Cat.No. N92–E1–1
K3NH
Temperature Meter
OPERATION MANUAL
AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K3NH and is the answer not in the manual?

Questions and answers

Related Manuals for Omron K3NH

Summary of Contents for Omron K3NH

  • Page 1 Cat.No. N92–E1–1 K3NH Temperature Meter OPERATION MANUAL AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr...
  • Page 2 K3NH Temperature Meter Operation Manual Produced January 1998 AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr...
  • Page 3 OMRON. No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is constantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS PRECAUTIONS ....... . . 1 General Precautions .
  • Page 5 TABLE OF CONTENTS Appendices A Specifications ............. . B Available Models .
  • Page 6 About this Manual: This manual describes the installation and operation of the K3NH Temperature Meter and includes the sections described below. Please read this manual carefully and be sure you understand the information provided before attempting to install and operate the K3NH.

  • Page 7: Precautions

    This section provides precautions for using the K3NH Temperature Meter and related devices. The information contained in this section is important for the safe and reliable application of the K3NH. You must read this section and understand the information contained before attempting to set up or operate the K3NH.

  • Page 8: General Precautions

    OMRON representative. Be sure to read this manual before attempting to use the product and keep this manual close at hand for reference during operation.

  • Page 9: Noise Prevention

    Noise Prevention Section Noise Prevention Provide the following countermeasures when using the product in an environ- ment where the product is exposed to noise. • Countermeasures for protecting the product against high-frequency noise or abnormal voltages. Line filter Temperature Power Meter input + + +...

  • Page 10: Introduction

    SECTION 1 Introduction This section describes the functions of the K3NH. The main components are also described. Refer to the remaining sections of this manual for the operation of the K3NH and its menus in detail. Features ..............

  • Page 11: Features

    K3NH. The teaching function can be used to set the set and scaling values. It can be also used to set the linear output range of the K3NH with a Linear Output Board. Refer to 5-1 Teaching Function for details.

  • Page 12: Front Of The Meter

    Setting Mode: Displays the menu, parameter, or setting value. When chang- ing a value, all digits other than those that can be set become dimmer. K3NH-jjjC Set Value LED Display Model RUN Mode: Displays the process, maximum, and minimum values.
  • Page 13 Front of the Meter Section 1-2 Status Indicators HOLD Indicator Lit when the HOLD input signal is ON. MAX Indicator Lit when the value displayed on the PV display is the maximum value. MIN Indicator Lit when the value displayed on the PV display is the minimum value. PROG Indicator Lit when the setting mode menu is displayed.
  • Page 14 Front of the Meter Section 1-2 The value increases in the following order: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, (–1), and (–) Only the leftmost digit will be displayed if the value is set to “–1” or“ –.” The value will be set to 0 if this key is pressed when “9”...

  • Page 15: Rear Of The Meter

    For wiring, refer to Section 2 Setup. K3NH with Relay Output Board, K31-C1, -C2, -C5 K3NH with Transistor Output Board, K31-T1, -T2 K3NH with Linear Output Board, K31-L1, -L2, -L3, -L4, -L5, -L6, -L7, -L8, -L9, -L10 K3NH with RS-485 Output Board, K31-FLK2, -FLK5 Output Board...

  • Page 16: Modes

    RUN Mode K3NH is in RUN when the K3NH is turned ON. The K3NH in this mode provides an output signal as a result of the comparison of the measured and setting values. AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr...

  • Page 17: Communications Function

    Refer to Section 4 Operations in RUN Mode for RUN mode in detail. Setting Mode Values are set in the K3NH in this mode by key input or using the teaching func- tion. Refer to Section 3 Parameter Setting for value setting by key input and 5-1 Teaching Function for the teaching function in detail.

  • Page 18: Setup

    SECTION 2 Setup This section provides instructions required for mounting and wiring the K3NH. Mounting ............. . .

