CC2652PSIP
SWRS263A – FEBRUARY 2021 – REVISED JUNE 2022
T = 25 °C, V = 3.0 V, unless otherwise noted.
c DDS
PARAMETER
Offset error
Max code output voltage
variation
Output voltage range
Load = Low Power Clocked
Comparator
(1) 1 LSB (V 3.8 V/3.0 V/1.8 V/DCOUPL/ADCREF) = 14.10 mV/11.13 mV/6.68 mV/4.67 mV/5.48 mV
REF
(2) Includes comparator offset
(3) A load > 20 pF will increases the settling time
(4) Keysight 34401A Multimeter
