar.gov;...
Page 349: Publication Order Forms
CUSTOMER ASSISTANCE PUBLICATION ORDER FORMS Diagnostic Procedure Manuals Owner's Manuals Diagnostic Procedure Manuals are filled with These Owner's Manuals have been prepared with To order the following manuals, you may use either diagrams, charts and detailed illustrations. These the assistance of service and engineering the website or the phone numbers listed below.
Page 350 INDEX .............80 Air Cleaner, Engine (Engine Air Ashtray ....259 ..........250 ..........124 Adding Engine Coolant (Antifreeze) Cleaner Filter) Assist, Hill Start ............193 ......251 ........293 Adding Fuel Air Conditioner Maintenance Audio Systems (Radio) ..........288 ....251 ......64 Additives, Fuel Air Conditioner Refrigerant Auto Down Power Windows .........
Page 351 Cargo Light ............42 Cooling System ..........258 Battery ..........110 Cellular Phone ..........337 Adding Coolant (Antifreeze) ...... 259 Charging System Light .......110 Center High Mounted Stop Light ....224 Coolant Level ........258 Keyless Key Fob Replacement ....15 Center Seat Storage Compartment ....74 Cooling Capacity...
Page 352 ............245 ........164 Disposal Engine Exhaust System .......260 ..........250 ........39 Antifreeze (Engine Coolant) Air Cleaner Exterior Lights ............341 ..........169 Disturb Block Heater ............111 ..... 170 Door Ajar Break-In Recommendations ..........111 ........245 Door Ajar Light Compartment Filters .....
Page 353 Fuel ...............287 Adding ............193 Hazard Ignition .............17 Additives ...........288 Driving Through Flowing, Rising, Or Shallow Switch ............17 Clean Air ............288 Standing Water ........209 Illuminated Entry ..........45 Ethanol ............288 Hazard Warning Flashers ......211 In Case Of Emergency ........211 Filler Cap (Gas Cap) ........194 Head Restraints...
Page 354 ....... 122 ....... 180 Brake Assist Warning Limited-Slip Differential .......... 109 ..... 106 Key Fob Brake Warning Load Shed Battery Saver Mode ..........15 ........221 ......106 Panic Alarm Bulb Replacement Load Shed Battery Saver On ..16 ............42 ...
Page 355 Mirrors ............. 35 Oil, Engine ..........248 Pedals, Adjustable ...........34 Electric Powered ......... 36 Capacity ............ 290 Pets ............... 163 Heated ............38 Change Interval ........248 Pickup Box ............81 Outside ............36 Dipstick ............ 247 Placard, Tire And Loading Information ..
Page 356 ........275 ......133 Replacement Tires Operating Instructions ..........273 ......346 ........136 Radial Ply Tires Reporting Safety Defects Pregnant Women .. 258 ........... 146 ........... 136 Radiator Cap (Coolant Pressure Cap) Restraints, Child Pretensioners ..........337 ..........31 ..........130 Radio Operation Restraints, Head Reminder ......
Page 357 Shifting ............171 Steering Tires ........166 Automatic Transmission ......172 Power ............180 Aging (Life Of Tires) ........274 Transfer Case, Shifting Into Transfer Case Tilt Column ..........33 Air Pressure ..........272 Neutral (N) ..........207 Wheel, Heated ..........33 Chains ............279 Transfer Case, Shifting Out Of Transfer Case Wheel, Tilt ............33...
Page 358 ............195 Towing ........238 Disabled Vehicle Uconnect Warning Lights (Instrument Cluster ............198 ........301 ..........112 Guide Uconnect Settings Descriptions) ..........205 ........12 Recreational Uconnect Phone Warnings And Cautions ............198 ........336 ........346 Weight Call Continuation Warranty Information ......205 ......45 Towing Behind A Motorhome Uconnect Settings Washers, Windshield...
Page 359 It is always the driver’s responsibility to comply with all local laws. This Owner’s Manual has been prepared to help you get acquainted with your new Ram brand vehicle and to provide a convenient reference for common questions.
Page 360 ©2021 FCA US LLC. All Rights Reserved. Tous droits réservés. Ram is a registered trademark of FCA US LLC. Ram est une marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.

RAM 1500 CLASSIC 2020 Owner's Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RAM 1500 CLASSIC 2020

Summary of Contents for RAM 1500 CLASSIC 2020