  • Page 19: Mounting

    Section 2-1 Mounting Mounting Dimensions All dimensions are in millimeters. PV LED Indicator Size 14.2 mm 8.2 mm Panel Cutouts +0.8 –0 75 min. +0.8 –0 120 min. Recommended panel thickness is 1 to 3.2 mm. Do not mount more than one Unit closely in the horizontal or vertical direction. Be sure to keep the distance between adjacent Units.

  • Page 20: Input Block

    Panel 1, 2, 3... 1. Insert the K3NH into the mounting hole on the panel. 2. Hook the fixture claws onto the side holes. 3. Mount a fixing metal to the right and left sides as shown above and while keeping them in balance, alternately tighten each screw until the ratchet be- comes idle.

  • Page 21: Wiring Precautions

    2-2-2 Wiring Precautions • Do not make any mistake in polarity when supply DC power to the K3NH. • Do not wire power lines alongside the signal lines of the K3NH in order to pre- vent against noise interference. • Wire the terminal block with crimp terminals •...
  • Page 22 Input Block Section 2-2 Voltage/Current Input Connect sensor output to terminals 12 through 14. Voltage input Current input Connect a sensor with an output of 0 to 5 V, 1 to 5 V, or 0 to 10 V to terminals 12 through 14.

  • Page 23: Output Board

    K3NH with Relay Output Board, K31-C1, -C2, -C5 K3NH with Transistor Output Board, K31-T1, -T2 K3NH with Linear Output Board, K31-L1, -L2, -L3, -L4, -L5, -L6, -L7, -L8, -L9, -L10 K3NH with RS-485 Output Board, K31-FLK2, -FLK5 K3NH with BCD Output Board, K31-B2, -B4 K3NH with RS-232C + Transistor Output Board, K31-FLK4 AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr...
  • Page 24 Output Board Section 2-3 K3NH with RS-422 + Transistor Output Board, K31-FLK6 K3NH with RS-232C Output Board, K31-FLK1 K3NH with RS-422 Output Board, K31-FLK3 AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr...

  • Page 25: Relay Output Board

    Board, K31-B2 or K31-B4 Transistor Output Boards, K31-FLK4 K3NH with Linear Output Board, K31-L4, -L5, -L6, -L9, -L10 K3NH with RS-422 + 5 Transistor Output Boards, K3NH with RS-485 + 5 Relay K31-FLK6 Output Boards, K31-FLK5 HH comparative HH comparative HH comparative output...

  • Page 26: Linear Output Board

    Maximum rated voltage: 24 VDC Load current: 50 mA Current leakage with transistor turned off: 100 µA. 2-3-4 Linear Output Board The following figures show connections for linear output. K3NH with Linear K3NH with Linear K3NH with Linear Output Board, Output Board,...

  • Page 27: Parameter Setting

    SECTION 3 Parameter Setting This section provides instructions for setting the parameters of the K3NH with key inputs. Be sure to read this section before using the K3NH Temperature Meter for the first time. Overview ............. . .

  • Page 28: Overview

    K3NH will vary depending on the Output Board installed. Refer to Appendix D Available Parameters. • The K3NH is in RUN mode when the K3NH is turned on. Parameter settings in protect or setting mode are described below on the basis that the parameters are set for the first time.

  • Page 29: Setting Mode

    Setting Mode 3-2-1 Selecting Setting Mode • The K3NH in RUN mode will go into setting mode if the Mode Key is pressed for 1 s minimum. • The K3NH in setting mode will go into RUN mode if the Escape Key is pressed.

  • Page 30: Menu Overview

    Setting Mode Section 3-2 3-2-2 Menu Overview Press the Mode and Shift Keys while turning the K3NH on. Maintenance Mode RUN Mode Power On Refer to Section 5 Useful Functions. Refer to Section 4 RUN Mode Operations. Press the Escape and Protect Mode Up Keys for 1 second.

