Specifications; Absolute Maximum Ratings; Esd Ratings; Recommended Operating Conditions - Texas Instruments SimpleLink CC2652PSIP Manual

CC2652PSIP
SWRS263A – FEBRUARY 2021 – REVISED JUNE 2022

8 Specifications

8.1 Absolute Maximum Ratings

over operating free-air temperature range (unless otherwise noted)
(3)
VDDS Supply voltage
Voltage on any digital pin
V Voltage on ADC input
in
Input level, RF pin
T Storage temperature
stg
(1) Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions beyond those indicated under Recommended Operating
Conditions is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
(2) All voltage values are with respect to ground, unless otherwise noted.
(3) VDDS_DCDC, VDDS2 and VDDS3 must be at the same potential as VDDS.
(4) Including analog capable DIOs.
(5) Injection current is not supported on any GPIO pin

8.2 ESD Ratings

V Electrostatic discharge
ESD
(1) JEDEC document JEP155 states that 500-V HBM allows safe manufacturing with a standard ESD control process.
(2) JEDEC document JEP157 states that 250-V CDM allows safe manufacturing with a standard ESD control process.

8.3 Recommended Operating Conditions

over operating free-air temperature range (unless otherwise noted)
(1)
Operating junction temperature
Operating supply voltage (VDDS)
Rising supply voltage slew rate
Falling supply voltage slew rate
(1) For thermal resistance characteristics refer to Section 8.8.

8.4 Power Supply and Modules

over operating free-air temperature range (unless otherwise noted)
PARAMETER
VDDS Power-on-Reset (POR) threshold
VDDS Brown-out Detector (BOD)
VDDS Brown-out Detector (BOD), before initial boot
VDDS Brown-out Detector (BOD)
(1) Brown-out Detector is trimmed at initial boot, value is kept until device is reset by a POR reset or the nRESET pin
10 Submit Document Feedback
(4) (5)
Voltage scaling enabled
Voltage scaling disabled, internal reference
Voltage scaling disabled, VDDS as reference
Human body model (HBM), per ANSI/ESDA/JEDEC JS001
Charged device model (CDM), per JESD22-C101
Rising threshold
(1)
Rising threshold
Falling threshold
Product Folder Links:
(1) (2)
MIN
–0.3
–0.3
–0.3
–0.3
–0.3
–40
(1)
All pins
(2)
All pins
Copyright © 2022 Texas Instruments Incorporated
CC2652PSIP
www.ti.com
MAX UNIT
4.1 V
VDDS + 0.3, max 4.1 V
VDDS
1.49 V
VDDS / 2.9
5 dBm
150 °C
VALUE UNIT
±1000 V
±500 V
MIN MAX UNIT
–40 105 °C
1.8 3.8 V
0 100 mV/µs
0 20 mV/µs
MIN TYP MAX UNIT
1.1 1.5 V
1.77 V
1.70 V
1.75 V
