8.12 Zigbee and Thread - IEEE 802.15.4-2006 2.4 GHz (OQPSK DSSS1:8, 250 kbps) - RX

Measured on the CC2652xSIP-EM
DC/DC enabled and high power PA connected to V
All measurements are performed at the antenna input with a combined RX and TX path, except for high power PA which is
measured at a dedicated antenna connection. All measurements are performed conducted.
PARAMETER
General Parameters
Receiver sensitivity
Receiver saturation
Adjacent channel rejection
Alternate channel rejection
Channel rejection, ±15 MHz or more
Blocking and desensitization,
5 MHz from upper band edge
Blocking and desensitization,
10 MHz from upper band edge
Blocking and desensitization,
20 MHz from upper band edge
Blocking and desensitization,
50 MHz from upper band edge
Blocking and desensitization,
–5 MHz from lower band edge
Blocking and desensitization,
–10 MHz from lower band edge
Blocking and desensitization,
–20 MHz from lower band edge
Blocking and desensitization,
–50 MHz from lower band edge
Spurious emissions, 30 MHz to 1000
MHz
Spurious emissions, 1 GHz to 12.75
GHz
Frequency error tolerance
Symbol rate error tolerance
RSSI dynamic range
RSSI accuracy
Copyright © 2022 Texas Instruments Incorporated
reference design with T
c
unless otherwise noted.
DDS
TEST CONDITIONS
PER = 1%
PER = 1%
Wanted signal at –82 dBm, modulated interferer at ±5 MHz,
PER = 1%
Wanted signal at –82 dBm, modulated interferer at ±10 MHz,
PER = 1%
Wanted signal at –82 dBm, undesired signal is IEEE
802.15.4 modulated channel, stepped through all channels
2405 to 2480 MHz, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Wanted signal at –97 dBm (3 dB above the sensitivity level),
CW jammer, PER = 1%
Measurement in a 50-Ω single-ended load
Measurement in a 50-Ω single-ended load
Difference between the incoming carrier frequency and the
internally generated carrier frequency
Difference between incoming symbol rate and the internally
generated symbol rate
Product Folder Links:
SWRS263A – FEBRUARY 2021 – REVISED JUNE 2022
= 25 °C, V = 3.0 V, f = 2440 MHz with
DDS RF
CC2652PSIP
CC2652PSIP
MIN TYP MAX
–98
> 5
36
57
59
57
62
62
65
59
59
63
65
–66
–53
> 350
> 1000
95
±4
Submit Document Feedback
UNIT
dBm
dBm
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dBm
dBm
ppm
ppm
dB
dB