  • Page 31: Hh Set Value (Su.hh)

    Refer to 5-1 Teaching Function. Refer to 4-1 Displaying and Changing Set Values. REFERENCE • The setting value menu is only available for K3NH with Comparative Output Board. MODELS AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr...
  • Page 32 Setting Mode Section 3-2 SETTING Follow the steps described below to input the following. EXAMPLE Setting value HH = “400” Setting value H = “300” Setting value L = “200” Setting value LL = “100” Set Value LED Display Model Basic Model 1.
  • Page 33 Setting Mode Section 3-2 6. Press the Up and Shift Keys to set the value to 300. The input will be vali- dated automatically if no change is made for five seconds. The sU. h H set- ting value setting will be displayed again. Note Press the Mode Key to enter the set value immediately.
  • Page 34 Setting Mode Section 3-2 12. Press the Up and Shift Keys to set the value to 100. The input will be vali- dated automatically if no change is made for five seconds. The sU.ll LL set- ting value setting will be displayed again. Note Press the Mode Key to enter the set value immediately.

  • Page 35: Setup Menu (Setup)

    Setting Mode Section 3-2 3-2-4 Setup Menu (setup) in t Input Type The following table lists the types of thermocouples, temperature-resistance thermometers, voltage, and current available to the K3NH. FUNCTION Default Settings: K1 Input type Setting Input type Setting JPt100...
  • Page 36 Setting Mode Section 3-2 3. Repeatedly press the Up Key until j2 ic is displayed. The displayed setting will be validated automatically if no change is made for five seconds. The in t input range setting will be displayed again. Set Value LED Display Model Basic Model When no operation is executed for five seconds...

  • Page 37: Temperature Unit (C F)

    Setting Mode Section 3-2 Temperature Unit The following menu settings determine the unit of measured temperature. FUNCTION Setting Default c: °C f: °F SETTING SETTING Follow the steps described below to set the temperature unit to °F. EXAMPLE Set Value LED Display Model Basic Model 1.
  • Page 38 Setting Mode Section 3-2 When no operation is executed for five seconds Set Value LED Display Model Basic Model Note Press the Mode Key to enter the displayed setting immediately. The next parameter will be displayed for setting. AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr...

  • Page 39: Scaling Upper Limit Value (In H)

    For example, if a sensor with 4- to 20-mA output is connected to the K3NH and the K3NH is set so that it will display “0” for 4-mA input and “999” for 20-mA input, the following will be the relationship between input and display values.
  • Page 40 Setting Mode Section 3-2 Refer to 5-1 Teaching Function. REFERENCE SETTING Follow the steps described below to input the following. EXAMPLE Scaling upper limit value = “500” Scaling lower limit value = “100” Decimal point position = “%%%.%” Set Value LED Display Model Basic Model 1.
  • Page 41 Setting Mode Section 3-2 6. Press the Shift Key to display the present set value 000 for changing. The PROG indicator will flash. Set Value LED Display Model Basic Model 7. Press the Up and Shift Keys to set the value to 100. The input value will be validated automatically if no change is made for five seconds.

  • Page 42: Communications Unit Number (U No)

    • Set a communications unit number as an identification number by which the host computer is connected to the K3NH. • If more than one K3NH is connected in parallel, make sure that each commu- FUNCTION nications unit number is unique.
  • Page 43 Setting Mode Section 3-2 3. Press the Shift Key to display the prior set value 00 for changing. The PROG indicator will flash. Set Value LED Display Model Basic Model 4. Press the Up and Shift Keys to set the value to 15. The input value will be validated automatically if no change is made for five seconds.

  • Page 44: Word Length (Len)

    Setting Default none: None eUen eUen: Even odd: Odd This setting is available for the K3NH with the Communications Output Board. MODELS SETTING Follow the steps described below to set the following. EXAMPLE Word length: 8 bits Number of stop bits: 1...
  • Page 45 Setting Mode Section 3-2 3. Press the Shift Key to display the prior set value 7 for changing. The PROG indicator will flash. Set Value LED Display Model Basic Model 4. Press the Up Key to set the value to 8. The input value will be validated auto- matically if no change is made for five seconds.
  • Page 46 Setting Mode Section 3-2 10. Press the Up Key to display none. The setting will be validated automatically if no change is made for five seconds. The prty parity bit setting will be dis- played again. Note Press the Mode Key to enter the setting immediately. The next pa- rameter will be displayed for setting.

  • Page 47: Option Menu (Opt)

    Setting Mode Section 3-2 3-2-5 Option Menu (opt) Average Processing • The average processing of inputs are enabled for setting. • Average processing prevents the display from fluctuating due to unstable in- put. FUNCTION • Select simple average processing or movement average processing and the number of sampling times.
  • Page 48 Setting Mode Section 3-2 Input value Display value Movement average processing Simple Average Processing: The average value is displayed after the input is sampled “n” times. The previous value is displayed until the sampling is complete. Simple average processing is ideal for a display refresh period that is compara- tively long.
  • Page 49 Setting Mode Section 3-2 3. Repeatedly press the Up Key until m0016 is displayed. The setting will be validated automatically if no change is made for five seconds. The aUg aver- age processing setting will be displayed again. Note Press the Mode Key to enter the set value immediately. The next pa- rameter will be displayed for setting.

  • Page 50: Display Digit Change (Digit)

    Section 3-2 digit Display Digit Change • The number of digits of data displayed by the K3NH is set in the option menu. • A maximum of four digits can be set regardless of the number of actual digits. FUNCTION...
  • Page 51 Setting Mode Section 3-2 When no operation is executed for five seconds Set Value LED Display Model Basic Model AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr...

  • Page 52: Upper-Limit Compensation Value (Insh)

    Setting Mode Section 3-2 insh Upper-limit Compensation Value insl Lower-limit Compensation Value The upper- and lower-limit values of the sensor can be shifted. If both the upper- and lower-limit values are shifted by 2°C each, for example, a process value of 200°C will be treated as 202°C after compensation.
  • Page 53 Setting Mode Section 3-2 3. Press the Shift Key to display present set value 0000 for changing. The PROG indicator will flash. Set Value LED Display Model Basic Model 4. Press the Up Key to set the value to 2. The setting will be validated automati- cally if no change is made for five seconds.

  • Page 54: Hysteresis (Hys)

    Hysteresis Hysteresis L setting value H comparative output L comparative output This setting is only available for the K3NH with the Comparative Output Unit. MODELS SETTING Follow the steps described below to set the hysteresis to 30. EXAMPLE Set Value LED Display Model Basic Model 1.
  • Page 55 Setting Mode Section 3-2 2. Repeatedly press the Mode Key until the hys hysteresis setting is displayed. Set Value LED Display Model Basic Model 3. Press the Shift Key to display the prior set value 0001 for changing. The PROG indicator will flash. Set Value LED Display Model Basic Model 4.

  • Page 56: Comparative Output Pattern (C Out)

    Setting Mode Section 3-2 c out Comparative Output Pattern • The pattern of HH, H, L, LL, and PASS comparative outputs is set in the option menu. FUNCTION Setting Default nomal: Standard output nomal =one: Zone output SETTING leUel: Level output Standard Output H or HH Comparative Output: Turns ON when the measured value is larger than the H or HH setting value.
  • Page 57 Setting Mode Section 3-2 Level Output LL, L, H, or HH Comparative Output: Turns ON when the measured value exceeds the LL, L, H, or HH setting value. PASS Output: Turns ON when the LL, L, H, and HH comparative outputs are all OFF. HH setting value Measured value H setting value...
  • Page 58 Setting Mode Section 3-2 This setting is only available for the K3NH with the Comparative Output Units. MODELS SETTING Follow the steps described below to set the comparative output pattern to level output. EXAMPLE Set Value LED Display Model Basic Model 1.

  • Page 59: Standby Sequence (Stdby)

    Standby Sequence When the K3NH is tuned on, the K3NH will have no output until the measured value is within the PASS range. This function avoids unnecessary output until the output is within the measurement range after the power is turned ON.
  • Page 60 Setting Mode Section 3-2 When no operation is executed for five seconds Set Value LED Display Model Basic Model AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr...

  • Page 61: Upper Limit (H) Of Linear Output Range (Lset.h)

    Lower Limit (L) of Linear Output Range Linear output setting is made in the option menu to enable the K3NH to have voltage or current output in proportion to the change in display value. • The maximum and minimum values of linear output are set in this parameter.
  • Page 62 Setting Mode Section 3-2 SETTING Follow the steps described below to set the following. EXAMPLE H: 100 L: 0 Set Value LED Display Model Basic Model 1. Press the Mode Key for more than one second while the opt option menu is 1, 2, 3...
  • Page 63 Setting Mode Section 3-2 7. Press the Up and Shift Keys to set the value to 0000. The setting will be vali- dated automatically if no change is made for five seconds. The lset.l L lin- ear output range setting will be displayed again. Note Press the Mode Key to enter the set value immediately.

  • Page 64: Remote/Local Programming (R L)

    Section 3-2 Remote/Local Programming • The K3NH can be set to remote or local mode in the option menu. The K3NH in remote mode is operated through the host computer and the K3NH in local mode is operated through the front panel key input.
  • Page 65 Setting Mode Section 3-2 5. The setting will be validated automatically if no change is made for five se- conds. The aUg average processing setting will be displayed again. Note Press the Mode Key to enter the setting immediately. The r l re- mote/local setting will be displayed again.

  • Page 66: Protect Mode

    Protect Mode 3-3-1 Selecting Protect Mode • The K3NH in RUN mode will go into protect mode if the Escape and Up Keys are pressed for more than 1 second. • The K3NH in protect mode will go into RUN mode if the Escape Key is pressed.

  • Page 67: Menu Overview

    Protect Mode Section 3-3 3-3-2 Menu Overview Press the Mode and Shift Keys Maintenance Mode while turning the K3NH on. Power On Refer to Section 5 Useful Functions. RUN Mode Press the Mode Refer to Section 4 Operations in RUN Mode.

  • Page 68: All Key Protect (All)

    Protect Mode Section 3-3 3-3-3 Protect Menu (prot) All Key Protect • The operation of all keys can be prohibited in the protect menu. FUNCTION Setting Default kpon: Key protect ON kpoff kpoff: Key protect OFF SETTING SETTING Follow the steps described below to set the key protect to ON. EXAMPLE Set Value LED Display Model Basic Model...

  • Page 69: Setting Value Change Prohibit (Suset)

    Protect Mode Section 3-3 sUset Setting Value Change Prohibit • The setting value change of the K3NH in RUN mode with the front-panel key inputs can be prohibited in the protect menu. FUNCTION Setting Default kpon: Key protect ON kpoff...
  • Page 70 Protect Mode Section 3-3 4. Press the Up Key to display kpon. The setting will be validated automatically if no change is made for five seconds. The sUset setting value prohibit set- ting will be displayed again. Note Press the Mode Key to enter the setting immediately. The next pa- rameter will be displayed for setting.

  • Page 71: Maximum/Minimum Value Clear Prohibit (Mm.rst)

    Protect Mode Section 3-3 mm.rst Maximum/Minimum Value Clear Prohibit • The resetting of maximum and minimum values with key input can be prohib- ited in the protect menu. However, the resetting of maximum and minimum values with external signal FUNCTION input is permitted.
  • Page 72 Protect Mode Section 3-3 4. Press the Up Key to display kpon. The setting will be validated automatically if no change is made for five seconds. The mm.rst maximum/minimum value clear prohibit setting will be displayed again. Note Press the Mode Key to enter the setting immediately. The next pa- rameter will be displayed for setting.

  • Page 73: Security (Secr)

    Protect Mode Section 3-3 secr Security • Settings in setting mode can be prohibited in the protect menu. • The following table shows what set values for menus can be prohibited. The default is 0. FUNCTION Set value Menu Setting value Prohibited SETTING Scaling...
  • Page 74 Protect Mode Section 3-3 4. Press the Up Key to display 1. The setting will be validated automatically if no change is made for five seconds. The secr security setting will be dis- played again. Note Press the Mode Key to enter the setting immediately. The next pa- rameter will be displayed for setting.

  • Page 75: Operations In Run Mode

    SECTION 4 Operations in RUN Mode This section provides instructions for operating the K3NH in RUN mode. Displaying and Changing Setting Values ........

  • Page 76: Displaying Setting Values

    4-1-1 Displaying Setting Values Basic Model • When the Mode Key is pressed in RUN mode, the K3NH displays a setting val- ue on the PV display (in the order of HH, H, L, and LL). • While the setting value is displayed, the corresponding SV display status indi- cator is lit.
  • Page 77 • Repeatedly press the Mode Key until the process value appears. • Leave the K3NH with no key input for five seconds. AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr...
  • Page 78 Displaying and Changing Setting Values Section 4-1 SETTING EXAMPLE Set Value LED Display Follow the steps below to change the H setting value from 600 to 700 while the Model process value is displayed in RUN mode, provided that the HH setting value is already displayed on the SV display.

  • Page 79: Displaying And Resetting Of Maximum And Minimum Values

    The external RESET input signal is turned ON. The K3NH receives the reset command through communications. • When the K3NH is reset, the maximum and minimum values are set to the pro- cess value. Note The K3NH cannot be reset with the Reset/Teach Key if the maximum/minimum value clear prohibit is ON in protect mode.

  • Page 80: External Input Signals

    4-3-2 HOLD • The K3NH will stop the measurement if the HOLD input is ON. • When the HOLD input is ON, the K3NH will retain the process value, output, and BCD data effective immediately before the HOLD input. • The HOLD indicator is lit while HOLD input is ON.

  • Page 81: Useful Functions

    SECTION 5 Useful Functions This section provides information on the teaching function, output test, and maintenance mode. Teaching Function ............5-1-1 Set Value .

  • Page 82: Teaching Function

    Teaching Function Teaching Function • The K3NH is provided with a teaching function that can set an actual measured value as a set value without any front panel key input. This function is useful for setting parameters while checking the operating sta- tus of the K3NH.

  • Page 83: Linear Output Range

    5-1-2 Linear Output Range The teaching function can be also used to set the linear output range of the K3NH with the Linear Output Board. • The H and L linear output ranges can be set using the actual measured value instead of key input in the option menu.

  • Page 84: Output Test

    • Follow the steps described below to perform the test. 1, 2, 3... 1. While the K3NH is in RUN mode, press the Mode Key for more than one se- cond to set the K3NH to the setting mode. 2. Repeatedly press the Mode Key until test output test setting is displayed.

  • Page 85: Maintenance Mode

    Maintenance Mode Section 5-3 Maintenance Mode The set values of the K3NH can be initialized and field calibration of the K3NH is possible in maintenance mode. The operations of the K3NH in this mode are de- scribed below. 5-3-1 Maintenance Mode •...

  • Page 86: Field Calibration

    Maintenance Mode Section 5-3 4. Press the Up Key to display yes. Press the Mode Key to initialize all set val- ues. The K3NH will go into RUN mode. Set Value LED Display Model Basic Model RUN mode 5-3-3 Field Calibration Calibration is to be performed when adjustment is required for display accuracy exceeding the specified value.

  • Page 87: Thermocouple Calibration

    • The data registration setting str does not appear unless all calibration items are tentatively registered. Procedure for Field Calibration 1, 2, 3... 1. Press the Mode and Shift Keys simultaneously while turning the K3NH on to display mant maintenance mode setting. Set Value LED Display Model Basic Model 2.
  • Page 88 Short-cir- Cold junction compensator Cold junction compensator cuiting K3NH K3NH Open Compensating conductor Compensating conductor Thermocouple Group 1 Calibration 1. First, the sUre alarm display will appear. This will not appear once field cal- 1, 2, 3...
  • Page 89 Maintenance Mode Section 5-3 value stabilizes (i.e., the fluctuation of the value is less than several digits), press the Mode Key to tentatively register the calibration data. Set Value LED Display Model Basic Model 4. The display will change to 1t 0 for 0-mV calibration. The teaching indicator will be lit.
  • Page 90 Basic Model 14. Press the Up Key to select yes. 15. Press the Mode Key to overwrite all calibration data and to put the K3NH into RUN mode. The calibration data will not be overwritten if no is selected. Set Value LED Display Model...
  • Page 91 Maintenance Mode Section 5-3 Thermocouple Group 2 Calibration 1. First, the sure alarm display will appear. This will not appear once field cal- 1, 2, 3... ibration is performed. Set Value LED Display Model Basic Model 2. Press the Mode Key to display 2ts0. The teaching indicator will be lit. Then calibrate the main input.
  • Page 92 Maintenance Mode Section 5-3 the value stabilizes (i.e., the fluctuation of the value is less than several dig- its), press the Mode Key to tentatively register the calibration data. Set Value LED Display Model Basic Model 8. The display will change to k 0 for 0-mV calibration. The teaching indicator will be lit.

  • Page 93: Temperature-Resistance Thermometer Calibration

    Basic Model 14. Press the Up Key to select yes. 15. Press the Mode Key to overwrite all calibration data and to put the K3NH into RUN mode. The calibration data will not be overwritten if no is selected. Set Value LED Display Model...
  • Page 94 Maintenance Mode Section 5-3 3. Press the RESET/TEACH Key to display the calibration value setting. Then set Dial 6 to 300 Ω. The teaching indicator will flash. After the value stabilizes (i.e., the fluctuation of the value is less than several digits), press the Mode Key to tentatively register the calibration data.
  • Page 95 Basic Model 12. Press the Up Key to select yes. 13. Press the Mode Key to overwrite all calibration data and to put the K3NH into RUN mode. The calibration data will not be overwritten if no is selected. Set Value LED Display Model...

  • Page 96: Current Input Calibration

    Maintenance Mode Section 5-3 5-3-6 Current Input Calibration Preparation Connect an STV to input terminals 13 and 14. 100 to 240 VAC 12 to 24 VDC Calibration 1. First, the sure alarm display will appear. This will not appear once field cal- 1, 2, 3...

  • Page 97: Voltage Input Calibration

    Basic Model 8. Press the Up Key to select yes. 9. Press the Mode Key to overwrite all calibration data and to put the K3NH into RUN mode. The calibration data will not be overwritten if no is selected. Set Value LED Display Model...
  • Page 98 Maintenance Mode Section 5-3 Calibration (0 to 5 V or 1 to 5 V) 1. First, the sure alarm display will appear. This will not appear once field cal- 1, 2, 3... ibration is performed. Set Value LED Display Model Basic Model 2.
  • Page 99 Basic Model 8. Press the Up Key to select yes. 9. Press the Mode Key to overwrite all calibration data and to put the K3NH into RUN mode. The calibration data will not be overwritten if no is selected. Set Value LED Display Model...
  • Page 100 Basic Model 8. Press the Up Key to select yes. 9. Press the Mode Key to overwrite all calibration data and to put the K3NH into RUN mode. The calibration data will not be overwritten if no is selected. Set Value LED Display Model...

  • Page 101: Bcd Output

    SECTION 6 BCD Output This section provides information on the use of the K3NH with the BCD Output Board. Connectors ............. .

  • Page 102: Connectors

    Section 6-1 Connectors Connectors Terminal Arrangement Terminal Signal name Signal number direction GND:VO (See note 1.) RD1-1 Output 1: Read data 10 digit RD1-2 Output 2: Read data 10 digit RD1-4 Output 4: Read data 10 digit RD1-8 Output 8: Read data 10 digit RD2-1 Output...
  • Page 103 Plug: XM2A-3701 (OMRON) Hood: XM2S-3711 (OMRON) The depth required for the installation of the K3NH is 200 mm min. in consider- ation of the space required by the cable. Connecting Conditions Refer to the following for the connecting conditions of each I/O. Refer to 2-3 Out- put Block for output signals HH through LL.
  • Page 104 Section 6-1 Connectors Connection Example SYSMAC Programmable Controller Temperature Meter DC Input Unit 23.DSV Transistor Output Unit DC power supply Note 1. Connect RD2-1 through RD2-4, RS3-1 through RS3-4, RD4-1 through RD4-4, and RD5-1 through RD5-4 in the same way as RD1-1 through RD1-4.

  • Page 105: Timing Charts

    The polarity of the data must be checked with a POLARITY signal. The polarity is positive when the POLARITY signal is OFF and negative when the POLARITY signal is ON. The K3NH in output test has test data output regardless of the type of REQ sig- nal. Operating Conditions The RUN signal is turned ON in RUN or output test.

  • Page 106: Troubleshooting

    SECTION 7 Troubleshooting This section provides information for troubleshooting the K3NH. Items to Be Checked First ..........

  • Page 107: Items To Be Checked First

    The internal memory has an error. Remedy Turn the K3NH off and on. If the memory error still exists, the K3NH will need to be repaired. If the K3NH returns to normal operation, the K3NH may have been affected by noise. Check if there is any source of noise generation near the K3NH.
  • Page 108 Output Error Meaning of Error The internal circuit has an error. Remedy Turn the K3NH off and on. If the output error still exists, the K3NH will need to be repaired. s.err Sensor Error Meaning of Error The input has an error.

  • Page 109: A Specifications

    Appendix A Specifications Ratings Supply voltage 100 to 240 VAC (50/60 Hz); 12 to 24 VDC Operating voltage range 85% to 110% of supply voltage Power consumption (see note) 15 VA max. (max. AC load with all indicators lit) 10 W max. (max. DC load with all indicators lit) Insulation resistance 20 MΩ...
  • Page 110 Baud rate 1,200/2,400/4,800/9,600/19,200/38,400 bps Transmission code ASCII (7-bit) Communicatio Write to K3NH Comparative set value, prescaling value, remote/local programming, reset control of maximum/minimum values, and other setting mode items excluding communications conditions. Read from Process value, comparative set value, maximum value, minimum value, model...
  • Page 111 Appendix A Specifications Characteristics Indication accuracy (at 23±5°C) Thermocouple: (±0.3% of indication value or ±1°C, whichever greater) ±1 digit max. (see note) Platinum resistance thermometer: (±0.2% of indication value or ±0.8°C, whichever greater) ±1 digit max. Analog input: ±0.2% FS ±1 digit max. Input Thermocouple: K, J, T, E, L, U, N, R, S, B, W, PLII Platinum resistance thermometer: JPt100, Pt100...

  • Page 112: B Available Models

    Base Units Supply voltage Model 100 to 240 VAC 12 to 24 VDC Basic Models K3NH-TA1A K3NH-TA2A These models provide a present value LED and front-panel control keys. Can be connected to any Output Board, or can be used for display only without an Output Board.
  • Page 113 Base Units and Output Boards can be ordered individually or as sets. Refer to the Available Output Board Com- binations table on page 107. Base Units Output Boards Base Units with Output Boards K3NH - K31 - K3NH - 2 3 4 2 3 4 1, 2.

  • Page 114: C List Of Settings

    Appendix C List of Settings Use this sheet to keep a record of set values. Menu Parameter Setting range Unit Set value sUset sU.hh HH set value –1999 to 9,999 Setting value menu sU. h H set value –1999 to 9,999 sU.

  • Page 115: D Available Parameters

    Appendix D Available Parameters Available parameters vary with the output board of the K3NH and are indicated as “YES” in the following table. Setting Mode Output board Menu Parameter C2/C5 L1/L2/ L4/L5/ FLK1/ FLK4/ output /T1/T2 L6/L9/ FLK2/ FLK5/ L7/L8...
  • Page 116 Appendix D Available Parameters Protect Mode Output board Menu Parameter C2/C5 L1/L2/ L4/L5/ FLK1/ FLK4/ output /T1/T2 L3/L7/ L6/L9/ FLK2/ FLK5/ FLK3 FLK6 prot All key protect Protect sUset Set value change menu prohibit mm.rst Maximum/Minimum value clear prohibit secr Security AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr...

  • Page 117: Index
